For Your Records and Warranty Assistance Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: _______________________ Date Purchased: ___________________ Where Purchased: _________________ For reference also attach your receipt or a copy of your receipt to the manual. 42503-01 • 02/08/06...
• Read this entire manual carefully before beginning installation. Save these instructions. • Use only Hunter replacement parts. • To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these instructions, and use only the hardware supplied.
Page 3
Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation fl exibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profi le, Standard, or Angle mounting. e steps in this manual include instructions for all three Installer’s Choice mounting methods.
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...
CAUTION: To avoid possible electrical shock, before installing your fan, disconnect the power by turning off the circuit breakers to the outlet box and associated wall switch location. If you cannot lock the circuit breakers in the off position, securely fasten a prominent warning device, such as a tag, to the service panel.
For Standard or Angled Mounting: 3-1. Unbundle the wires from the fan. 3-2. To assemble fan to hang down from a flat or angled ceiling, insert the downrod through the canopy and canopy trim ring. Feed the wires from the fan through the downrod.
Page 7
3-10. Align the holes in the washer with the holes in the adapter. Assemble securely with three low profile screws. 3-11. Raise the fan and place the hook on the adapter through the loop on the ceiling plate. Loop...
2. Press fi rmly on opposite sides of the ring towards the canopy. e tabs will fl ex out releasing the trim ring from the canopy. 42503-01 • 02/08/06 5 • Installing the Canopy and Canopy Trim Ring Step 5-1 Tab Hole Steps 5-2 –...
Mounting Screw Hunter Fan Company Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades.
Align the side screw holes in the upper and lower switch housings. Attach the lower switch housing to the upper switch housing with three housing assembly screws. 42503-01 • 02/08/06 7 • Completing Your Installation Steps 7-1 – 7-3...
Hunter Fan Company 8-1. Turn on electrical power to the fan. 8-2. e fan pull chain controls power to the fan. e pull chain has four settings in sequence: High, Medium, Low and Off . • Pull the chain slowly to change settings.
Page 13
7% on energy costs. So, you can cut back on expensive air conditioning...and save up to 40%* on cooling. In winter, your Hunter fan recirculates warm air and saves up to 10%* on heating bills.
1. If your fan wobbles when operating, use the enclosed balancing kit and instructions to balance the fan. 2. Tighten all blade and/or blade iron screws. 3. Turn power off , support fan very carefully, and check that the hanger ball is properly seated. 42503-01 • 02/08/06...
