- Page 1 DCT-8S SRS TruVolume HDMI v1.3 Volume Leveler Operation Manual DCT-8S...
- Page 2 Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
-
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents Introduction…………………………………………………..………. Applications……………………..…………………………....…. Package Contents…………………………..…………….....… System Requirements……...…………………..….…………..……. Features……………………………………………..……..……… Specifications..………………………………………...………...…. Operation Controls and Functions………………...……..……… Top Panel ................. Left Side Panel…………………………………....…….… Right Side Panel................ Connection and Installation …….…………………..…..…..…... -
Page 5: Introduction
1. Introduction This most advanced HDMI to HDMI audio repeater and decoder incorporating SRS TruVolume™ technology will free you from volume fluctuations when switching TV channels. This device is HDMI v1.3 compliant and can transfer deep color video with high bandwidth up to 225MHz . It also does signal amplification with equalization for repeater function. -
Page 6: Features
5. Features HDMI v1.3, HDCP v1.1 and DVI v1.0 compliant Supports high definition input up to 1080p@(24/60)Hz, output resolution follows input Support HDMI signal amplification and equalization output for repeater function. Supports 2 channels audio from HDMI input to HDMI output ports. ... -
Page 7: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Top Panel VOLUME LEVELER POWER POWER: Press this button to turn ON or set the device to standby mode. ① 7.2 Left Side Panel HDMI IN DC 5V HDMI In: This slot is where you plug in your source equipment such as set- ①... -
Page 8: Connection And Installation
8. Connection and Installation Blue Ray DCT-8S Set-Top-Box... - Page 9 Acronyms Acronym Complete Term Consumer Elelctronics Control Digital Visual Interface HDCP High-bandwith Digital Content Protection HDMI High-Definition Multimedia Interface Sound Retrieval System...
