Summary of Contents for Hyundai 2009 Entourage

Page 1 2009 Owner’s Manual...
Page 2 RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 7. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals. When the vehicle is used in severe driving conditions, more frequent main- tenance is required for some operations.
Page 3 Specifications All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment.
Page 4 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your Hyundai should not be modified in any way. Such modifications may adversely affect the per- formance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations estab- lished by the U.S.
Page 5 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTICE. These titles indicate the following: WARNING This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning. CAUTION This indicates that a condition may result in damage to your vehicle or its equipment if the caution is not heeded.
Page 6 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it care- fully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
Page 7 English. facturing requirements. Using imita- tion, counterfeit or used salvage parts Hyundai Genuine Parts are only sold A100A03L is not covered under the Hyundai New through authorized Hyundai Vehicle Limited Warranty or any other Dealerships.
Page 9 Introduction Your vehicle at a glance Features of your vehicle Driving your vehicle What to do in an emergency table of contents Maintenance Consumer information, Reporting safety defects Specifications Index...
Page 10 Introduction How to use this manual / 1-2 Fuel requirements / 1-2 Vehicle break-in process / 1-3 Vehicle data collection and event data recorders / 1-4...
Page 11: Introduction
10% ethanol or grain alcohol) A NOTICE indicates interesting or help- glance if that section has the information may be used in your Hyundai. However, if ful information is being provided. you want. your engine develops driveability prob- lems, the use of 100% unleaded gasoline is recommended.
Page 12: Vehicle Break-In Process
• Don't drive faster than 55 MPH (88 Operation in Foreign Countries km/h). Do Not Use Methanol If you are going to drive your Hyundai in • While driving, keep your engine speed another country, be sure to: Fuels containing methanol (wood alco- (rpm, or revolutions per minute) hol) should not be used in your Hyundai.
Page 13: Vehicle Data Collection And Event Data Recorders
• as part of Hyundai’s defense of liti- determine when the airbag and seat how it was being operated. This infor-...
Page 14: Your Vehicle At A Glance
Your vehicle at a glance Interior overview / 2-2 Instrument panel overview / 2-3...
Page 15: Table Of Contents
Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button ....3-13 2. Driver position memory system*..3-57 3. Seat adjust knob*......3-39 4. Outside rearview mirror control switch ..........3-105 5. Power rear quarter window switches* ...........3-28 6. Power window switches ....3-28 7.
Page 16: Instrument Panel Overview
Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Driver’s air bag .......3-79 2. Light control / Turn signals ...3-129 3. Instrument cluster......3-109 4. Wiper/Washer .......3-132 5. Auto cruise controls* ......4-14 6. Audio controls* ......3-181 7. Steering wheel ......3-102 8. Ignition switch........4-5 9.
Page 17: Driver Position Memory System
Keys / 3-3 Remote keyless entry / 3-4 Theft-alarm system / 3-7 Immobilizer system / 3-8 Door locks / 3-10 Power sliding door and power tailgate / 3-17 Features of your vehicle Window / 3-26 Hood / 3-29 Fuel filler lid / 3-30 Sunroof / 3-33 Seat / 3-36 Driver position memory system / 3-57...
Page 18 Interior lights / 3-125 Lighting / 3-128 Wipers and washers / 3-132 Horn / 3-135 Defroster / 3-136 Features of your vehicle Hazard warning flasher / 3-137 Manual climate control system / 3-138 Automatic climate control system / 3-150 Windshield defrosting and defogging / 3-164 Luggage net holder / 3-167 Roof rack / 3-168 Homelink®...
Page 19: Features Of Your Vehicle
KEYS Key operations WARNING Master key Use only Hyundai original parts for Used to start the engine, lock and unlock the ignition key in your vehicle. If the doors, lock and unlock the glove box an aftermarket key is used, the igni- and center console storage (if equipped).
Page 20: Remote Keyless Entry /
Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) (3) Power tailgate opening or closing Type A (1) Lock ( , if equipped) All doors are locked if the lock button The tailgate is opened or closed is pressed. automatically if the button is pressed. If all doors are closed, the hazard The hazard warning lights will blink warning lights blink once to indicate...
Page 21 If you have a problem large amounts of vehicle electric with the transmitter, contact an author- power. To prevent the battery from ized Hyundai Dealer. being discharged, do not operate them consecutively (more than approximately 10 times).
Page 22 2. Replace the battery with new one. When replacing the battery, make sure the battery positive “+” symbol faces up as indicated in the illustration. 3. Install the battery in the reverse order of removal. For replacement transmitters, see an Authorized Hyundai Dealer for repro- gramming.
Page 23: Theft-Alarm System /
Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage • If any door, tailgate or engine hood remains open, the system will not Park the car and stop the engine. Arm be armed. If this happens, re-arm the system as described below. the system as described previously.
Page 24: Immobilizer System /
Features of your vehicle IMMOBILIZER SYSTEM (IF EQUIPPED) Theft-alarm stage Disarmed stage Your vehicle is equipped with an elec- The alarm will be activated if any of the The system will be disarmed when the tronic engine immobilizer system to following occurs while the system is doors are unlocked by depressing the reduce the risk of unauthorized vehicle...
Page 25: Switch
Limp home (override) procedure system: If you need additional keys or lose your When you turn the ignition key to the ON keys, consult your authorized Hyundai position, if the immobilizer indicator Insert the ignition key into the key cylin- dealer.
Page 26: Door Locks /
After performing the limp home proce- authorized Hyundai dealer. Unlock dure, you have to see an authorized Lock Hyundai dealer immediately to inspect Malfunctions caused by improper and repair your ignition key or immobiliz- alterations, adjustments or modifi- cations to the immobilizer system er system.
Page 27 Features of your vehicle • Once the doors are unlocked, they may Rear sliding doors Rear sliding doors be opened by pulling the door handle. • To close the door, push the door by hand. Make sure that doors are closed securely.
Page 28 Features of your vehicle Front door WARNING WARNING When the rear sliding door is not Always remove the ignition key, fully open, it is not latched and may engage the parking brake, close all move unintentionally. This could windows and lock all doors when result in a serious injury.
Page 29: Central Door Lock Switch
Features of your vehicle • To lock a door, push the door lock but- Front door Driver’s door ton (1) to the “Lock” position. If the door is locked, red part (2) of the button is Unlock Lock not visible. •...
Page 30 Features of your vehicle Passenger’s door (if equipped) WARNING - WARNING Doors Unlocked vehicles • The doors should always be fully closed and locked while the vehi- Always remove the ignition key, cle is in motion to prevent acci- engage the parking brake, close all dental opening of the door.
Page 31 Features of your vehicle 3. Close the rear door. To open the rear door, pull the outside door handle or push the main control but- ton of the power sliding door. Even though the doors may be unlocked, the rear door will not open by pulling the inner door handle or pushing the sub control button until rear door child safety lock is unlocked (...
Page 32: Driving Your Vehicle
Features of your vehicle WARNING WARNING Exhaust fumes • In cold and wet climates, door lock and door mechanisms may The tailgate should always be kept not work properly due to freezing completely closed while the vehicle conditions. Be sure that all the is in motion.
Page 33: Power Sliding Door And Power Tailgate /
Features of your vehicle POWER SLIDING DOOR AND POWER TAILGATE (IF EQUIPPED) (1) Left power sliding door main control On the overhead console WARNING button (2) Right power sliding door main control Never leave children or animals button unattended your vehicle.
Page 34 This must be done by may stop at that position. At this time, an authorized Hyundai dealer. 1VQA2347 close the doors manually and operate • When jacking up the vehicle to the door automatically again.
Page 35 Hyundai dealer. • Make sure there are no people or 1. Put the shift lever in the P (Park) for objects around the door before ✽...
Page 36 Features of your vehicle • When the power ON/OFF button WARNING (PWR) is OFF (not depressed), the power sliding door and power tailgate • Keep the power ON/OFF button can not be controlled with the sub con- (PWR) in the OFF (not depressed) trol buttons or door handles.
Page 37 Features of your vehicle - If the door handle is pulled from On the overhead console On the center pillar trim inside or outside while the door is locked or child safety lock is engaged, the power sliding door will not open.
Page 38 Features of your vehicle WARNING WARNING If children accidentally open the • Rear passengers should get in or sliding doors while the vehicle is in out of the vehicle only after the motion, they could fall out and be door completely opened.
Page 39 Features of your vehicle • If the window on the power sliding door • The left power sliding door cannot be • If the power sliding door is operated is open (more than 3 in./80 mm), the opened while the fuel filler lid is open again while the door is closing, the power sliding door will not power open fully.
Page 40 Features of your vehicle Power sliding door non-opening condi- On the overhead console On the tailgate tions When the ignition switch is in the ON position, the power sliding door will only automatically close under the following conditions: 1. Vehicle is moving above 3 mph (5 km/h). 2.
Page 41 Features of your vehicle • When the power ON/OFF button • If the power tailgate is operated again WARNING (PWR) is OFF (not depressed), the while the tailgate is closing, the tailgate power tailgate cannot be controlled is automatically opened fully. Make sure there are no people or with the sub control buttons or tailgate •...
Page 42: Power Rear Quarter Window
Features of your vehicle WINDOWS Power windows (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Power rear quarter window (left) switch* (6) Power rear quarter window (right) switch*...
Page 43 Features of your vehicle The ignition switch must be in the ON (Continued) (Continued) position for power windows to operate. • Never try to operate the main • Do not attempt to operate the Each door has a power window switch switch on the driver's door and main switch on the driver's door that controls that door’s window.
Page 44: Power Window Switches
Features of your vehicle Automatic power window down (driver’s window) Depressing the power window switch momentarily to the second detent posi- tion (9) completely lowers the driver’s window even when the switch is released. To stop the window at the desired position while the window is in operation, pull up the switch momentarily to the opposite direction of the window...
Page 45 Features of your vehicle HOOD Closing the hood 1. Before closing the hood, check the fol- lowing: • All filler caps in engine compartment must be correctly installed. • Gloves, rags or any other com- bustible material must be removed from the engine compartment.
Page 46: Fuel Filler Lid /
Features of your vehicle FUEL FILLER LID WARNING - Refueling • Always remove the fuel cap care- fully and slowly. If the cap is vent- ing fuel or if you hear a hissing sound, wait until the condition stops before completely remov- ing the cap.
Page 47 Features of your vehicle (Continued) (Continued) WARNING - Refueling dan- • Do not get back into a vehicle Use only approved portable plas- gers tic fuel containers designed to once you have begun refueling Automotive fuels are flammable carry and store gasoline. since you can generate static materials.
Page 48 • If the fuel filler cap requires replacement, use only a genuine OVQ036007N Hyundai cap or the equivalent When fuel filler lid does not open specified for your vehicle. An with the release button incorrect fuel filler cap can result...
Page 49: Sunroof /
Features of your vehicle SUNROOF (IF EQUIPPED) The sunroof can only be opened, closed, or tilted when the ignition switch is in the ON position. The sunroof can be operated for approx- imately 30 seconds after the ignition key is removed or turned to the ACC or LOCK position.
Page 50 Features of your vehicle Open Open Autoslide Autotilt To use the autoslide feature, momentari- To use the autotilt feature, momentarily ly (less than 0.4 second) press the slide (less than 0.4 second) press the tilt but- button on the overhead console. ton on the overhead console.
Page 51 Features of your vehicle 2) in case that the sunroof has slide- CAUTION opened: • Do not press any sunroof control Press and hold the close button button longer than necessary. (for more than 5 seconds) until the Damage to the motor or system sunroof has closed completely.
Page 52 Features of your vehicle SEAT Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height (4) Seat warmer* (5) Headrest (6) Armrest (7) Lumbar support Rear seats (8) Forward and backward (9) Seatback angle (10) Headrest (11) Armrest (12) Stowing* * if equipped WARNING...
Page 53 Features of your vehicle (Continued) WARNING - WARNING Uprighting - Rear Seatback • Do not allow anything to interfere seat • The rear seatback must be with the normal position of the securely latched. If not, passen- When you return the seatback to its seatback.
Page 54 Features of your vehicle WARNING Driver respon- sibility for front seat pas- senger Riding with a reclined seatback increases your chance of serious or fatal injuries in the event of a colli- sion or sudden stop. The protection of your restraint system (seat belts and air bags) is greatly reduced by reclining your seat.
Page 55 Features of your vehicle CAUTION • Power seats are driven by an electric motor. Stop operating once the adjustment is complet- ed. Excessive operation may damage the electrical equipment. • When in operation, the power seats consume large amounts of electrical power.
Page 56 Features of your vehicle (Continued) Seat belts must be snug against your hips and chest to work proper- The more the seatback is reclined, the greater the chance that an occupant's hips will slide under the lap belt causing serious internal injuries or the occupant's neck could strike the shoulder belt.
Page 57 Features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most people's head is similar with height of the top of their eyes.
Page 58 Features of your vehicle 1VQH3900N 1VQA2049 1VQA2050 Active headrest (if equipped) Forward and backward adjustment Adjusting the height up and down The active headrest is designed to move The headrest may be adjusted forward to To raise the headrest, pull it up to the forward and upward during a rear impact.
