Specifications
Depth Capability ............................................................................ 1500 ft (500 m)
Power Output ........................................ 500 Watts (RMS), 4000 Watts (Peak to Peak)
Operating Frequency ............................ 200 kHz and 83 kHz DualBeam PLUS™
Area of Coverage .............................................................. 60° @ -10 dB in 83 kHz
Target Separation ................................................................ 2 Inches (63.5 mm)
Power Requirement ................................................................................ 10-20 VDC
LCD Matrix.......................................................................................... 320 V x 240 H
Transducer .............................................................................................. XHS-9-20-T
Transducer Cable Length ...................................................................... 20 ft (6 m)
Product specifications and features are subject to change without notice.
53
4:30 PM
Page 58
20° @ -10 dB in 200 kHz
Notes
54
