SET-UP INSTRUCTIONS (continued)
3. From inside of the pool, unscrew the nozzle from the water return
connector (upper hose connection). See Fig. 3.
Lower Hose
Connection
Inside of
the Pool
Wall
4. Screw the hose adaptor (7) to hose
A (8). See Fig. 4.
NOTE: Please use hose adaptor for
small AGP pool (12) instead of hose
adaptor (7) If your pool comes
with 1-1/4" outlet.
5. Screw the end of hose A (8) with
adaptor to the threaded strainer
connector, from inside of the pool.
See Fig. 5.
SAVE THESE INSTRUCTIONS
(100IO) AUTO CLEANER ENGLISH 7.5" X 10.3" PANTONE 295U 08/05/2008
Upper Hose
Connection
8
8
English
3
Threaded Strainer
Connector
nozzle
4
7
5
Threaded Strainer
Connector
Page 7