Page 59 Features of your vehicle OVQ039001 OVQ027052 OVQ028053 Removal Armrest (for driver’s seat) Seatback pocket To remove the headrest, raise it as far as The front seat armrest are located on the A seatback pocket is provided on the it can go then press the release button side of the seatback.
Page 60: Seat Warmer*
Features of your vehicle CAUTION WARNING • When cleaning the seats, do not For proper operation of the occu- use an organic solvent such as pant classification system: thinner, benzene, alcohol and • Do not place any items cumula- gasoline. Doing so may damage tively weighing over 2.2 lbs (1 kg) the surface of the heater or seats.
Page 61 Features of your vehicle 2nd row seat OVQ036204N 3rd row seat 1VQA2042 OVQ036203N Lumbar support Rear seat adjustment (driver’s seat only, if equipped) Adjusting the seat forward and back- You can adjust the lumbar support by ward (2nd row) moving the lever on the outside of the dri- To move the seat forward or backward: ver’s seatback.
Page 62 Features of your vehicle 2. Carefully lean back on the seat and adjust the seatback of the seat to the position you desire. 3. Release the lever (or strap) and make sure the seatback is locked in place. (The lever MUST return to its original position for the seatback to lock.) OVQ036206N OVQ039300N-3...
Page 63 Features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most people's head is similar with height of the top of their eyes.
Page 64 Features of your vehicle 2nd row seat WARNING - Uprighting seat When you return the seatback to its upright position, hold the seatback and return it slowly. If the seatback is returned without holding it, the back of the seat could spring for- ward resulting in accidental injury from being struck by the seatback.
Page 65 Features of your vehicle 3rd row seat OVQ036209N OVQ036210N OVQ036208N 3. Push down the seat backward firmly to 4. Make sure the green mark on the rear 3rd row seat lock the catches into the rear anchors seat cushion frame is visible and the 1.
Page 66 Features of your vehicle To unfold the rear seat: 1. Pull up the seatback recline lever (or folding strap). 2. Lift and push the seatback backward firmly until it clicks into place. Make sure the seatback is locked in place. 3.
Page 67 Features of your vehicle OVQ036213N OVQ036210N OVQ036211N To unfold the rear seat 4. Make sure the green mark on the rear Removing the rear seat (2nd row) seat cushion frame is visible and the 1. Untie the strap from the assist handle. To remove a rear seat: catches are locked in position by mov- 1.
Page 68 Features of your vehicle OVQ036214N OVQ036216N OVQ036217N To install the rear seat: 3. Lift the rear portion of the seat cushion then push down firmly to lock the 1. Put the front anchor strikers along the catches into the rear anchors until an front anchors on the floor.
Page 69 Features of your vehicle OVQ036210N OVQ036400L OVQ036401E/OVQ036402L 4. Make sure the green mark on the rear If the rear catches of the seat are locked 1. Lift the seatback (2) while pulling up seat cushion frame is visible and the into the rear anchors (2) while the front the seatback recline lever (1) and push catches are locked in position by mov-...
Page 70 Features of your vehicle OVQ036403L OVQ036218N OVQ036219N 4. Remove the seat while lifting up the Stowing the rear seat (3rd row) 3. Pull the seat by using the stowing rear portion of seat cushion (6). strap. The rear seat can be folded and stowed in the luggage compartment to provide additional cargo space.
Page 71 Features of your vehicle OVQ036220N OVQ036221N OVQ036222N 4. Stow the seat by pushing down firmly. To use the rear seat: 2. Release the strap and push the seat forward firmly until it clicks into place to 1. Lift the seat by pulling out the stowing insert the catches into the anchors.
Page 72 Features of your vehicle 2nd row 3rd row CAUTION - Avoid damag- ing rear seat belt buckles When you fold the rear seatback or put luggage on the rear seat cush- ion, insert the buckle in the pocket between the rear seatback and cushion.
Page 73: Driver Position Memory System /
Features of your vehicle DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED) WARNING WARNING - Cargo Cargo should always be secured to Never attempt to operate the driver prevent it from being thrown about position memory system while the the vehicle in a collision and caus- vehicle is moving.
Page 74 WARNING Have the driver position memory system and exit the vehicle. checked by an authorized Hyundai deal- Use caution when recalling adjust- • It will move the driver’s seat rearward ment memory while sitting in the when the ignition key is removed.
Page 75: Power Adjustable Pedals /
Features of your vehicle POWER ADJUSTABLE PEDALS (IF EQUIPPED) SEAT BELTS Setting the adjustable pedal posi- Seat belt precautions tion 1. Be sure the parking brake is engaged. WARNING 2. Move the accelerator and brake ped- All occupants of the vehicle must als to the front most position by push- wear their seat belts at all times.
Page 76 Features of your vehicle Larger children WARNING WARNING - Shoulder belts Children who are too large for child on small children restraint systems should always occupy Every person in your vehicle needs the rear seat and use the available to be properly restrained at all •...
Page 77 Hyundai Dealer. will slide under the lap belt causing serious internal injuries or the occupant's neck could strike the shoulder belt.
Page 78 Features of your vehicle Release the button to lock the anchor 1st and 2nd row into position. Try sliding the height adjuster to make sure that it has locked into position. WARNING • Verify the shoulder belt anchor is locked into position at the appro- priate height.
Page 79 ON, the safety belt warning provides the same level of protection for passenger seat position, Hyundai strong- light will blink until the belt is fas- seated passengers in either emergency ly recommends that children always be tened.
Page 80 Features of your vehicle (Continued) • Children age 12 and younger must always properly restrained in the rear seat. Never allow children to ride in the front passenger seat. If a child over 13 must be seated in the front seat, he/she must be properly belted and the seat should be moved as far back as possible.
Page 81 Features of your vehicle OVQ036225N OVQ036097N 1VQH3903 3-Point rear center seat belt (3rd row) 2. Insert the tongue plate (A) into the 3. Pull the tongue plate (B) and insert the open end of the buckle (C) until an tongue plate (B) into the open end of To fasten the rear center belt audible “click"...
Page 82 Features of your vehicle There will be an audible “click” when the tab locks in the buckle. The seat belt automatically adjusts to the proper length only after the lap belt is adjusted manu- ally so that it fits snugly around your hips. If you lean forward in a slow, easy motion, the belt will extend and let you move around.
Page 83 Features of your vehicle Proper use and care of the seat 3rd row seat belt system To ensure that the seat belts provide the maximum protection, please follow these instructions: • Use the seat belts at all times - even on short trips.
Page 84 1LDE3100 Pre-tensioner seat belt The seat belt pre-tensioner system con- sists mainly of the following components. Your Hyundai vehicle is equipped with Their locations are shown in the illustra- driver's and front passenger's pre-ten- tion: sioner seat belts. The purpose of the pre- 1.
Page 85 6 seconds, or if it pre-tensioner seat belts were activat- illuminates while the vehicle is being driven, please have an authorized Hyundai dealer inspect the pre-tensioner seat belt or SRS air bag system as soon as possi- ble. 3 69...
Page 86 • Do not attempt to inspect or replace the pre-tensioner seat belts yourself. This must be done by an authorized Hyundai dealer. • Do not strike the pre-tensioner seat belt assemblies. • Do not attempt to service or repair the pre-tensioner seat belt system in any manner.
Page 87: Child Restraint System /
Features of your vehicle CHILD RESTRAINT SYSTEM Children riding in the car should sit in the WARNING WARNING rear seat and must always be properly restrained to minimize the risk of injury in • A child restraint system must be To reduce the chance or serious or an accident, sudden stop or sudden placed in the rear seat.
Page 88 Features of your vehicle Using a child restraint system (Continued) (Continued) For small children and babies, the use of • Never leave children unattended • Never use an infant carrier or a a child seat or infant seat is required. This in a vehicle –...
Page 89 Features of your vehicle 2nd row seat WARNING Tether strap • A child can be seriously injured or killed in a collision if the child restraint properly anchored. Always follow the child seat manufacturer’s instructions for installation and use. • Never mount more than one child restraint to a single tether or to a single lower anchorage point.
Page 90 Features of your vehicle WARNING - Child restraint anchorage • Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circum- stances are they to be used for adult seat belts or harnesses or for attaching other items or equipment to the vehicle.
Page 91 Features of your vehicle Also, test the child restraint seat before WARNING WARNING you place the child in it. Tilt the seat from side to side. Also try to tug the seat for- • A child can be seriously injured Install the child restraint seat fully ward.
Page 92 Features of your vehicle E2MS103005 E2BLD310 MMSA3028 Installing a child restraint system by 2. Fasten the lap/shoulder belt latch into 3. Pull the shoulder portion of the seat lap/shoulder belt belt all the way out. When the shoulder the buckle. Listen for the distinct “click” sound.
Page 93 Features of your vehicle WARNING - Auto lock mode The lap/shoulder belt automatically returns to the “emergency lock mode” whenever the belt is allowed to retract fully. Therefore, the pre- ceding seven steps must be fol- lowed each time a child restraint is installed.
Page 94 Features of your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM Front passenger’s Driver’s air bag Side impact air bag Curtain Air bag air bag Side impact sensor Front impact sensor Front seat position Occupant classi- SRS control module sensor fication system OEP036094/1VQA2076/OVQ028077/OVQ037900N/OVQ036017N/1VQA2079/1VQA2323/OEP036080/OVQ036096N/OVQ036095N/1VQA2081...
Page 95 The Hyundai SRS consists of air bags installed under the pad covers in the cen- ter of the steering wheel and the passen- ger's side front panel above the glove box.
Page 96 6 sec- front seat. These may cause a contact Hyundai Customer onds when the ignition key is malfunction of the seat track Assistance Center at 1-800-633-5151.
Page 97 Hyundai dealer inspect the air can be severely injured when the air • Do not allow a passenger to ride bag system as soon as possible. bag inflates. Always follow the pre- in the front seat when the “PAS-...
Page 98 Never be replaced by an authorized allow children to ride in the front OVQ036018N Hyundai dealer. Deployed air passenger seat. If a child over 13 Rollover bags WILL NOT inflate again and must be seated in the front seat,...
Page 99 Features of your vehicle SRS components and functions The SRSCM continually monitors all ele- (Continued) ments while the ignition is "ON" to deter- The SRS consists of the following com- • For maximum safety protection in mine if a frontal or near-frontal impact is ponents: all types of crashes, all occupants severe enough to require air bag deploy-...
Page 100 Features of your vehicle Driver’s front air bag Driver’s front air bag Driver’s front air bag B240B01L B240B02L B240B03L The air bag modules are located both in Upon deployment, tear seams molded A fully inflated air bag, in combination the center of the steering wheel and in directly into the pad covers will separate with a properly worn seat belt, slows the the front passenger's panel above the...
Page 101 Features of your vehicle Passenger’s front air bag Passenger’s front air bag (Continued) If there is any leakage from the air freshener onto these areas (instrument cluster, instrument panel or air ventilator), it may damage these parts. If the liquid from the air freshener does leak onto these areas, wash them with water immediately.
Page 102 OVQ038012N vehicle immediately inspected by This system detects the conditions 1~4 Occupant classification system your Hyundai dealer. in the following table and activates or • Before you replace a fuse or dis- Your vehicle is equipped with an occu- deactivates front passenger air bags...
Page 103 Features of your vehicle Condition and operation in the front passenger occupant classification system WARNING Indicator/Warning light Devices Riding in an improper position or Condition detected by placing weight on the front passen- "PASSENGER AIR the occupant classifi- Front passenger ger's seat when it is unoccupied by SRS warning light BAG OFF"...
Page 104 Features of your vehicle (Continued) OVQ036013N 1KMN3663 1KMN3665 - Never put a heavy load in the - Never sit with hips shifted - Never place feet on the dash- front passenger seat or seatback towards the front of the seat. board.
Page 105 Do not senger seat, if the "PASSENGER AIR restarted, Hyundai recommends hang onto the front passenger seat. BAG OFF" indicator is on, turn the igni- that passenger move to the rear tion key to "LOCK"...
Page 106 "ON" position, or if it illuminates upright with the seatback in an while the vehicle is being driven, upright position, centered on the have an authorized Hyundai dealer seat cushion with their seat belt inspect the occupant classification on, legs comfortably extended...
Page 107 Side impact air bag (if equipped) senses less weight than if the occupant were seated properly Your Hyundai is equipped with a side (sitting upright with the seatback impact air bag in each front seat. The purpose of the air bag is to provide the...
Page 108 Features of your vehicle (Continued) WARNING • Do not install any accessories on • The side impact air bag is supple- the side or near the side impact mental to the driver's and the pas- air bag. senger's seat belt systems and is •...
Page 109 (Continued) air bag system. This should only done authorized OVQ036093N Hyundai dealer. Curtain air bag (if equipped) Failure to follow the above men- Curtain air bags are located along both tioned instructions can result in sides of the roof rails above the front and injury or death to the vehicle occu- rear doors.
Page 110: Maintenance
Hyundai dealer. formed by a qualified Hyundai technician. and the front passenger's panel Improper handling of the SRS system above the glove box, because any may result in serious personal injury.
Page 111 Features of your vehicle Additional safety precautions • Keep occupants away from the air WARNING bag covers. All occupants should sit • Never let passengers ride in the upright, fully back in their seats with • Sitting improperly or out of posi- cargo area or on top of a folded- their seat belts on and their feet on the tion can cause occupants to be...
