Pix Controller DigitalEye Instruction Manual page 6

Sensor
Switch 1
Address
A Down/Off
B Down/Off
C Down/Off
D Down/Off
E Up/On
F Up/On
G Up/On
H Up/On
PIR Delay Setting
Switches 4, 5, and 6 control the delay between PIR events. This setting is used so you can limit
or not limit the number of photos taken when a motion event.
PIR Delay
Switch 1
Digital Units
Trail Mode Down/Off
10 Seconds Down/Off
30 Seconds Down/Off
1 Minute Down/Off
5 Minutes Up/On
10 Minutes Up/On
15 Minutes Up/On
20 Minutes Up/On
Picture Mode Setting
Switch 7 controls the operation of the attached camera. Here you can either setup your camera in
digital still mode, or movie/double photo mode. If you want to take digital movies with your digital
camera you must have your digital camera setup in movie mode.
Picture Mode
Still Photo
Movie or Double
Switch 2 Switch 3
Down/Off Down/Off
Down/Off Up/On
Up/On Down/Off
Up/On Up/On
Down/Off Down/Off
Down/Off Up/On
Up/On Down/Off
Up/On Up/On
Switch 2 Switch 3
Down/Off Down/Off
Down/Off Up/On
Up/On Down/Off
Up/On Up/On
Down/Off Down/Off
Down/Off Up/On
Up/On Down/Off
Up/On Up/On
Switch 7
Down/Off
Up/On
