1x1 HDMI 1.3 Repeater
Operation Manual
CLUX-11S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLUX-11S and is the answer not in the manual?

Questions and answers

Related Manuals for Cypress CLUX-11S

Summary of Contents for Cypress CLUX-11S

  • Page 1 1x1 HDMI 1.3 Repeater Operation Manual CLUX-11S...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Introduction................2. Features..................3. Operation Controls and Functions.......... 3.1 Front Panel................3.2 Rear Panel................4. Connection and Installation............. 5. Specifications................6. Cypress HDMI v1.3 Series............

  • Page 3: Introduction

    1. Introduction The HDMI v1.3 Distribution Amplifier Series is the most advanced solution to HDMI signal distribution. Each product in this series is compatible to HDMI v1.3 specifications, a cutting-age technology which defines the support to transfer Deep Color (10-bit and 12-bit ) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz (6.75Gbps).

  • Page 4: Operation Controls And Functions

    3. Operation Controls and Functions 3.1 Front Panel HDMI OUTPUT 1x1 HDMI 1.3 REPEATER 1 HDMI Output: Connect output port to the HDMI display. 3.2 Rear Panel DC 5V HDMI INPUT POWER HDMI Input: Connect input port to the HDMI or DVI output of your source equipment such as DVD player or set-top-box.

  • Page 5: Connection And Installation

    4. Connection and Installation HDMI Cable HDMI Cable DVD or Set-Top-Box HDTV HDMI display LCD TV 5. Specifications Frequency bandwidth 2.25Gbps (single link) Input port 1 x HDMI female port (Type A connector) Output port 1 x HDMI female port Power Supply 5VDC/1A (US/EU standards, CE/FCC/UL certified) Dimensions (mm)

  • Page 8: Cypress Hdmi V1.3 Series

    6. Cypress HDMI v1.3 Series: Product Description CLUX-11S 1x1 HDMI V1.3 Repeater CLUX-12S 1x2 HDMI V1.3 Splitter CLUX-14S 1x4 HDMI V1.3 Splitter CLUX-18S 1x8 HDMI V1.3 Splitter CLUX-21SY 2x1 HDMI V1.3 Switcher CLUX-31S 3x1 HDMI V1.3 Switcher CLUX-31SY 3x1 HDMI V1.3 Switcher CLUX-41SY 4x1 HDMI V1.3 Switcher...
