READ AND SAVE THESE INSTRUCTIONS
DRI-STEEM
CRU SERIES
ELECTRIC STEAM HUMIDIFIERS
Installation Instructions
Maintenance Operations Manual
For Toll-Free Customer Support,
UL RECOGNIZED
COMPONENT
®
and
Call: 1-800-328-4447
CUL RECOGNIZED
COMPONENT
