- Page 1 CHDBX-1C HDBaseT Repeater 5-Play™ Operation Manual Operation Manual...
- Page 3 Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel .........3 6.2 Rear Panel .........4 7. Connection Diagram ......5 8. -
Page 6: Introduction
1. INTRODUCTION The HDBaseT™ Repeater allows HDBaseT systems to be extended and cascaded. Supporting the highest quality of uncompressed high- definition HD video up to 4K×2K, up to 8 channels of uncompressed multi-channel audio, RS-233 and IR control systems, PoE and Ethernet, complete HDBaseT 5 Play™... -
Page 7: Features
5. FEATURES • HDCP and DVI Compliant • Supports 3D over HDMI and 4k×2k resolution • Supports CEC bypass • Transmission of uncompressed data up to 200m/656ft with single device • Uncompressed video 1080p, 60Hz, 36-bit • Audio support up to LPCM 7.1CH, Dolby TrueHD and DTS-HD Master Aduio •... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel HDBaseT Repeater MODE LINK CHDBX-1C CAT5e/6 OUT MODE LED The yellow LED will flash when the unit is powered or when an active transmitter is connected. CAT5e/6 OUT Connect to the receiver unit with a single CAT5e/6/7 cable (up to 100m). -
Page 9: Rear Panel
6.2 Rear Panel DC 24V POWER MODE LINK CAT5e/6 IN MODE LED The yellow LED will flash when the unit is powered or when an active transmitter is connected. CAT5e/6 IN Connect to the transmitter unit with a single CAT5e/6/7 cable (up to 100m). -
Page 10: Connection Diagram
Ethernet with suitable Transmitters) Front DC 24V POWER MODE LINK CAT5e/6 IN Rear HDBaseT Repeater MODE LINK CHDBX-1C CAT5e/6 OUT 100 m Power Supply RS-232 Out Receiver HDMI Out CAT5e/6 to HDMI with LAN/IR/RS232 HDMI Output RS-232 RS-232 Device to... - Page 11 100 m Ethernet with suitable Transmitters) Front DC 24V POWER MODE LINK CAT5e/6 IN Rear HDBaseT Repeater MODE LINK CHDBX-1C CAT5e/6 OUT Power Supply 100 m Front DC 24V Optional 2nd Repeater POWER MODE LINK extends the operating CAT5e/6 IN...
-
Page 12: Specifications
8. SPECIFICATIONS Video Bandwidth 300 MHz/10.2 Gbps Input Port 1×RJ-45 Output Port 1×RJ-45 Resolution Support 480i~1080p@50/60, 1080p@24, 4k×2K CAT5e/6 In/Out Distance Up to 100/100 meters Power Supply 24 V/1.25 A DC (US/EU Standards, CE/ FCC/UL certified) Dimensions 102 mm (W)×145 mm (D)×25 mm (H) Weight 324 g Chassis Material... -
Page 13: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM CAT5e Category 5 Cable CAT6 Category 6 Cable Consumer Electronics Control HDCP High-bandwidth Digital Content Protection HDMI High Definition Multimedia Interface Power over Ethernet... - Page 16 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw...
