Huffy Table-Top Basketball Game Owner's Manual

Table-top basketball game
Hide thumbs

Advertisement

Quick Links

Download this manual
© COPYRIGHT 2000 by HUFFY SPORTS
Table-Top Basketball Game
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
Read and understand
operator's manual before
using this unit.
Failure to follow operating
instructions could result
in injury or damage to
property.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-333 061
Internet Address: http://www.huffysports.com
REQUIRED TOOLS AND MATERIALS
• Phillips Head Screwdriver
1
WARNING
NOT SUITABLE FOR CHILDREN
UNDER THREE YEARS OF AGE
DUE TO SMALL PARTS/CHOKING
HAZARD.
07/03
:
P/N 211737A

Advertisement

loading

Related Manuals for Huffy Table-Top Basketball Game

Summary of Contents for Huffy Table-Top Basketball Game

  • Page 1 • N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A. Toll-Free Customer Service Number for U.S: 1-800-558-5234, For Europe: 00 800 555 85234 (Sweden: 009 555 85234), © COPYRIGHT 2000 by HUFFY SPORTS Owners Manual Customer Service Center...

  • Page 2: Safety Instructions

    • Climate, corrosion or misuse could result in system failure. • If technical assistance is required, contact Huffy Sports. Most injuries are caused by misuse and/or not following instructions.
  • Page 3 Get to know the basic parts of your basketball system... BACKBOARD SUPPORT TUBE NETTING TARP SUPPORT TUBES MINI BASKETBALLS 07/03 P/N 211737A...
  • Page 4 PARTS LIST AND IDENTIFIER Item Qty Part No Description 202250 Support Pipe, Curved 202251 Support Pipe, Curved 202252 Threaded Stabelizer Pipe, Straight 202253 Support Pipe, White, Plastic 202254 Support Pipe, Straight 202255 Upper U-Pipe 202256 Lower U-Pipe, Angled Connectors 202257 202258 202259 Tarp...

  • Page 5: Section A: Assemble The Stand And Tarp

    SECTION A: ASSEMBLE THE STAND AND TARP HARDWARE USED IN THIS SECTION TOOLS REQUIRED FOR THIS SECTION (actual size) Phillips-Head Screwdriver Item #17 (6) Attach lower U-pipe (7) to curved support pipes (1). Slide sleeve of the tarp (10) over stabelizer pipe (3) and secure by connecting stablizer pipe (3) to lower U-pipe with screws (17).
  • Page 6 Slide curved support pipe (2) over curved support pipe (1) NOTE: Locking pins on curved support pipe (2) MUST be facing inward (toward eachother). Connect threaded stablelizer pipe (3) using screws (17). P/N 211737A 07/03...
  • Page 7 Attach straight bars (5) by snapping them over the pins of curved support pipes (2). Connect threaded stablelizer pipe (3) using screws (17). 07/03 P/N 211737A...
  • Page 8 Slide upper U-pipe (6) over straight pipes (5). NOTE: Locking pins on pipe (5) MUST snap into holes of upper U-pipe (6). See FIG. A. Connect white, plastic pipes (4) together with plastic adapter (12). NOTE: Keep pins of each pipe aligned. P/N 211737A 07/03 FIG A.
  • Page 9 Slide white pipe assembly through sleeve of tarp (10) and snap it into opening on lower U-pipe (7). See FIG. A. NOTE: Locking pins on pipe (4) MUST snap into holes of U-pipe (7). Snap white pipe assembly into opening in upper U-pipe (6). NOTE: Locking pins on white pipe (4) MUST snap into holes of upper U-pipe (6).

  • Page 10: Section B: Assemble The Board And Rim

    SECTION B: ASSEMBLE THE BOARD AND RIM TOOLS REQUIRED FOR THIS SECTION Phillips-Head Screwdriver Install net (8) to rim (9). Item #8 (1) Position rim bracket (11) inside welded bracket extending from ring of the rim (9). P/N 211737A 07/03 HARDWARE USED IN THIS SECTION Item #16 (2) Item #18 (4)
  • Page 11 Attach rim (9) to board (19) using screws (18), rim bracket (11) and threaded reinforcement brackets (14). NOTE: Rim should be able to flip up. If it flops down the rim bracket (11) is on upside down. Hook board and rim assembly onto extension pipes of upper U-pipe (6).
  • Page 12 Secure board (19) with screws (16), bracket (21), washer (13) and wingnuts (15). Loop tarp onto hook of bracket (21) as shown. NOTE: Brackets (21) do not attach to the tubes. They are positioned correctly when attached to the board. Inflate mini basketballs (20) and place on tarp.
