OPERATOR'S MANUAL
Tiller/Cultivator
This product is covered by U. S. patents and other international patents
Copyright All Rights Reserved.
Model TC70001
This product has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual
before using this product.
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING, ASSEMBLY, PARTS, SERVICE QUESTIONS?
CALL 1-800-313-5111 BETWEEN 7:30AM-4:30PM EST FOR ASSISTANCE.
SAVE THIS MANUAL FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading

Related Manuals for EarthWise TC70001

Summary of Contents for EarthWise TC70001

  • Page 1 This product is covered by U. S. patents and other international patents Copyright All Rights Reserved. Model TC70001 This product has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    Operating ........7 - 8 PRODUCT SPECIFICATIONS Model: TC70001 Power supply voltage:...

  • Page 3: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. Precautions that involve your safety. Read the instruction manual and follow the warning and safety instructions! SWITCH OFF! Remove plug from outlet immediately if the cable is damaged or cut.

  • Page 4: Safety Warnings

    IMPORTANT SAFETY WARNINGS TO REDUCE RISK OF INJURY: Before any use Save these instructions and review frequently prior be sure everyone using this product reads and to use and in instructing others. understands all safety instructions and other WARNING: When using electric gardening information contained in this manual.

  • Page 5: General Safety

    GENERAL SAFETY GROUND FAULT CIRCUIT INTERRUPTER (GFCI) STAY ALERT - Watch what you are doing. Use protection should be provided on the circuit or outlet common sense. Do not operate the tiller/cultivator to be used for the tiller/cultivator. Receptacles are when you are tired or under the influence of drugs available having built-in GFCI protection and may or medication.

  • Page 6: Assembly

    ASSEMBLY This product must be assembled correctly before use. 7. Install the switch and power cable assembly onto the upper handle section using the two supplied bolts 1. Remove the screws (M5 X 12) and washers from (ST3.9 x 19). (Fig. 2-6) wheel frame.

  • Page 7: Operating

    OPERATING STARTING: To lower wheel frame, push the lock button on back of motor housing to release the frame. Lower the Make sure the wheel frame is raised before you wheel frame and pull out the lock pin on lower start the tiller.

  • Page 8: Operating

    OPERATING For preparing seed beds, we recommend using one of these tilling patterns: Tilling Pattern A– Make two passes over area to be Tilling Pattern B– Make two passes over area to be tilled, the second at a right angle to the first. tilled, the second overlapping the first.

  • Page 9: Maintenance

    MAINTENANCE Before carrying out maintenance operations, disconnect power supply. Before each use check the extension cord for Replace worn or damaged parts with original signs of damage or ageing. Replace the cable if replacement parts only. Parts from another tiller/ it is cracked, split or otherwise damaged.

  • Page 10: Storage

    Replace damaged or worn blades. CALL US FIRST !! Call us first with questions about operating or maintaining this product at 1.800.313.5111 between 7:30 a.m. – 4:30 p.m. Eastern Standard Time, or send emails to earthwise@reelin.com. The Great States Corporation American Lawn Mower Company...

  • Page 11: Warranty

    WARRANTY This product is manufactured for The Great States Corporation/American Lawn Mower Company. The Great States Corporation/American Lawn Mower Company, Shelbyville, Indiana, has been making lawn mowers for over 100 years and it warrants to the original owner that each new product and service part is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective product or part from the original date of purchase for two (2) years except for the conditions and circumstances listed below.

  • Page 12: Repair Parts

    REPAIR PARTS Please record your serial number in the space provided below. • NAME OF ITEM Tiller/Cultivator • MODEL NUMBER TC70001 • SERIAL NUMBER The Great States Corporation American Lawn Mower Company 830 Webster Street Shelbyville, IN 46176 Phone 1-800-313-5111 www.americanlawnmower.com...
