Setup Menu Tab

From any view, press the MENU key twice to access
the tabbed Main Menu System, then press the RIGHT
cursor key until the Setup tab is selected.
NOTE:
Units - Temp
Units - Distance
Units - Speed
Language
Triplog Reset
Select Readouts
Depth Offset
Temp Offset
Speed Calibration (Advanced, only if Temp/Speed is Connected)
NMEA Output
Setup Menu
39
4:30 PM Page 44
(International Models Only)
(If Temp/Speed or GPS Receiver is Connected)
(If Temp/Speed or GPS Receiver is Connected)
(International Models Only)
(If Temp/Speed or GPS Receiver is Connected)
(Advanced, Sonar View Only)
(Advanced)
(Advanced)
(Advanced)

Units - Depth

Units - Depth selects the units of measure for all depth-
related readouts.
To change the Units - Depth setting:
1. Highlight Units - Depth on the Setup menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the Units - Depth
setting. (Meters [International Models Only], Feet, Fathoms; Default is
Meters for International models, and Feet for Domestic models)
Units - Temp
(International Only)
Units - Temp selects the units of measure for all temperature-related readouts.
International Models Only.
To change the Units - Temp setting:
1. Highlight Units - Temp on the Setup menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the Units - Temp
setting. (Celsius, Fahrenheit; Default = Celsius)
Units - Distance
(with Temp/Speed or GPS Receiver)
Units - Distance selects the units of measure for all distance-related readouts, and
will appear in the menu if a Temp/Speed Accessory is connected and the
paddlewheel has moved at least once, or if a GPS Receiver is connected.
To change the Units - Distance setting:
1. Highlight Units - Distance on the Setup menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the Units - Distance
setting. (Domestic Models: Statute Miles, Nautical Miles; Default = Statute
Miles; International Models: Meters/Kilometers, Meters/Nautical Miles,
Feet/Statute Miles, Feet/Nautical Miles; Default = Meters/Kilometers)
40
