SET-UP INSTRUCTIONS (continued)
6. Connect the rest of the hoses together outside the pool, in the order of
hose description (Fig. 6), B-C-B-C-B-D or B-C-B-D.
For pool size above 18':
(B)
For pool size 18' and below:
7. With hose clamp (6), fasten the end
of hose D (11) to the top connection
of cleaner. A small coin can be used
to tighten the hose clamp. See Fig. 7.
8. Place auto cleaner into the water. Fill up the hose assembly with water
by submerging the hose into the water to remove all of the entrapped air
from the hose.
9. Connect hose B (9) from the hose assembly to the hose A (8) which
was already installed in step 4. See Fig. 8.
9
10. Set up the Filter Pump following the Filter Pump owner's manual. The
auto cleaner is now ready to use.
SAVE THESE INSTRUCTIONS
