APPLIANCE INFORMATION

APPLIANCE SPECIFICATIONS:

Model Numbers: AP-UCBS
Descriptions: AP-UCBS-KIT With Programmable Clock/Timer and LIGHTED
Display
Dimensions: 13" W x 3-9/16" H x 7-3/16" D
Volts: 120
Watts: 1600
Amps: 13.6
Hertz: 60
Phase: 1
Power Supply Cord: 4 Ft., 3 Wire w/Ground
Plug: NEMA 5-15P. Furnished and attached
Power Supply Required: 120Volts, 15 Amp, dedicated circuit.
Wall Receptacle Required: 15Amp. NEMA 5-15R. Not furnished
Listing: ETL Electrical & NSF Sanitation

SETTINGS AND ADJUSTMENTS:

Brewing Capacity: 16, 32 and 64 ounce standard setting (quarter, half or full setting)
Brewing Temperature Brew Cone: User Adjustable. Default Temp Setting (t2): 192ºF (89ºC) to 196ºF (91ºC)
Thermostat Adjustment: Adjustable via Program Mode
Flow Control: .065 GPM Flow Rate
Hi-Limit Thermostat: Manual reset. Not adjustable.
Page 4