Page 112 Features of your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-inflation conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection. These include rear impacts, second or third collisions in multiple impact accidents, as well as low speed...
Page 113 Hyundai dealer. • If the installation location or • Your vehicle has been designed angle of the sensors is altered in to absorb impact and deploy the any way, the air bags may deploy air bag(s) in certain collisions.
Page 114 Features of your vehicle Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact.
Page 115 Features of your vehicle OUN036087 OVQ036018N 1VQA2089 • Frontal air bags are not designed to • Front air bags may not inflate in side • In a slant or angled collision, the force inflate in rear collisions, because occu- impact collisions, because occupants of impact may direct the occupants in a pants are moved backward by the move to the direction of the collision,...
Page 116 Features of your vehicle 1VQA2090 1VQA2091 1VQA2092 • Just before impact, drivers often brake • Air bags may not inflate in rollover acci- • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the dents because air bag deployment collides with objects such as utility front portion of the vehicle causing it to would not provide protection to the...
Page 117 Features of your vehicle (if equipped) OVQ039411/OVQ039020N/1VQA2096/1VQA2330 Air bag warning label Air bag warning labels required by the U.S. National Highway Traffic Safety Administration (NHTSA) are attached to alert driver and passengers of potential risks of the air bag system. 3 101...
Page 118: Steering Wheel /
When this happens, increase the engine vehicle operation, have the power steer- • If the power steering drive belt RPM by depressing accelerator until the ing checked by an Authorized Hyundai breaks or if the power steering RPM reaches 1,500 rpm then release or Dealer.
Page 119 Features of your vehicle Tilt steering WARNING A tilt steering wheel allows you to adjust • Never adjust the angle of the the steering wheel before you drive. You steering wheel while driving. You can also raise it to the highest level to may lose your steering control give your legs more room when you exit and cause an accident that may...
Page 120: Mirrors /
Features of your vehicle MIRRORS Outside rearview mirror WARNING - Rearview mir- Be sure to adjust mirror angles before rors driving. • The right outside rearview mirror Your vehicle is equipped with both left- is convex. Objects seen in the hand and right-hand outside rearview mirror are closer than they mirrors.
Page 121 Features of your vehicle Outside rearview mirror heater CAUTION (if equipped) • The mirrors stop moving when The outside rearview mirror heater is they reach the maximum adjust- actuated in connection with the rear win- ing angles, but the motor contin- dow defroster.
Page 122 Features of your vehicle Use the mirror selection switch lever to (Examples) control automatic mirror adjustment as If the shift lever is shifted into reverse (R) follows: when the outside rearview mirror selec- tion switch is in L, both the right and left : Both the left and right outside outside rearview mirrors will automatical- rearview mirrors will be turned...
Page 123 Features of your vehicle Inside rearview mirror Electric type The electric rearview mirror automatical- Adjust the rearview mirror to center on ly controls the glare from the headlights the view through the rear window. Make Day/Night lever of the car behind you in nighttime or low this adjustment before you start driving.
Page 124 Features of your vehicle 1KMA3084 OVQ036025N OVQ028107 Type A Type B (with homelink wireless Conversation mirror control system) To operate the electric rearview mirror The mirror is a convenient feature to help To operate the electric rearview mirror Press the ON/OFF button (1) to turn the the front passenger talk with rear pas- automatic- dimming function on.
Page 125: Instrument Cluster /
Features of your vehicle INSTRUMENT CLUSTER ■ ■ Type A 1. Tachometer 2. Turn signal indicators 3. Speedometer 4. Engine temperature gauge 5. Warning and indicator lights 6. Shift position indicator (Automatic transaxle only) 7. Odometer/Trip odometer ■ ■ Type B 8.
Page 126: Gauges /
Features of your vehicle GAUGES OVQ037028N OVQ039032N OVQ037035N Speedometer Odometer/Trip odometer Odometer The odometer indicates the total dis- The speedometer indicates the forward You can choose the odometer, trip tance the vehicle has been driven. speed of the vehicle. odometer A and trip odometer B by pressing the tripmeter mode button.
Page 127 Features of your vehicle OVQ037036N OVQ036030N OVQ039031N Trip odometer Tachometer Engine temperature gauge TRIP A: Trip odometer A The tachometer indicates the approxi- This gauge shows the temperature of the TRIP B: Trip odometer B mate number of engine revolutions per engine coolant when the ignition switch minute (rpm).
Page 128: Instrument Panel Illumination
Features of your vehicle WARNING - Fuel gauge Running out of fuel can expose vehicle occupants to danger. You must stop and obtain addition- al fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the E level.
Page 129: Trip Computer /
Features of your vehicle TRIP COMPUTER (IF EQUIPPED) Mode selection The compass is always displayed until the display is turned off. Push the MODE button to select distance to empty, driving time, average fuel con- sumption and outside temperature func- tions.
Page 130 Features of your vehicle ✽ ✽ NOTICE 5. Press and hold the MODE button again for 2~4.5 seconds until the “turn” Perform the calibration procedure for a appears and “DIR” blinks in the display new vehicle as follows. and release the button. 6.
Page 131 Features of your vehicle ✽ ✽ NOTICE 3. Release the MODE button and press the RESET button repeatedly until the 1. Do not install a ski rack, antenna, etc. correct terrestrial deviation angle value that is attached to the vehicle using a for your location appears in the display.
Page 132 Features of your vehicle Compass zone map...
Page 133 Features of your vehicle ✽ ✽ NOTICE • If the vehicle is not on level ground or the battery power has been interrupt- ed, the “Distance to empty” function may not operate correctly. The trip computer may not register additional fuel if less than 1.6 gallons (6 liters) of fuel are added to the vehi- cle.
Page 134 Features of your vehicle OVQ036038N OVQ036040N 1VQA2322 Average fuel consumption (“AVG” Outside temperature Unit conversion shown on display) This mode indicates the outside temper- The unit on each mode can be changed ature around the vehicle. by pushing the RESET button for more This mode calculates the average fuel than 4 seconds as follows: consumption from the total fuel used and...
Page 135: Warnings And Indicators /
If the light stays on, you may have a unexpected and dangerous situa- problem with your ABS system. Contact tion during sudden braking. In this an authorized Hyundai dealer as soon as case, avoid high speed driving and possible. abrupt braking. Have your vehicle checked by Authorized Hyundai Dealer as soon as possible.
Page 136 Have it towed to any Authorized tion or when the turn signal lever is pulled Hyundai Dealer for a brake system into the Flash-to-Pass position. inspection and necessary repairs.
Page 137 3. If the belt is adjusted properly, a prob- (if equipped) lem exists somewhere in the electrical charging system. Have an Authorized Hyundai Dealer correct the problem as This light comes on when the front fog soon as possible. lights are ON.
Page 138 Hyundai Dealer. converter damage is possible an authorized Hyundai Dealer promptly. which could result in loss of Low fuel level engine power. Have the Engine ✽ ✽ NOTICE...
Page 139 OFF indicator will illuminate indicating the ESC is deactivated. If this indicator stays on in the ESC ON mode, the ESC may have a malfunction. Take your car to the authorized Hyundai dealer and have the system checked. 3 123...
Page 140 If this happens, the system may not moni- If this occurs, have your vehicle checked makes the vehicle unstable and can by an authorized Hyundai dealer as soon tor the tire pressure. Have the system contribute to loss of vehicle control as possible.
Page 141: Interior Lights /
Features of your vehicle INTERIOR LIGHTS Main control switch Map light The lights are turned ON or OFF based on the status of the doors, main control switch and corresponding light switch. Map lights operating logic Map light switch Door open/ Main control switch status close status...
Page 142 Features of your vehicle Main control switch Dome light The lights are turned ON or OFF based on the status of the doors, main control switch and corresponding light switch. Dome lights operating logic Dome light switch Door open/ Main control switch status close status DOOR...
Page 143 Features of your vehicle Main control switch Tailgate light The lights are turned ON or OFF based on the status of the tailgate, main control switch and corresponding light switch. Tailgate light operating logic Tailgate light switch Tailgate open/ Main control close status switch status DOOR...
Page 144: Lighting /
CAUTION exiting the vehicle. It also serves as a If the rescue mode occurs, have warning to passing vehicles that the vehi- your vehicle checked by an author- cle door is open. ized Hyundai dealer as soon as possible.
Page 145 Features of your vehicle 1VQA2129 1VQA2130 1VQA2131 Lighting control Parking light position ( Headlight position ( The light switch has a Headlight and a When the light switch is in the parking When the light switch is in the headlight Parking light position.
Page 146 Features of your vehicle 1VQA2132 1VQA2134 1VQA2133 Auto light position (if equipped) High - beam operation Flashing headlights When the light switch is in the AUTO light To flash the headlights, pull the lever To turn on the high beam headlights, position, the taillights and headlights will towards you.
Page 147 Features of your vehicle Lane change signals (B) To signal a lane change, move the turn signal lever slightly and hold it in position. The lever will return to the OFF position when released. If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal bulbs may be burned out and will require replacement.
Page 148: Wiper/Washer
Features of your vehicle WIPERS AND WASHERS A : Wiper speed control Windshield wiper/washer · MIST – Single wipe Fast · OFF – Off · INT/AUTO – Intermittent wipe or AUTO control wipe · LO – Low wiper speed · HI – High wiper speed B : Intermittent or Auto control wipe time adjustment Slow...
Page 149 Features of your vehicle ✽ ✽ NOTICE If the wiper switch is set in AUTO mode when the ignition switch is ON, or the If there is heavy accumulation of snow speed control knob is turned toward the or ice on the windshield, defrost the upward position when the wiper switch is windshield for about 10 minutes, or in AUTO mode, wiper will operate once to...
Page 150 Features of your vehicle Variable intermittent wipers CAUTION Set the lever to the INT/AUTO position When the ignition switch is ON and and choose the desired wiper interval by the windshield wiper switch is turning the ring. placed in the AUTO mode, use cau- tion in the following situations to One - touch wiper avoid any injury to the hands or...
Page 151: Switch
Features of your vehicle HORN The spray and wiper operation will con- tinue until you release the lever. If the washer does not work, check the washer fluid level. If the fluid level is not sufficient, you will need to add appropri- ate non-abrasive windshield washer fluid to the washer reservoir.
Page 152: Defroster /
Features of your vehicle DEFROSTER Type A CAUTION • To prevent damage to the con- ductors bonded to the inside sur- face of the rear window, never use sharp instruments or window cleaners containing abrasives to clean the window. • If you want to defrost and defog on the front windshield, refer to “Windshield Defrosting...
Page 153: Hazard Warning Flasher Switch
Features of your vehicle HAZARD WARNING FLASHER To activate the flasher, depress the haz- Type A ard warning flasher switch. This switch operates in any ignition switch position. To turn the flashers off, depress the switch again. OVQ049031 Type B OVQ049032 The hazard warning flasher causes the front and rear turn signal lights to flash...
Page 154: Climate Control System*
Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) Type A 1. Front temperature control knob 2. Rear temperature control knob* 3. Front fan speed control knob Type B 4. Air conditioning button* 5. Rear window defroster button 6. Mode selection knob 7.
Page 155 Features of your vehicle OVQ049306 OVQ049307 OVQ049308 Front fan speed control knob Temperature control knob Mode selection knob The ignition switch must be in the ON The temperature control knob allows you The mode selection knob controls the position for fan operation. to control the temperature of the air flow- direction of the air flow through the venti- ing from the ventilation system.
Page 156 Features of your vehicle MAX/ A/C position (if equipped) When you select the MAX A/C mode while the fan speed is on, the following system settings will be made automatically; • the air conditioning system will be turned on. • the recirculated air position will be selected.
Page 157 Features of your vehicle Face position Floor - defrost position Air flow is directed toward the Most of the air flow is direct- upper body face. ed to the floor and the wind- Additionally, each outlet can shield with a small amount be controlled to direct the air directed to the side window discharged from the outlet.
Page 158 Features of your vehicle Recirculated air position Outside (fresh) air position With the recirculated air With the outside (fresh) air position selected, air from position selected, air enters passenger compartment the vehicle from outside and will be drawn through the is heated or cooled accord- heating system and heated ing to the function selected.
Page 159 Features of your vehicle ✽ ✽ NOTICE WARNING It should be noted that prolonged oper- • Continued climate control system ation of the heating in recirculated air operation in the recirculated air position will cause fogging of the wind- position may allow humidity to shield and side windows and the air increase inside vehicle which within the passenger compartment will...
Page 160: Seat
Features of your vehicle Rear climate control ■ Front (if equipped) 1. Rear fan speed control knob To turn on the rear climate control sys- (from front seat) tem; 2. Rear temperature control knob* From the front seat (from front seat) 1.
Page 161 Features of your vehicle From the rear seat (if equipped) 1. Set the rear climate control selection (REAR CONTROL) button in the front climate control panel to the ON posi- tion. 2. Set the rear fan speed control knob on the rear climate control panel to the desired position.
Page 162 Features of your vehicle with rear air conditioner OVQ028338 with rear heater OVQ049315 OVQ049316 1VQA2174 Rear temperature control From rear seat (if equipped) Rear mode selection (if equipped) (if equipped) Set the rear climate control selection When the rear climate control selection (REAR CONTROL) button in the front cli- From front seat (REAR CONTROL) button in the front cli-...
