Optimus Operation

33-3021.fm Page 1 Tuesday, August 10, 1999 12:18 PM
Unidirectional Dynamic Microphone
The Optimus Unidirectional Dynamic Micro-
phone is a high-quality microphone that pro-
vides the performance you need for your PA
or recording system. Its directional pickup
pattern allows a greater distance between
the microphone and the sound source, while
reducing background noise and feedback.
Other features include:
Frequency Response — lets you pick up a
wide range of sound, from low to high, to pro-
vide a more natural sound.
Switch — let's you conveniently turn the mi-
crophone on and off at any time.
Unidirectional Pickup Pattern — controls
feedback, reduces pickup of undesired sig-
nals, and provides increasd sensitivity in any
direction you point the microphone.
Wire-Mesh Windscreen — effectively cuts
down wind noise and voice "pops" so singers
and speakers can perform close to the mi-
crophone.
Internal Filter Design — helps reduce feed-
back.
Swivel Adapter —positive action swivel to fit
5
standard / inch threads.
8
RadioShack is a trademark used by Tandy Corporation.
RadioShack is a trademark sed by Tandy Corporation
OPERATION
1. Adjust the microphone volume on
your PA or recording system to mini-
mum.
2. Plug your microphone's
the microphone jack of your PA or
recording system.
3. Turn on your PA or recording system.
4. Set the microphone's switch to
Adjust the microphone volume on your
PA or recording system to the desired
level. When you finish using the micro-
phone, set the switch to the opposite
position of
If you want to use the supplied swivel adapt-
er with your microphone, screw it onto the
top of a microphone stand. Then slide the mi-
crophone into the larger end of the holder un-
til it reaches the security position.
©
1997 Tandy Corporation.
All Rights Reserved.
© 1997 Tandy Corporation.
All Rights Reserved.
33-3021
Cat. No.
1
/ -inch plug into
4
ON.
.
ON
1
