Summary of Contents for Quest Engineering QM 1000P
- Page 1 User Manual MODEL: QM 1000P...
-
Page 2: Table Of Contents
Contents Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 General Description . -
Page 3: Safety Precautions
Indicates a potentially hazardous situation which, if mishandled, could result in death or serious personal injury . Indicates a potentially hazardous situation which, if CAUTION mishandled, could result in moderate or minor personal injury, and/or property damage . Q Motion Series User Manual QM 1000P... - Page 4 . from the AC outlet and contact your nearest Quest dealer . Make no further attempt to • Use the unit only with the voltage operate the unit in this condition as this specified on the unit .
- Page 5 Doing otherwise may result in fire or electric shock . An all-pole mains switch with a contact separation of at least 3mm in each pole shall be incorporated in the electrical installation of the building . Q Motion Series User Manual QM 1000P...
-
Page 6: General Description
. Your choice of QM series speakers The ideal combination for the QM 1000P is a pair of QM600S 15” sub bass boxes and two or four QM108 /QM10DC speakers . The QS150/230/300i speakers... -
Page 7: Front Panel Layout
Sub bass amplifier set to below There are indicatiors for signal presence, clip/ 100 Hz for low bass, above 125 for a higher range of compression and power . The QM 1000P soft knee bass frequencies . limiting will prevent severe amplifier clipping, but... -
Page 8: Rear Panel Layout
Connect signal leads from your mixer (master left/right, line out, to the balanced inputs using XLR mic leads . XLR connectors to be wired as follows: 1 ground, 2 +, 3 - . User Manual Q Motion Series QM 1000P... -
Page 9: Connections Block Diagram
• Two 8 speaker boxes will have a Ω combined impedances of 4 . If the sub Ω bass box is a 4 sub bass, only one sub Ω box can be connected . Q Motion Series User Manual QM 1000P... -
Page 10: Specifications
* Power output specifications will vary depending on power supply . Recommended power range 220V - 240V . Power rating tests performed at 240V . Tests at lower voltage (220v) will have a small reduction on output power User Manual Q Motion Series QM 1000P... -
Page 11: Dimensional Diagram
1000P User Manual Dimensional Diagram 490mm 436mm 24mm 410mm 440mm 490mm Q Motion Series User Manual QM 1000P... -
Page 12: Glossary
. Clipping up to the point of audible distortion (red lights flashing and signal overload), while the power amplifiers are turned down and running at only 30% power . User Manual Q Motion Series QM 1000P... -
Page 13: Operating Tips
. If you need more volume, turn down the input CLIP/LIMI T signal so it is out of the red and turn up the output of the mixer . Q Motion Series User Manual QM 1000P... - Page 14 Register Your Product Thank you for choosing Quest . Please take the time to complete your product registration card which is included with the packaging . Registering your Quest Engineering product will: • CONFIRM YOUR WARRANTY • REGISTER YOUR PRODUCT •...