Page 163 Features of your vehicle • Front climate control is MAX A/C, Rear air blows from the upper vents on the rear ceiling. • Front climate control is Rear air blows from the upper vents on the rear ceiling and the lower vents on the right rear trim together.
Page 164 Features of your vehicle System operation Air conditioning (if equipped) CAUTION All Hyundai Air Conditioning Systems are Ventilation • When using the air conditioning filled with environmentally friendly 1. Set the mode to the position. system, monitor the temperature R-134a refrigerant which is not damag- 2.
Page 165 Hyundai dealer. Improper service cause the air inside the vehicle to windows for a short time to let the hot may cause serious injury.
Page 166: Automatic Climate Control System /
Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) Type A 1. AUTO (automatic control) button 2. Driver’s temperature control button 3. A/C display 4. Passenger’s temperature control button 5. Dual temperature control selection button 6. Front fan speed control knob 7.
Page 167 Features of your vehicle 2. Push the TEMP button to set the desired temperature. If the temperature is set to the lowest setting LO (17°C/62°F), the air condi- tioning system will operate continu- ously. 3. To turn the automatic operation off, press any button except temperature control button.
Page 168 Features of your vehicle Manual operation The heating and cooling system can be controlled manually as well by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons select- When pressing any button except AUTO button while automatic operation, the functions of the buttons not selected will be controlled automatically.
Page 169 Features of your vehicle Adjusting the driver and passenger side temperature equally 1. Press the DUAL button again to deac- tivate DUAL mode. The passenger side temperature will be set to the same as the driver side temperature. 2. Press the left temperature control but- ton.
Page 170 Features of your vehicle ✽ ✽ NOTICE Recirculated air position WARNING With the recirculated air posi- It should be noted that prolonged oper- tion selected, air from pas- • Continued climate control system ation of the heating in recirculated air senger compartment will be operation in the recirculated air position will cause fogging of the wind-...
Page 171 Features of your vehicle OVQ049327 Mode selection button The mode selection button controls the direction of the air flow through the venti- lation system. The air flow outlet port is converted as follows: 1VQA2147 Outlet port locations 3 155...
Page 172 Features of your vehicle Face position Floor position Air flow is directed toward the Most of the air flow is direct- upper body face. ed to the floor, with a small Additionally, each outlet can amount of the air being be controlled to direct the air directed to the windshield discharged from the outlet.
Page 173 Features of your vehicle 1VQA2148 OVQ049329 OVQ049330 Instrument panel vents Air conditioning button OFF button If air flow control is not satisfactory, check Push the OFF button to turn off the air cli- Push the A/C button to turn the air condi- the instrument panel vents.
Page 174 Features of your vehicle Rear climate control ■ Front To turn on the rear climate control sys- 1. Rear fan speed control knob tem; (from front seat) From the front seat 2. Rear temperature control button* 1. Set the rear climate control selection (from front seat) (REAR) button in the front climate con- 3.
Page 175 Features of your vehicle From the rear seat (if equipped) 1. Set the rear climate control selection (REAR) button in the front climate con- trol panel to the ON position. 2. Set the rear fan speed control knob on the rear climate control panel to the desired position.
Page 176 Features of your vehicle with rear air conditioner OVQ028338 with rear heater OVQ049333 OVQ049335 1VQA2174 Rear temperature control From rear seat (if equipped) Rear mode selection (if equipped) (if equipped) Set the rear climate control selection When the rear climate control selection (REAR) button in the front climate control From front seat (REAR) button in the front climate control...
Page 177 Features of your vehicle • Front climate control is Rear air blows from the upper vents on the rear ceiling. • Front climate control is Rear air blows from the upper vents on the rear ceiling and the lower vents on the right rear trim together.
Page 178 Features of your vehicle System operation Air conditioning CAUTION All Hyundai Air Conditioning Systems are Ventilation • When using the air conditioning filled with environmentally friendly 1. Set the mode to the position. system, monitor the temperature R-134a refrigerant which is not damag- 2.
Page 179 Hyundai dealer. Improper service cause the air inside the vehicle to windows for a short time to let the hot may cause serious injury.
Page 180: Windshield Defrosting And Defogging /
Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING WARNING Do not use the position during cooling operation extremely humid weather. The dif- ference between the temperature of the outside air and that of the wind- shield could cause the outer sur- face of the windshield to fog up, causing loss of visibility.
Page 181 Features of your vehicle WARNING Do not use the position during cooling operation extremely humid weather. The dif- ference between the temperature of the outside air and that of the wind- shield could cause the outer sur- face of the windshield to fog up, causing loss of visibility.
Page 182 Features of your vehicle • For maximum defrosting, set the tem- Defogging logic perature control to the extreme Manual climate control system right/hot position and the fan speed To reduce the probability of fogging up control to the highest speed. the inside of the windshield, the air intake •...
Page 183: If Equipped
(fresh) air position, press the cor- gage net. 2. Select the defrost position pressing responding button to cancel the opera- Contact your authorized Hyundai dealer defrost button ( tion. to obtain a luggage net. 3. While holding the air conditioning but-...
Page 184: Specifications
CAUTION Hyundai dealer. firmly. • If the vehicle has a sunroof, do not position the roof rack loads CAUTION ROOF 165 lbs.
Page 185: Homelink® Wireless Control System /
Features of your vehicle HOMELINK® WIRELESS CONTROL SYSTEM (IF EQUIPPED) Programming Glare detection sensor (Continued) Indicator light Your vehicle may require the ignition • Do not use HomeLink with any switch to be turned to the ACC position garage door opener that lacks the for programming and/or operation of safety stop and reverse feature as HomeLink.
Page 186 Features of your vehicle ✽ ✽ NOTICE Flashing Flashing For non rolling code garage door open- ers, follow steps 2 - 3. For rolling code garage door openers, follow steps 2 - 6. For Canadian Programming, please fol- low the Canadian Programming section. For help with determining whether your garage is non-rolling code or rolling code, please refer to the garage door...
Page 187 Features of your vehicle Rolling code programming Operating HomeLink Flashing To train a garage door opener (or other To operate, simply press the pro- rolling code equipped devices) with the grammed HomeLink button. Activation rolling code feature, follow these instruc- will now occur for the trained product tions after completing the “Programming”...
Page 188 Features of your vehicle Reprogramming a single Gate operator programming & Accessories HomeLink button canadian programming If you would like additional information on the HomeLink Wireless Control System, To program a device to HomeLink using During programming, your hand-held HomeLink compatible products, or to a HomeLink button previously trained, transmitter may automatically stop trans- purchase other accessories such as the...
Page 189: Storage Compartments /
Features of your vehicle STORAGE COMPARTMENTS WARNING Always keep the storage compart- ment covers closed while driving. Do not attempt to place so many items in the storage compartment that the storage compartment cover can not close securely. WARNING Flammable materials Do not store cigarette lighters, propane cylinders, or other flamma-...
Page 190 Features of your vehicle CAUTION Since key is not fully inserted into the glove box key set, do not apply excessive force. Doing so may dam- age the parts. WARNING To reduce the risk of injury in an accident or sudden stop, always keep the glove box door closed OVQ028191 OVQ028198...
Page 191: Interior Features /
CAUTION • Do not hold the lighter in after it is already heated because it will overheat. • Only a genuine Hyundai lighter should be used in the cigarette lighter socket. The use of plug-in accessories (shavers, hand-held vacuums, and coffee pots, for example) may damage the socket or cause electrical failure.
Page 192 Features of your vehicle Cup holder WARNING Hot liquids • Do not place uncovered cups of hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you could be burned. Such a burn to the driver could cause a loss of control of the vehicle.
Page 193 Features of your vehicle OVQ036234N OVQ037090N OVQ036308N Center (if equipped) Rear Shopping bag holder ✽ ✽ NOTICE Cups or small beverage cans may be Cups or small beverage cans may be placed in the cup holders. placed in the cup holders. Do not hang heavy bags as they may The storage can be removed and rein- damage the holder.
Page 194 Features of your vehicle CAUTION - Vanity mirror (if equipped) Close the vanity mirror cover securely and return the sunvisor to its original position after use. If the vanity mirror is not closed securely, the lamp will stay on and could result in battery discharge and pos- sible sunvisor damage.
Page 195 Features of your vehicle (1) : Can be used when the ignition Front (Type A) CAUTION switch is in ACC or ON position. • Use power outlet only when the (2), (3) : Can be used regardless of the engine is running and remove the ignition switch position.
Page 196: Digital Clock
Features of your vehicle ANTENNA • HOUR: Pressing the “H” button with your fin- ger, a pencil or similar object will advance the time displayed by one hour. • MINUTE: Pressing the “M” button with your fin- ger, a pencil or similar object will advance the time displayed by one minute.
Page 197: Audio Controls*
Features of your vehicle AUDIO REMOTE CONTROL (IF EQUIPPED) MODE Press the MODE button to select Radio, or CD (compact disc). MUTE • Pull the MUTE button to deactivate the sound. • Once again pull the MUTE button to reactivate the sound. VOL (▲/▼) 1VQA2343 OVQ028448...
Page 198: Audio System /
Features of your vehicle AUDIO SYSTEM FM reception AM reception FM radio station JBM001 JBM002 JBM003 How car audio works AM broadcasts can be received at FM broadcasts are transmitted at high frequencies and do not bend to follow the greater distances than FM broadcasts.
Page 199 In such a case, use the cellu- lar phone at a place as far as possible from the audio equipment. WARNING Hyundai recommends that you JBM004 JBM005 never use a cell phone while driv- • Fading - As your car moves away from •...
Page 200 Features of your vehicle Care of disc (if equipped) • Depending on the type of CD-R/CD- RW CDs, certain CDs may not operate • If the temperature inside the car is too normally according to manufacturing high, open the car windows for ventilation companies or making and recording before using your car audio.
Page 201 Features of your vehicle RADIO, SET UP, VOLUME CONTROL (PA710S) (IF EQUIPPED) 1. FM/AM Selection Button 2. XM Selection Button 3. CD Selection Button 4. AUX Selection Button 5. Automatic Channel Selection Button 6. Power ON/OFF & VOLUME Button 7. SCAN Selection Button 8.
Page 202 Features of your vehicle 1. FM/AM Selection Button 5. Automatic Channel Selection 8. MUTE Selection Button Button Turns to FM mode and toggles FM1 and When inputting [MUTE] button, indicate FM2 and AM when the button is pressed "AUDIO MUTE" at the some time with out- •...
Page 203 Features of your vehicle 11. TUNE/ENTER Knob Turn this button clockwise by one notch to increase frequency by 200KHz(AM: 10KHz) from current frequency. Turn this button counterclockwise by one notch to decrease frequency by 200KHz (AM:10KHz)from current frequency. Press this button while holding SETUP button to activate / inactivate the item to.
Page 204 Features of your vehicle CD (PA710S) (IF EQUIPPED) 1. CD Loading Slot 2. CD Indicator 3. CD Eject Button 4. AUX Selection Button 5. Automatic Track Selection Button 6. INFO Selection Button 7. TUNE/ENTER Knob 8. REPEAT Selection Button 9. RANDOM Selection Button 10.
Page 205 Features of your vehicle 1. CD Loading Slot 5. Automatic Track Selection 7. TUNE/ENTER Knob Button Please face printed side upward and Turn this button clockwise to display gently push in. When the ignition switch songs after current song. • Push [SEEK ] button for less than is on ACC or ON and power is off, power 0.8 second to play from the beginning...
Page 206 Features of your vehicle (Continued) (Continued) CAUTION IN USING • Depending on the condition of • If you dismount the external USB USB DEVICE the external USB device, the con- device during playback in USB • To use an external USB device, nected external USB device can mode, the external USB device can make sure the device is not...
Page 207 Features of your vehicle (Continued) • Please avoid using USB memory products which can be used as key chains or cellular phone accessories as they could cause damage to the USB jack. Please make certain only to use plug type connector products as shown below.
Page 208 Features of your vehicle USING USB (PA710S) (IF EQUIPPED) 1. AUX Selection Button 2. Track Moving Button 3. INFO Selection Button 4. Folder Moving Button 5. TUNE/ENTER Knob 6. RANDOM Playback Button 7. REPEAT Selection Button 8. SCAN Selection Button A-200EP...
Page 209 Features of your vehicle Using a USB that is connected to the 3. INFO Selection Button 6. RANDOM Playback Button multiple terminal inside the console on Displays the information of the file current- Press the button for less than 0.8 second the right hand side of the driver’s seat.
Page 210 Features of your vehicle RUNNING iPod ® (PA710S) (IF EQUIPPED) 1. iPod Selection Button 2. Track Moving Button 3. INFO Selection Button 4. MENU Selection Button 5. TUNE/ENTER Knob 6. RANDOM Playback Button 7. REPEAT Selection Button A-200EP iPod ® is a trademark of Apple Inc.
Page 211 Features of your vehicle Using an iPod when the exclusive cable 5. TUNE/ENTER Knob • Press the [SEEK ] button for less is connected to the multiple terminal When you turn the button clockwise, it than 0.8 second to move to the next inside the console on the right hand side will display the songs (category) next to track.
