Page 1: Operation Manual
PLL FM STEREO/SW.MW.LW DUAL CONVERSION SYNTHESIZED WORLD RECEIVER DE1103 PLL FM STEREO/SW.MW.LW DUAL CONVERSION SYNTHESIZED WORLD RECEIVER Downloaded by RadioAmateur.EU DE1103 OPERATION MANUAL... -
Page 2: Table Of Contents
POWER SUPPLY INDEX OPERATING ON BATTERY POWER SUPPLY ............1 POWER INDICATION ............ 3 BATTERY INSTALLATION BATTERY CHARGER ............ 4 BEFORE OPERATION........... 6 1. Slide the battery lid. 2. Insert four AA batteries with SET THE CLOCK ............correct polarity as shown in TURN ON OFF THE UNIT ........... -
Page 3: Power Supply
POWER INDICATION POWER SUPPLY OPERATING ON AC Power indicator is a trapeze pattern, it is hidden when receiving programme. User can check power level by press Left side Medium Lower Full More 1. Plug the adaptor into a 220V AC power outlet. 2. -
Page 4: Battery Charger
BATTERY CHARGE BATTERY CHARGE Install four AA rechargeable batteries with correct polarity. CAUTIONS 2. Plug the adaptor into an 220V AC power outlet, connect the other side securely to DC Jack constantly displays, the unit is in charging process. 3. In power off mode, hold down button , in the meantime Please select high-quality rechargeable batteries. -
Page 5: Before Operation
Normally, set Local / DX button to DX position 4. Turn jog dial wheel to adjust minutes. 5. After setting, press to confirm. TIME DEGEN DEGEN STORE SSB/268MEMORIES 2. /4. DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET ST/MO SCAN 1. -
Page 6: Turn On Off The Unit
After setting, indicator AlARM 1 AlARM 2 constantly appears (Details refer to Page 12 Method 2 Press number button to input volume level directly, then press to confirm. DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET... -
Page 7: Band Meter Band Conversion
13.7 15.2 17.3 21.2 11.6 13.6 15.1 17.2 21.1 11.5 13.5 15.0 17.1 21.0 FM STEREO/SW.MW.LW DUAL CONVERSION DE1103 HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET ST/MO SCAN DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER... -
Page 8: Set Alarm On Off
Cancel Alarm /5./6. 1./7. In power off mode, press button , the unit defaults last STORE Alarm 2 setting. Press again to cancel, indicator AlARM STORE DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET ST/MO SCAN 2 disappears from the display. -
Page 9: Tuning Into A Station
3. When near a station, you can use two fingers to turn the jog dial wheel slowly to find the exact frequency. Sample 2 AM 810KHz BAND+ TUNE DEGEN DEGEN Sample 3 AM 120KHz BAND+ Sample 4 AM 10000KHz BAND+... - Page 10 4. Press any button to stop auto scan tuning. DEGEN DEGEN STORE SSB/268MEMORIES ALARM1 DEGEN DEGEN STORE DEGEN DEGEN SSB/268MEMORIES STORE SSB/268MEMORIES ALARM1 DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET ST/MO SCAN DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+...
-
Page 11: Preset Stations
SSB/268MEMORIES DEGEN DEGEN STORE SSB/268MEMORIES DEGEN DEGEN STORE SSB/268MEMORIES DEGEN DEGEN STORE SSB/268MEMORIES 1./3. 2./4. DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET ST/MO SCAN FM STEREO/SW.MW.LW DUAL CONVERSION DE1103 HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER... -
Page 12: Hold & Backlight
LCD will on when choosing stereo. HOLD DEGEN DEGEN STORE SSB/268MEMORIES NEWS/MUSIC Push the switch to corresponding position when listen news or music. DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET ST/MO SCAN NAR./WIDE 1./2. -
Page 13: Reset & Line Out
EARPHONES & FOLDING STAND RESET & LINE OUT RESET LISTENING WITH EARPHONES When listening to stereo reception, normally use earphones, If the unit operates erratically, press RESET to resume normal and the speaker will stop work automatically. operation. Reset function will not erase all of the memories except the clock time. -
Page 14: Receiving Ssb/Cw
DEGEN DEGEN STORE SSB/268MEMORIES MW Reception Ferrite antenna inside the unit functions as MW antenna, it is strongly effected by the reception direction. Therefore, when DE1103 FM STEREO/SW.MW.LW DUAL CONVERSION HOLD TIME BAND+ SYNTHESIZED WORLD RECEIVER SLEEP RESET... -
Page 15: Using Antenna
SW antenna. Extending the antenna 3.160 - 3.455 MHz 11.510 - 12.155 MHz straight upward to get the best 3.860 - 4.055 MHz 13.510 - 13.905 MHz DEGEN DEGEN reception. 4.710 - 5.105 MHz 15.010 - 15.705 MHz 5.910 - 6.255 MHz 17.260 - 18.105 MHz...