Page 212 Features of your vehicle ✽ ✽ NOTICE FOR USING iPod (Continued) CAUTION IN USING • When the iPod cable is connected, DEVICE iPod DEVICE the system can be switched to the • Some iPod models might not sup- • You need the power cable exclu- AUX mode even without the iPod port the communication protocol sive for an iPod in order to oper-...
Page 213 Features of your vehicle RSE(Rear Seat Entertainment System) (PA710S) (IF EQUIPPED) 1. RSE Selection Button 2. Power ON/OFF & VOLUME Button A-200EP 3 197...
Page 214 Features of your vehicle 1. RSE Selection Button Play the RSE, and "RSE" Icon is dis- played. After pressing the RSE button, you can enjoy the RSE audio through the speakers in RSE mode and "Connected" is appeared at the same time. At the state of NO RSE Icon, the RSE button is pressed and "RSE Not Ready"...
Page 215 Features of your vehicle RADIO, SET UP, VOLUME CONTROL (PA760S) (IF EQUIPPED) 1. FM/AM Selection Button 2. XM Selection Button 3. CD Selection Button 4. AUX Selection Button 5. Automatic Channel Selection Button 6. Power ON/OFF & VOLUME Button 7. SCAN Selection Button 8.
Page 216 Features of your vehicle 1. FM Selection Button 5. Automatic Channel Selection 8. MUTE Selection Button Button Turns to FM/AM mode and toggles FM1 When inputting [MUTE] button, indicate and FM2 and AM when the button is "AUDIO MUTE" at the some time with out- •...
Page 217 Features of your vehicle 11. TUNE/ENTER Knob Turn this button clockwise by one notch to increase frequency by 200kHz(AM: 10KHz) from current frequency. Turn this button counterclockwise by one notch to decrease frequency by 200kHz (AM:10KHz)from current frequency. Press this button while holding SETUP button to activate / inactivate the item to.
Page 218 Features of your vehicle CD (PA760S) (IF EQUIPPED) 1. CD Loading Slot 2. CD Indicator 3. CD Eject Button 4. CD LOAD Button 5. AUX Selection Button 6. Automatic Track Selection Button 7. INFO Selection Button 8. TUNE/ENTER Knob 9. REPEAT Selection Button 10.
Page 219 Features of your vehicle 1. CD Loading Slot 1. Press and release the [LOAD] Button. To insert multiple discs: 2. Green light on the slot will be illuminat- Please face printed side upward and ed and the lowest number of empty 1.
Page 220 Features of your vehicle When you have finished loading discs, 10. RANDOM Selection Button • Push [SEEK ] button for less than press [LOAD] button to cancel the load- Turns on/off the randomization of the play 0.8 second to play the next song. ing function or wait for 10 seconds.
Page 221 Features of your vehicle (Continued) (Continued) CAUTION IN USING • Depending on the condition of • If you dismount the external USB USB DEVICE the external USB device, the con- device during playback in USB • To use an external USB device, nected external USB device can mode, the external USB device can make sure the device is not...
Page 222 Features of your vehicle (Continued) • Please avoid using USB memory products which can be used as key chains or cellular phone accessories as they could cause damage to the USB jack. Please make certain only to use plug type connector products as shown below.
Page 223 Features of your vehicle USING USB (PA760S) (IF EQUIPPED) 1. AUX Selection Button 2. Track Moving Button 3. INFO Selection Button 4. Folder Moving Button 5. TUNE/ENTER Knob 6. RANDOM Playback Button 7. REPEAT Selection Button 8. SCAN Selection Button A-300EP 3 207...
Page 224 Features of your vehicle Using a USB that is connected to the 3. INFO Selection Button 6. RANDOM Playback Button multiple terminal inside the console on Displays the information of the file current- Press the button for less than 0.8 second the right hand side of the driver’s seat.
Page 225 Features of your vehicle RUNNING iPod (PA760S) (IF EQUIPPED) 1. iPod Selection Button 2. Track Moving Button 3. INFO Selection Button 4. MENU Selection Button 5. TUNE/ENTER Knob 6. RANDOM Playback Button 7. REPEAT Selection Button A-300EP ® iPod is a trademark of Apple Inc. 3 209...
Page 226 Features of your vehicle Using an iPod when the exclusive cable 5. TUNE/ENTER Knob • Press the [SEEK ] button for less is connected to the multiple terminal When you turn the button clockwise, it than 0.8 second to move to the next inside the console on the right hand side will display the songs (category) next to track.
Page 227 Features of your vehicle ✽ ✽ NOTICE FOR USING iPod (Continued) CAUTION IN USING • When the iPod cable is connected, DEVICE iPod DEVICE the system can be switched to the • Some iPod models might not sup- • You need the power cable exclu- AUX mode even without the iPod port the communication protocol sive for an iPod in order to oper-...
Page 228 Features of your vehicle RSE(Rear Seat Entertainment System) (PA760S) (IF EQUIPPED) 1. RSE Selection Button 2. Power ON/OFF & VOLUME Button A-300EP...
Page 229 Features of your vehicle 1. RSE Selection Button Play the RSE, and "RSE" Icon is dis- played. After pressing the RSE button, you can enjoy the RSE audio through the speakers in RSE mode and "Connected" is appeared at the same time. At the state of NO RSE Icon, the RSE button is pressed and "RSE Not Ready"...
Page 230: Rear Seat Entertainment System / Dvd Player /
Features of your vehicle REAR SEAT ENTERTAINMENT SYSTEM / DVD PLAYER (IF EQUIPPED) The Rear Seat Entertainment (RSE) Connections / Setup CAUTION System is a compact, built-in, easy-to-use The RSE system is designed to make entertainment system designed to provide Disclaimer: The RSE system is pro- your time on the road more enjoyable.
Page 231 Features of your vehicle Close To close the monitor, pull the bottom Folded edge forward and push it up until it clicks into the stow-away position. RES_CLOSED_8111 HEADPHONE8111 Open Spread RES_OPEN_8111 HEADPHONE8112 Viewing/Adjusting the Monitor Headphones To view the monitor, locate the latch on The RSE comes with two (2) sets of wire- the bottom center of the mounted unit less headphones and four (4) AAA 1.5V...
Page 232 Features of your vehicle ✽ ✽ NOTICE • Conserve the energy of your batteries by turning the headphones off when they are not in use. The on/off button is located on the left side of the head- phones. • The headphone has an automatic shutoff feature if an IR signal from the RSE units is not received after 20 seconds.
Page 233 Features of your vehicle The RSE unit has an automatic video CAUTION detection feature that will automatic switch to external device when the device is Connect only appropriate input plugged into the auxiliary jacks in the vehi- sources jacks. cle. Connecting an incorrect input may cause damage to the player and/or Once the RSE has switched to the exter-...
Page 234 The player will automatically grip the disc PLAY/PAUSE( ) button to “wake and pull it in the rest of the way. The player up” the unit and resume disc play. will display “reading” on the screen and show the “Hyundai Motors” logo before beginning the DVD.
Page 235 Features of your vehicle VIDEO MODE OPERATION (IF EQUIPPED) 1. STOP/EJECT 2. SPEAKER VOLUME CONTROL 3. PLAY/PAUSE 4. DISPLAY 5. FORWARD 6. REVERSE 7. NEXT CHAPTER 8. PREVIOUS CHAPTER 9. ENTER 10. MENU 11. SOURCE RES_OPEN_8111 3 219...
Page 236 Features of your vehicle ✽ ✽ NOTICE 4. Display 2. Speaker Volume Control The RSE will enter standby mode when When the player is in DVD mode, press You can adjust the volume one of two the vehicle ignition is turned off and the DISP button to view the DVD title, ways.
Page 237 Features of your vehicle You have two options: 4:3 (normal) and 6. Reverse 8. Previous Chapter 16:9 (widescreen). Press the display but- There are three DVD and VCD fast Press the PREV button to skip to the ton to select the preferred aspect ratio. reverse speeds.
Page 238 Features of your vehicle When viewing a menu, pressing the Pressing the SRC button will switch Using the CD Player MENU button again will automatically between the following RSE states: The RSE will play audio CDs in both the return to the movie at the point it was standard (12 cm) and mini-disc (8 cm) Playback state - will play DVDs, VCDs, and being viewed.You can also select “play”...
Page 239 Features of your vehicle AUDIO MODE OPERATION (IF EQUIPPED) 1. STOP/EJECT 2. VOLUME CONTROL 3. PLAY/PAUSE 4. DISPLAY 5. FORWARD 6. REVERSE 7. NEXT TRACK 8. PREVIOUS TRACK RES_CLOSED_8111 3 223...
Page 240 When an audio CD is inserted, the RSE When the player is in DVD mode, press STOP/EJECT( ) button to stop disc will display the HYUNDAI logo, then the DISP button to view the DVD title, play. automatically begin playing the first track.
Page 241 Features of your vehicle 5. Forward 7. Next Track There are two CD fast forward speeds. Press the NEXT button to skip to the Press and hold the FWD button for up to beginning of the next track. The next 2 seconds and the player will fast forward track number is displayed on the screen.
Page 242 Features of your vehicle REMOTE CONTROL 1. STOP 2. SPEAKER VOL (+, -) 3. PLAY/PAUSE 4. DISPLAY 5. FORWARD 6. REVERSE 7. NEXT 8. PREVIOUS 9. ENTER 10. MENU 11. SOURCE 12. ANGLE 13. SUBSCRIPT 14. LANGUAGE 15. SLOW PLAY 16.
Page 243 When an audio CD(VCD/DVD) is insert- In addition to having all the buttons and and “Night Time” brightness which has ed, the RSE will display the HYUNDAI functionality listed in the DVD and CD 70% level of “Day Time” brightness. Adjust...
Page 244 Features of your vehicle 5. Forward 7. Next 9. Enter There are three DVD and VCD fast for- While a DVD is playing, press the NEXT A momentary press shall initiate a select ward speeds. Press and hold the FWD button to skip to the next chapter.
Page 245 Features of your vehicle ✽ ✽ NOTICE When an external source is selected, the 12. Angle RSE’s internal DVD player turns off. Some DVDs offer different scene angles. You must repeatedly push any button to Press the SRC button to switch back If available on the DVD, the ANGLE but- move through several items.
Page 246 Features of your vehicle 15. Slow Play From the remote control for DVD, you can immediately switch to 1/8 forward or There are 3 slow forward and 3 slow backward speed with the ( ) but- reverse speeds available when viewing tons.
Page 247 Features of your vehicle Appendix Messages NON PLAYABLE MEDIA An incompatible format disc is inserted, or the disc is not playable. [INVALID ICON] Invalid button press: The PREV button was pressed during the first chapter of a DVD, or the NEXT button was pressed during the last chapter of a DVD.
Page 248 [Device requires one (1) CR2025 battery.] Use the control buttons on the RSE dis- play panel. If the remote control still does not work, contact your authorized Hyundai dealer. Continue receiving an invalid Invalid button press. The function you are trying to perform is not available.
Page 249 Engine exhaust can be dangerous! / 4-2 Before driving / 4-3 Key positions / 4-5 Starting the engine / 4-6 Automatic transaxle / 4-7 Cruise control system / 4-14 Brake system / 4-17 Electronic stability control (ESC) / 4-22 Driving your vehicle Rear parking assist system / 4-25 Good braking practices / 4-28 Economical operation / 4-29...
Page 250 Hyundai dealer. • Do not run the engine in an enclosed area.
Page 251: Before Driving
Driving your vehicle BEFORE DRIVING Before entering vehicle: Before starting PROPOSITION 65 WARN- • Be sure that all windows, outside mir- • Close and lock all doors. ror(s), and outside lights are clean. • Position the seat so that all controls are Engine exhaust and a wide variety •...
Page 252 Driving your vehicle WARNING WARNING - Driving under the influence of alcohol or All passengers must be properly drugs belted whenever the vehicle is mov- ing. Refer to pages: 3-59 through 3- Drinking and driving is dangerous. 70 for more information on their Drunk driving is the number one proper use.
Page 253: Ignition Switch
Driving your vehicle KEY POSITIONS The warning lights can be checked before the engine is started. This is the normal running position after the engine is started. Do not leave the ignition switch ON if the engine is not running to prevent battery discharge.
Page 254: Starting The Engine
Driving your vehicle STARTING THE ENGINE CAUTION WARNING - WARNING Ignition key If the engine stalls while you are in • Never turn the ignition switch to Always wear appropriate shoes motion, do not attempt to move the LOCK or ACC while the vehicle is when operating your...
Page 255: Shift Lever
Driving your vehicle AUTOMATIC TRANSAXLE Lock release button prevents shift lever movement without first depressing the button. + (UP) - (DOWN) Automatic mode Sports mode Depress the brake pedal and push the button when shifting. The lock release button must be depressed while moving the shift lever. The shift lever can be moved without depressing the lock release button.
Page 256 Driving your vehicle For smooth operation, depress the brake CAUTION pedal when shifting from N (Neutral) to a forward or reverse gear. • To avoid damage your transaxle, do not accelerate the engine in R (Reverse) or any for- WARNING - Automatic ward gear position with the transaxle...
Page 257 Driving your vehicle Transaxle ranges R (reverse) (Continued) Use this position to drive the vehicle P (park) • Before leaving the driver’s seat, backward. Always come to a complete stop before always make sure the shift lever shifting into P (Park). This position locks is in the P (PARK) position.
Page 258 Driving your vehicle ✽ ✽ NOTICE N (neutral) The wheels and transaxle are not locked. • In sports mode, the driver must exe- The vehicle will roll freely even on the cute upshifts in accordance with road slightest incline unless the parking brake conditions, taking care to keep the or service brakes are applied.
Page 259 Driving your vehicle Moving up a steep grade from a Good driving practices • Optimum vehicle performance and economy is obtained by smoothly standing start • Never move the gear selector lever depressing and releasing the accelera- from "P" or "N" to any other position To move up a steep grade from a stand- tor pedal.
Page 260 Driving your vehicle Shift lock system CAUTION For your safety, the automatic transaxle If your vehicle becomes stuck in has a shift lock system which prevents snow, mud, sand, etc., then you may shifting the transaxle out of P (Park) attempt to rock the vehicle free by unless the brake pedal is depressed.
Page 261 1VQA3028 2. Insert a screwdriver into the access 3. Depress the lock release button and hole and press down on the screwdriv- move the shift lever. 4. Have your vehicle inspected by an authorized Hyundai dealership imme- diately. 4 13...
Page 262 Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) The cruise control system allows you to program the vehicle to maintain a con- stant speed without resting your foot on the accelerator pedal. This system is designed to function above approximately 24 mph (40 km/h). WARNING - Cruise control...
Page 263 Driving your vehicle To turn cruise control off, do one of the following: • Pull the CRUISE ON-OFF button (the CRUISE indicator light in the instru- ment cluster will go OFF). • Turn the ignition off. Both of these actions cancel cruise con- trol operation.
Page 264 Driving your vehicle To temporarily accelerate with the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
Page 265: Brake System
Driving your vehicle BRAKE SYSTEM Power brakes In the event of brake failure (Continued) Your vehicle has power-assisted brakes If service brakes fail to operate while the • When descending a long or steep that adjust automatically through normal vehicle is in motion, you can make an hill, shift to a lower gear and usage.
Page 266 Driving your vehicle Disc brakes wear indicator WARNING - Brake wear Your vehicle has disc brakes. This brake wear warning sound When your brake pads are worn and new means your vehicle needs service. pads are required, you will hear a high- If you ignore this audible warning, pitched warning sound from your front you will eventually lose braking per-...
Page 267 Whenever leaving vehicle or park- way, have the system checked by an ized Hyundai dealer. ing always set the parking brake as authorized Hyundai dealer. far as possible and fully engage the vehicle's transaxle into the park position.
Page 268 Driving your vehicle Check the brake warning light by turning the ignition switch ON (do not start the engine). This light will be illuminated when the (Continued) The safety features of an ABS (ESC) WARNING - ABS equipped vehicle should not be tested by high speed driving or cor- ABS (ESC) will not prevent acci- nering.
Page 269 ABS is malfunctioning. light stays on, you may have a • Do not pump your brakes! problem with your ABS. Contact • Have the battery recharged before an authorized Hyundai dealer as driving the vehicle. soon as possible. 4 21...
Page 270 Driving your vehicle ELECTRONIC STABILITY CONTROL (ESC) (IF EQUIPPED) The Electronic Stability Control (ESC) ESC operation system is designed to stabilize the vehicle ESC ON condition during cornering manuevers. ESC checks • When the ignition is turned where you are steering and where the ON, ESC and ESC OFF indi- vehicle is actually going.
Page 271 Driving your vehicle ESC operation off ■ ESC indicator light (blinks) When operating ESC OFF state When the ESC is in operation, • To cancel ESC operation, ESC indicator light blinks. press the ESC OFF button (ESC OFF indicator light illu- •...
Page 272 Driving your vehicle ✽ ✽ NOTICE CAUTION ESC OFF usage • When operating the vehicle on a Driving with varying tire or wheel dynamometer, ensure that the ESC is When driving sizes may cause the ESC system to turned off (ESC OFF light illuminat- •...
Page 273 Driving your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) Operation of the rear parking WARNING assist system The rear parking assist system is a Operating condition supplementary function only. The • This system will activate when backing operation of the Rear Parking up with the ignition key ON.
Page 274 Driving your vehicle Non-operational conditions of The detecting range may decrease CAUTION when: rear parking assist system 1. The rear parking assist system 1. The sensor is stained with foreign mat- The rear parking assist system may may not sound sequentially ter such as snow or water.
Page 275 “R” posi- function. Always drive safely and tion, this may indicate a malfunction in cautiously. the rear parking assist system. If this occurs, have your vehicle checked by an authorized Hyundai dealer as soon as possible. 4 27...
Page 276: Good Braking Practices
Hyundai dealer for assistance. front wheels into the curb to help keep position. Vehicles not fully engaged the car from rolling.
Page 277: Economical Operation
Therefore, have an authorized engine is running smoothly, begin driv- pads. Driving in such a way will also Hyundai dealer perform scheduled ing. Remember, engine warm-up may save fuel because extra fuel is required inspections and maintenance.
Page 278: Special Driving Conditions
Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions CAUTION WARNING - Downshifting When hazardous driving conditions are Prolonged rocking may cause Downshifting with an automatic encountered such as water, snow, ice, engine over-heating, transaxle dam- transaxle, while driving on slippery mud, sand, or similar hazards, follow age or failure, and tire damage.
Page 279 Driving your vehicle Driving at night Driving in the rain Driving in flooded areas Because night driving presents more Rain and wet roads can make driving Avoid driving through flooded areas hazards than driving in the daylight, here dangerous, especially if you’re not pre- unless you are sure the water is no high- are some important tips to remember: pared for the slick pavement.
Page 280: Winter Driving
• We recommend that you carry emer- Snow tires gency equipment, including tire chains, If you mount snow tires on your Hyundai, a window scraper, windshield de-icer, make sure they are radial tires of the a bag of sand or salt, flares, a small same size and load range as the original shovel and jumper cables.
Page 281 Driving your vehicle Chain installation CAUTION WARNING - Tire chains When installing chains, follow the manu- • Make sure the snow chains are facturer's instructions and mount them as • The use of chains may adversely the correct size and type for your tightly as you can.
Page 282: Trailer Towing
Driving your vehicle TRAILER TOWING This section contains many time-tested, CAUTION WARNING - Towing a trail- important trailering tips and safety rules. Pulling a trailer improperly can Many of these are important for your damage your vehicle and result in safety and that of your passengers.
Page 283 Driving your vehicle Hitches Safety chains Trailer brakes It's important to have the correct hitch should always attach chains If your trailer weighs more than the max- equipment. Crosswinds, large trucks between your vehicle and your trailer. imum trailer weight without trailer brakes going by, and rough roads are a few rea- Cross the safety chains under the tongue loaded, then it needs its own brakes and...
Page 284 Your Authorized Hyundai Dealer can assist you in installing the wiring harness. Making turns When you’re turning with a trailer, make WARNING wider turns than normal. Do this so your Failure to use an approved trailer trailer won’t strike soft shoulders, curbs,...
Page 285 Driving your vehicle Driving on grades Parking on hills CAUTION Reduce speed and shift to a lower gear Generally, you should not park your vehi- • When towing a trailer on steep before you start down a long or steep cle, with a trailer attached, on a hill.
Page 286: Index
Driving your vehicle Maintenance when trailer towing CAUTION WARNING - Parking brake Your vehicle will need service more often • Due to higher load during trailer It can be dangerous to get out of when you regularly pull a trailer. usage, overheating might occur your vehicle if the parking brake is Important items to pay particular atten-...
Page 287 • When towing a trailer, be sure to con- C190E01JM includes the curb weight of the vehicle, sult your Hyundai dealer for further any cargo you may carry in it, and the Weight of the trailer information on additional requirements people who will be riding in the vehicle.
Page 288 Driving your vehicle (Continued) • Never exceed maximum weight limits of the trailer or trail- er towing equipment. Improper loading can result in damage to your vehicle and/or personal injury. Check weights and loading at a commercial scale or highway patrol office equipped...
Page 289 Driving your vehilcle VEHICLE LOAD LIMIT Vehicle capacity weight: Towing capacity: 1157 lbs (525 kg) Without trailer brakes: 1000 lbs (453 kg) Vehicle capacity weight is the maxi- 1157 1157 mum combined weight of occupants With trailer brakes: and cargo. If your vehicle is equipped 3500 lbs (1587 kg) 235/60R17 240 kPa, 35 psi...
Page 290 Driving your vehicle Steps for determining correct 5. Determine the combined weight of Example 1 load limit luggage and cargo being loaded on the vehicle. That weight may 1. Locate the statement "The com- not safely exceed the available bined weight of occupants and cargo and luggage load capacity cargo should never exceed XXX calculated in Step 4.
Page 291 Driving your vehilcle Example 2 Example 3 C190F02JM C190F03JM OEP046001 Compliance label Item Description Total Item Description Total The compliance label is located on Vehicle Capacity 1400 lbs Vehicle Capacity 1400 lbs the driver's door sill. Weight (635 kg) Weight (635 kg) This label shows the maximum Subtract Occupant...
Page 292 Driving your vehicle To find out the actual loads on your (Continued) WARNING front and rear axles, you need to go • Do not load your vehicle any to a weigh station and weigh your • Overloading your vehicle can heavier than the GVWR, either vehicle.Your dealer can help you with cause heat buildup in your...
Page 293 Driving your vehilcle CAUTION WARNING - Loose cargo • Overloading your vehicle may Items you carry inside your cause damage. Repairs would vehicle can strike and injure not be covered by your war- occupants in a sudden stop or ranty. Do not overload your turn, or in a crash.
Page 294 Driving your vehicle WEIGHT OF THE VEHICLE This section will guide you in the GAW (Gross axle weight) proper loading of your vehicle and/or This is the total weight placed on trailer, to keep your loaded vehicle each axle (front and rear) - including weight within its design rating capa- vehicle curb weight and all payload.
Page 295 Road warning / 5-2 In case of an emergency while driving / 5-2 If the engine will not start / 5-3 Emergency starting / 5-4 If the engine overheats / 5-6 Tire pressure monitoring system (TPMS) / 5-7 If you have a flat tire / 5-12 Towing / 5-21 What to do in an emergency...
Page 296: Road Warning
What to do in an emergency ROAD WARNING IN CASE OF AN EMERGENCY WHILE DRIVING It should be used whenever emergency Type A repairs are being made or when the vehi- If the engine stalls at a crossroad cle is stopped near the edge of a road- or crossing way.
Page 297 4. If the engine still does not start, call a If engine doesn't turn over or Hyundai dealer or seek other qualified assistance. turns over slowly 1. If your car has an automatic transaxle, If engine stalls while driving be sure the gear selector lever is in "N"...
Page 298: Emergency Starting
What to do in an emergency EMERGENCY STARTING Jump starting WARNING - Battery Jump starting can be dangerous if done Never attempt to check the elec- incorrectly. Therefore, to avoid harm to trolyte level of the battery as this yourself or damage to your vehicle or may cause the battery to rupture or battery, follow the jump starting proce- explode causing serious injury.
Page 299: What To Do In An Emergency
What to do in an emergency Connecting jumper cables Jump starting procedure 1. Make sure the booster battery is 12- volt and that its negative terminal is Connect cables in numerical order and disconnect in reverse order. grounded. 2. If the booster battery is in another vehicle, do not allow the vehicles to Jumper Cables touch.
Page 300: If The Engine Overheats
Authorized Hyundai Dealer. If coolant is not boiling out, allow the cle checked by an Authorized Hyundai engine to idle and open the hood to Dealer. permit the engine to cool gradually.
Page 301 What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) As an added safety feature, your Your vehicle has also been equipped Type A vehicle has been equipped with a tire with a TPMS malfunction indicator to pressure monitoring system (TPMS) indicate when the system is not that illuminates a low tire pressure operating properly.
Page 302 TPMS is malfunction- your car to your nearest authorized ately reduce your speed, avoid hard ing because the decreased tem- HYUNDAI dealer and have the sys- cornering and anticipate increased perature leads to a proportional tem checked. lowering of tire pressure.
Page 303 TPMS malfunction indicator. System (TPMS). Have the system checked by an • The TPMS malfunction indica- authorized HYUNDAI dealer as soon tor may be illuminated if some as possible to determine the cause electronic devices, such as of the problem.
Page 304 Have the flat tire repaired by an 20 minutes of continuous driving authorized HYUNDAI dealer as soon A cold tire means the vehicle has because the compact spare tire does as possible or replace the flat tire been sitting for 3 hours and driven for not have a sensor.
Page 305 What to do in an emergency This device complies with Part 15 WARNING WARNING TPMS Protecting of the FCC rules. TPMS • The TPMS cannot alert you to Operation is subject to the following severe and sudden tire dam- Tampering with, modifying, or two conditions: age caused by external fac- disabling the Tire Pressure...
Page 306 What to do in an emergency IF YOU HAVE A FLAT TIRE 1VQA4035 OVQ056003N OVQ056004N Removing the spare tire 3. Use the wheel lug nut wrench to loosen the bolt enough to lower Your spare tire is stored underneath the spare tire. your vehicle, directly below the right sliding door (or the cargo area).
Page 307 What to do in an emergency WARNING Ensure the spare tire retainer is properly aligned with the center of the spare tire to prevent the spare tire “rattling”. Otherwise, it may cause the spare tire to fall off the carrier and lead to an accident. OVQ056005N OVQ056006N 4.
Page 308 What to do in an emergency Important - use of compact When using a compact spare tire, WARNING spare tire observe the following precautions: This spare tire should be used • Under no circumstances should Your vehicle is equipped with a com- only for VERY short distances.
Page 309 What to do in an emergency • Do not take this vehicle through an Follow jacking instructions to reduce automatic car wash while the com- the possibility of personal injury. pact spare tire is installed. • Do not use tire chains on the com- WARNING - Changing pact spare tire.
Page 310 What to do in an emergency (Continued) • The vehicle can easily roll off jack causing serious injury or death. No person should place any portion of their body under a vehicle that is supported only by a jack; use vehicle support stands. •...
Page 311 What to do in an emergency WARNING - Changing a tire • To prevent vehicle movement while changing a tire, always set the parking brake fully, and always block the wheel diago- nally opposite the wheel being changed. • We recommend that wheels of the vehicle be...
Page 312 9. Remove the wheel lug nuts by station. The specified tightening Authorized Hyundai Dealer. turning them counterclockwise, torque is 65-79 lb•ft (9~11 kg•m, then remove the wheel. 88-107 N•m). Improperly tight- ened wheel lug nuts could cause 10.
Page 313 What to do in an emergency Carrying a flat tire WARNING - Wheel studs Do not store the flat tire on the com- If the studs are damaged, they pact spare tire carrier underneath may lose their ability to retain your vehicle.
Page 314 What to do in an emergency OVQ056011N OVQ056013N OVQ059300A 4. Tighten the strap firmly pulling the strap out of the buckle. 5. Make sure the flat tire is properly secured by trying to move it. WARNING - Flat tire Never leave the flat tire unsecured in the vehicle to prevent the tire OVQ056012N OVQ056014N...
Page 315 It is acceptable to tow the vehicle with the recommend having it done by an author- rear wheels on the ground (without dol- ized Hyundai dealer or a commercial lies) and the front wheels off the ground. tow-truck service. Proper lifting and tow-...
Page 316 Towing with a vehicle other than a tow truck If towing is necessary, we recommend you to have it done by an Authorized Hyundai dealer or a commercial tow truck service. If towing service is not available in an emergency, your vehicle may be tem-...
Page 317 • If the disabled vehicle is unable to be moved, do not forcibly contin- towing. Contact • Before emergency towing, check that Authorized Hyundai dealer or a the hook is not broken or damaged. commercial tow truck service for • Fasten the towing cable or chain assistance.
Page 318 What to do in an emergency Tips for towing a stuck vehicle The following methods are effective when your vehicle is stuck in mud, sand or similar substances that prevent the vehicle from being driven out under its own power. •...
Page 319 Maintenance services / 6-2 Scheduled maintenance service / 6-2 Explanation of scheduled maintenance items / 6-7 Owner maintenance / 6-9 Engine compartment / 6-11 Engine oil / 6-12 Engine coolant / 6-13 Air cleaner / 6-15 Automatic transaxle / 6-17 Brakes / 6-19 Lubricants and fluids / 6-20 Power steering / 6-21...
Page 320: Scheduled Maintenance Service
Maintenance. Hyundai's high service quality standards After 120 months or 150,000 miles and receives technical support from (240,000 km) continue to follow the pre- Hyundai in order to provide you with a scribed maintenance intervals. high level of service satisfaction.
Page 321: Normal Maintenance Schedule
Maintenance NORMAL MAINTENANCE SCHEDULE The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the frequency of service is deter- mined by whichever occurs first.
Page 322 Maintenance R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MILES X 1000 22.5 37.5 52.5 67.5 82.5 97.5 105 112.5 120 127.5 135 142.5 150 DESCRIPTION KILOMETERS X 1000 108 120 132 144 156 168 180 192 204 216 228 240 MONTHS 102 108...
Page 323 Maintenance R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MILES X 1000 22.5 37.5 52.5 67.5 82.5 97.5 105 112.5 120 127.5 135 142.5 150 DESCRIPTION KILOMETERS X 1000 108 120 132 144 156 168 180 192 204 216 228 240 MONTHS 102 108...
Page 324: Maintenance Under Severe Usage Conditions
Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE DRIVING...
Page 325: Explanation Of Scheduled Maintenance Items
Fuel filter Air cleaner filter Vacuum, crankcase ventilation hoses A clogged filter can limit the speed at A Genuine Hyundai air cleaner filter is which the vehicle may be driven, damage recommended when filter Inspect the surface of hoses for evidence the emission system and cause hard replaced.
Page 326 MOND ATF SP-III, SK ATF SP-III or other brands meeting the SP III specification Power steering pump, belt and Brake pads, calipers and rotors approved by Hyundai Motor Co. when hoses Check the pads for excessive wear, discs adding or changing fluid. Using the...
Page 327: Owner Maintenance
• Check the operation of all exterior the owner or an Authorized Hyundai • Check for vibrations in the steering lights, including the stoplights, turn sig- Dealer at the frequencies indicated to wheel.
Page 328 • Lubricate door rubber weatherstrips. cedures. If you lack sufficient Authorized Hyundai Dealer with special • Check the air conditioning system knowledge and experience or the tools. before the warm weather season.
Page 329: Engine Compartment
Maintenance ENGINE COMPARTMENT 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake fluid reservoir 4. Air cleaner 5. Fuse box 6. Negative battery terminal 7. Positive battery terminal 8. Auto transaxle oil dipstick 9. Radiator cap 10. Engine oil dipstick 11.
Page 330: Engine Oil
Have engine oil and filter changed by an WARNING - Radiator hose washing your hands thoroughly Authorized Hyundai Dealer according to Be very careful not to touch the with soap and warm water as soon the Maintenance Schedule at the begin- radiator hose when checking or as possible after handling used oil.
Page 331: Engine Coolant
Maintenance ENGINE COOLANT The high-pressure cooling system has a (Continued) reservoir filled with year-round antifreeze • Turn the engine off and wait until coolant. The reservoir is filled at the fac- it cools down. Use extreme care tory. when removing the radiator cap. Check the antifreeze protection and Wrap a thick towel around it, and coolant level at least once a year, at the...
Page 332 For mixture percentage, refer to the fol- ing serious injury. level to F, but do not overfill. If frequent lowing table. additions are required, see an Authorized Hyundai Dealer for a cooling system Mixture Percentage (volume) inspection. Ambient Temperature Coolant...
Page 333: Air Cleaner
Maintenance AIR CLEANER OVQ066005N OVQ066006N OVQ066007N Element replacement 1. Loosen the air cleaner cover attaching 2. Wipe the inside of the air cleaner clips and open the cover. housing with a clean, damp cloth. A viscous paper air cleaner filter is used. It must be replaced when necessary, and should not be cleaned and reused.
Page 334 OVQ066008N cause a fire in the engine compart- ment. 3. Replace the air cleaner element. We recommend that the air cleaner ele- ment be replaced with genuine Hyundai parts. 4. Lock the cover with the cover attaching clips.
Page 335 Maintenance AUTOMATIC TRANSAXLE WARNING - Transaxle fluid The transaxle fluid level should be checked when the engine is at nor- mal operating temperature. This means that the engine, radiator, radiator hose and exhaust system etc., are very hot. Exercise great care not to burn yourself during this COLD procedure.
Page 336 WARNING - Parking brake ✽ ✽ NOTICE To avoid sudden movement of the Have an Authorized Hyundai dealer vehicle, apply parking brake and change the automatic transaxle fluid depress the brake pedal before according Scheduled moving the shift lever.
Page 337 1VQA5020 an Authorized Hyundai Dealer. parts. Checking brake fluid level Check the fluid level in the reservoir peri- odically. The fluid level should be...
Page 338: Lubricants And Fluids
Maintenance LUBRICANTS AND FLUIDS Body lubrication WARNING - Coolant All moving points of the body, such as • Do not use radiator coolant or door hinges, hood hinges, and locks, antifreeze in the washer fluid should be lubricated each time the reservoir.
Page 339: Power Steering
Check the connections for oil leaks, vehicle should be inspected by an severe damage and twists in the power Authorized Hyundai Dealer. steering hose before driving. CAUTION • To avoid damage to the power...
Page 340 (fresh) air position is selected. If this hap- pens, have the climate control air filter replaced by an Authorized Hyundai Dealer.
Page 341 Maintenance 1VQA5015 OVQ066014N OVQ066015N 2. With the glove box open, remove the 3. Remove the climate control air filter 4. Replace the climate control air filter. stoppers on both sides to allow the cover pulling up both taps of the cover. 5.
Page 342: Wiper Blades
Maintenance WIPER BLADES Contamination of either the windshield or Replacement the wiper blades with foreign matter can When the wipers no longer clean ade- reduce the effectiveness of the wind- quately, the blades may be worn or shield wipers. Common sources of con- cracked, and require replacement.
Page 343 Maintenance Rear window wiper blade To prevent damage to the wiper arms or other components, have an authorized Hyundai dealer replace the wiper blade. 1LDA5024 1LDA5023 Front windshield wiper blade 1. Raise the wiper arm and turn the wiper blade assembly to expose the plastic locking clip.
Page 344 Blown cates an electrical problem. Avoid using the system involved and immediately Fusible link consult an Authorized Hyundai Dealer. Three kinds of fuses are used: blade type CAUTION for lower amperage rating and cartridge Do not use a screwdriver or any...
Page 345 4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an Authorized OVQ066016N Hyundai Dealer. Inner panel 1. Turn the ignition switch and all other switches off.
Page 346 If you do not have a spare, use a fuse of If the main fuse is blown, consult an the same rating from a circuit you may Authorized Hyundai Dealer. not need for operating the vehicle, such as the cigar lighter fuse.
Page 347 Maintenance ✽ ✽ NOTICE Fuse/Relay panel description Not all fuse panel descriptions in this Inside the fuse/relay box covers, you can find the fuse/relay label describing fuse/relay manual may be applicable to your vehi- name and capacity. cle. It is accurate at the time of printing. Driver’s side panel When you inspect the fuse box on your Engine compartment...
Page 348 Maintenance Driver's side fuse panel Description Fuse rating Protected component AUDIO Audio, Step lamp MEMORY 7.5A Climate control module, Clock, Cluster, Trip computer, Front area module, Power sliding door module, Power tailgate module, Driver's door module, Front passenger door module, Driver's power seat module, Driver position memory system unit IG2-1 7.5A...
Page 349 Maintenance Description Fuse rating Protected component 7.5A Automatic shift lever switch, Vehicle speed sensor, Inhibitor switch, Transaxle control module, Input speed sensor, Output speed sensor, Back-up lamp switch, Fuel filter 7.5A Trip computer, Buzzer(Back warning system), Cluster, ESC switch, Ambient temperature sensor, Generator 7.5A ABS control module, ESC control module, Yaw rate sensor, Steering angle sensor AIRBAG...
Page 350 Maintenance Engine compartment Description Fuse rating Protected component Description Fuse rating Protected component FRT/RR WASHER Front washer motor relay, P/TRAIN 7.5A Theft alarm relay, Main relay, Rear washer motor relay TCM, Generator, ECM, Injector IG 2 7.5A Fuel filter 15A, ECU 2 15A, ECU 1 10A, STOP LAMP Stop lamp, Air conditioner compressor relay,...
Page 351 Maintenance Description Fuse rating Protected component IPM 1 Instrument panel module IPM 2 Instrument panel module IPM 3 Instrument panel module FRT BLOWER Inside relay box(Front blower relay) RR BLOWER Inside relay box(Rear blower relay) IG 2 RELAY Ignition relay A/C COMP RELAY Air conditioner compressor relay MAIN RELAY...
Page 352 Maintenance ✽ ✽ NOTICE • If the shunt connector is pulled up Shunt connector from the fuse panel, the warning chime, audio, clock and interior lamps, etc., will not operate. Some items must be reset after replacement. (Refer to “Items to be reset···.” on page 6-36) •...
Page 353 Maintenance BATTERY (Continued) (Continued) • When lifting a plastic-cased bat- Keep batteries out of the tery, excessive pressure on the reach of children because case may cause battery acid to batteries contain highly leak, resulting in personal injury. corrosive SULFURIC ACID. Lift with a battery carrier or with Do not allow battery acid to your hands on opposite corners.
Page 354 Maintenance For best battery service: Items to be reset after the battery (Continued) has been discharged or the bat- • Keep the battery securely mounted. • Wear eye protection when check- tery has been disconnected. • Keep the battery top clean and dry. ing the battery during charging.
Page 355 Maintenance TIRES AND WHEELS Tire care WARNING For proper maintenance, safety, and • Underinflated or overinflated maximum fuel economy, you must tires can cause poor handling, always maintain recommended tire loss of vehicle control, and inflation pressures and stay within sudden tire failure leading to the load limits and weight distribution accidents, injuries, and even...
Page 356 • Be sure to reinstall the tire Authorized Hyundai Dealer. inflation valve caps. Without • Overinflation produces the valve cap, dirt or moisture 1KMN5039 harsh ride, excessive wear at...
Page 357 Maintenance Checking tire inflation pres- Remove the valve cap from the tire CAUTION - Tire pressure sure valve stem. Press the tire gage firm- Always observe the following: ly onto the valve to get a pressure Check your tires once a month or measurement.
Page 358 Refer to Section 8, Specifications. are damaged. • Remember to check the pres- sure your spare tire. Hyundai recommends that you check the spare every time you check the pressure of the other tires on your vehi- CBGQ0707A cle.
Page 359 Maintenance Disc brake pads should be inspected Tread wear indicator WARNING for wear whenever tires are rotated. • Driving on tires with no or Rotate radial tires that have an insufficient tread is danger- asymmetric tread pattern only ous. Worn-out tires can result from front to rear and not from in loss of vehicle control, col- right to left.
Page 360 However, if you notice unusual tire A wheel that is not the correct new Hyundai and should be mount- wear or your vehicle pulling one way size may adversely affect wheel ed on the same compact spare tire...
Page 361 • Replace tires that are worn, • Wheels that do not meet show uneven wear, or are Hyundai's specifications may damaged. Worn tires fit poorly and result in damage cause loss of braking effec- to the vehicle or unusual han- tiveness, steering control, and dling and poor vehicle control.
Page 362 Maintenance Tire traction 2. Tire size designation A tire’s sidewall is marked with a tire Tire traction can be reduced if you size designation. You will need this drive on worn tires, tires that are information when selecting replace- improperly inflated or on slippery ment tires for your car.
Page 363 Maintenance 86 - Load Index, a numerical code Tire speed ratings 3. Checking tire life (TIN : Tire associated with the maximum Identification Number) The chart below lists many of the dif- load the tire can carry. ferent speed ratings currently being Any tires that are over 6 years, based H - Speed Rating Symbol.
Page 364 4. Tire ply composition and mate- The tires available as standard or rial optional equipment on Hyundai vehi- The number of layers or plies of rub- 7. Uniform tire quality grading cles may vary with respect to grade. ber-coated fabric are in the tire. Tire...
Page 365 Maintenance Traction - AA, A, B & C Tire terminology and defini- WARNING - Tire tions The traction grades, from highest to temperature lowest, are AA, A, B and C. The Air Pressure: The amount of air grades represent the tires ability to The temperature grade for this inside the tire pressing outward on stop on wet pavement as measured...
Page 366 Maintenance Cold Tire Pressure: The amount of Intended Outboard Sidewall: The Occupant Distribution: Designated air pressure in a tire, measured in side of an asymmetrical tire, that seating positions. pounds per square inch (psi) or kilo- must always face outward when Outward Facing Sidewall: The side pascals (kPa) before a tire has built mounted on a vehicle.
Page 367 All season tires code assigned to a tire indicating the Tire: Load on an individual tire due to Hyundai specifies all season tires on maximum speed at which a tire can curb and accessory weight plus some models to provide good per- operate.
Page 368 Maintenance Snow tires CAUTION WARNING - Snow or ice If you equip your car with snow tires, • If you hear noise caused by • When driving on roads cov- they should be the same size and chains contacting the body, ered with snow or ice, drive at have the same load capacity as the retighten the chain to avoid...
Page 369: Light Bulbs Replacement
Authorized Hyundai Dealer. Removing/installing the headlight Use only the bulbs of the specified assembly can result in damage to wattage.
Page 370 Maintenance 1LDA7048 OEP066019 OVQ056003 WARNING - Halogen bulbs Headlight bulb 1. Open the hood and loosen the fasten- • Halogen bulbs contain pressur- er on the radiator grill cover. (1) Headlight (High) ized gas that will produce flying (2) Headlight (Low) pieces of glass if broken.
Page 371 Maintenance Type A OEP056024 Type B 1VQA5034 OEP056025 2. Loosen the retaining bolts and remove Position/Turn signal light bulb the headlight assembly from the body 1. Open the hood. of the vehicle. 2. Loosen the retaining bolts and remove 3. Remove the headlight bulb cover by the headlight assembly from the body turning it counterclockwise.
Page 372 Pull the bulb out of the Hyundai Dealer. socket. 5. Insert a new bulb by inserting it into the socket and rotating it until it locks into place.
Page 373 Maintenance Interior lights bulb replacement Front map lamp Tailgate lamp 1. Using a flat-blade screwdriver, gently pry the lens from the interior light housing. WARNING Prior to working on the Interior Lights, ensure that the “OFF” but- ton is depressed to avoid burning your fingers or receiving an electric 1VQA5046 1VQA5043...
Page 374 Maintenance 1VQA5048 OEP056037 1VQA5038 License plate lights bulb Rear combination light bulb 1. Open the tailgate. 2. Loosen the light assembly retaining 1. Loosen the lens retaining screws with (1) Stop and tail light screws with a cross-tip screwdriver. a cross-tip screwdriver. (2) Back-up light 2.
Page 375 Maintenance 1VQA5039 OEP066041 OEP066042 3. Remove the rear combination light 4. Remove the socket from the assembly 5. Remove the bulb from the socket by assembly from the body of the vehicle. by turning the socket counterclockwise pressing it in and rotating it until the until the tabs on the socket align with tabs on the bulb align with the slots in the slots on the assembly.
Page 376 Maintenance OEP056042 High mounted stop light bulb replacement If the light bulb is not operating, have the vehicle checked by an authorized Hyundai Dealer.
Page 377 Oil are now available. Along with other <Recommends> additional benefits, they contribute to fuel economy by reducing the amount of fuel HYUNDAI GEUINE ATF SP-III, DIAMOND ATF necessary to overcome engine friction. SP-III, SK ATF SP-III or other brands meeting Often, these improvements are difficult to...
Page 378 Maintenance Recommended SAE viscosity Engine oil viscosity (thickness) has an When choosing an oil, consider the range effect on fuel economy and cold weather of temperature your vehicle will be oper- number operating (starting and oil flow). Lower ated in before the next oil change. viscosity engine oils can provide better Proceed to select the recommended oil CAUTION...
Page 379: Corrosion Protection
Some of the common causes of high humidity, particularly when tempera- sion, Hyundai produces cars of the high- accelerated corrosion are road salts, tures are just above freezing. In such est quality. However, this is only part of...
Page 380 Maintenance To help prevent corrosion • When cleaning underneath the car, Keep paint and trim in good condi- give particular attention to the compo- tion You can help prevent corrosion from get- nents under the fenders and other Scratches or chips in the finish should be ting started by observing the following: areas that are hidden from view.
Page 381: Appearance Care
Maintenance APPEARANCE CARE Exterior care Insects, tar, tree sap, bird droppings, industrial pollution and similar deposits Exterior general caution can damage your vehicle’s finish if not It is very important to follow the label removed immediately. directions when using any chemical Even prompt washing with plain water cleaner or polish.
Page 382 Maintenance Waxing Finish damage repair Underbody maintenance Wax the vehicle when water will no Deep scratches or stone chips in the Corrosive materials used for ice and longer bead on the paint. painted surface must be repaired snow removal and dust control may col- promptly.
Page 383 Maintenance Aluminum wheel maintenance Interior care Cleaning the upholstery and interior trim The aluminum wheels are coated with a Interior general precautions clear protective finish. Vinyl Prevent caustic solutions such as per- • Do not use any abrasive cleaner, pol- Remove dust and loose dirt from vinyl fume and cosmetic oil from contacting ishing compound, solvent, or wire...
Page 384: Emission Control System
Do not turn the Electronic Stability Control bleach or re-dye the webbing because Your Hyundai is equipped with an emis- (ESC) system off by pressing the this may weaken it. sion control system to meet all emission ESC switch.
Page 385 (The ORVR system is designed to allow This vehicle should not be modified. the vapors from the fuel tank to be Modification of your Hyundai could affect loaded into a canister while refueling at its performance, safety or durability and...
Page 386: California Perchlorate Notice
All inspections and adjustments must be made by an authorized Hyundai dealer. Operating precautions for catalyt- • Avoid driving with a very low fuel level. ic converters (if equipped)
Page 387 Label information / 7-2 Warranties for your Hyundai vehicle / 7-3 Consumer information / 7-4 Reporting safety defects / 7-5 Binding arbitration (U.S.A only) / 7-5 Consumer information, Reporting safety defects...
Page 388 Consumer information, reporting safety defects LABEL INFORMATION There are several important labels and Frame number VIN (if equipped) identification numbers located on your vehicle. The label locations are identified in the illustrations shown. OVQ076001N OVQ076002N Identification label (if equipped) OVQ066023N Vehicle identification number (VIN) The vehicle identification number (VIN) is...
Page 389 Consumer information, reporting safety defects WARRANTIES FOR YOUR HYUNDAI VEHICLE Please consult your Owner's Handbook & Warranty Information booklet for your vehicle's specific warranty coverage. OVQ066022N OVQ078003N Tire specification / pressure label Engine number Tire label located on the driver's side of...
Page 390 Eastern Region 1705 Sequoia Drive information on uniform tire quality grad- 1100 Cranbury South River Road Aurora, Illinois 60506 ing. Your Hyundai dealer will help answer Jamesburg, NJ 08831 (800) 633-5151 any questions you may have as you read (800) 633-5151 this information.
Page 391 Written notice must be and if it finds that a safety defect exists in administered by and through the National delivered (via certified mail) to Hyundai a group of vehicles, it may order a recall Arbitration Forum (NAF) or the American Motor America, Attn: Consumer Affairs, and remedy campaign.
Page 392 Dimensions / 8-2 Bulb wattage / 8-2 Tires / 8-3 Capacities / 8-3 Specifications...
Page 393 Specifications BULB WATTAGE DIMENSIONS Item in (mm) Light Bulb Wattage Headlights (Low) Overall length 202.0 (5130) Headlights (High) Overall width 78.1 (1985) / 76.4 (1940) Front turn signal/Position lights 28/8 (Amber) Overall height 71.1 (1805) / 69.3 (1760) Side mark lights Front tread 66.3 (1685) Front fog lights...
Page 394 API Service SJ, SL or above, ILSAC GF-3 or above (5.2 l) (SAE 5W-20, 5W-30) <Recommends> 11.52 US qt. HYUNDAI GENUINE ATF SP-III, DIAMOND ATF SP-III, SK ATF SP-III or other Automatic transaxle fluid (10.9 l) brands meeting the SP-III specification approved by Hyundai Motors Co. Power steering 1.06 US qt.
Page 395 Index...
Page 396 Index Air bag - advanced supplemental restraint system ······ 3-78 Battery ········································································· 6-35 Driver's and passenger's front air bag ······················ 3-79 Before driving ································································ 4-3 SRS components and functions ······························· 3-83 Biding arbitration (U.S.A only) ····································· 7-5 Occupant classification system ································ 3-86 Brake system ·······························································...
Page 397 Index Door locks ···································································· 3-11 Speedometer ··························································· 3-110 Central door lock switch ·········································· 3-13 Tachometer ····························································· 3-111 Child-protector rear door lock ································· 3-15 Good braking practices ················································ 4-28 Tailgate ····································································· 3-15 Driver position memory system ·································· 3-57 Hazard warning flasher ············································· 3-137 Homelink®...
Page 398 Index Digital clock ··························································· 3-180 Power outlet ··························································· 3-179 Shopping bag holder ·············································· 3-177 Owner maintenance ······················································· 6-9 Sunvisor ·································································· 3-178 Interior lights ····························································· 3-125 Interior overview ··························································· 2-2 Power adjustable pedals ·············································· 3-59 Power sliding door and power tailgate ························ 3-17 Power ON/OFF button ·············································...
Page 399 Side table ································································ 3-175 Sunglass holder ······················································ 3-174 Warnings and indicators ············································ 3-119 Sunroof ········································································ 3-33 Warranties for your Hyundai vehicle ···························· 7-3 Weight of the vehicle ··················································· 4-40 Window ········································································ 3-26 Rear quarter window (manual flip - open) ·············· 3-28 Theft-alarm system ························································...
Page 400 Index Windshield defrosting and defogging ······················· 3-164 Automatic climate control system ························· 3-165 Defogging logic ······················································ 3-166 Manual climate control system ······························ 3-164 Winter driving ······························································ 4-32 Snow tires ································································· 4-32 Tire chains ································································ 4-32 Wiper blades ································································ 6-24 Wipers and washers ··················································· 3-132...
Page 401 This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER'S INFORMATION ORIGINAL OWNER _____________________________________________________ ADDRESS CITY _________________ STATE ___________ ZIP CODE _____________________ DELIVERY DATE (Date Sold to Original Retail Purchaser) DEALER NAME _______________ DEALER NO.
Page 402 See the label on the driver’s side of the center pillar outer panel. check the level of fluid on the dipstick. Use only HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands meeting OTHER TIRE INFORMATION : the SP III specification approved by Hyundai Motor Co..

Hyundai 2009 Entourage Owner's Manual

Your Vehicle at a Glance Interior Overview

4 Driving Your Vehicle

6 Maintenance

Quick Links

Chapters

Related Manuals for Hyundai 2009 Entourage

Summary of Contents for Hyundai 2009 Entourage

Table of Contents
