  6. Owner's manual

Huffy N53 W24700 Owner's Manual

Huffy fitness equipment user manual
Hide thumbs

Advertisement

Table of Contents

WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO
PROPERTY.
Portable Basketball System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
• 2 People
• Tape Measure
• Wood Board (scrap)
• Sawhorse or
• Hammer
• Tape
• Phillips Screwdriver
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-632-792
Internet Address: www.huffysports.com

REQUIRED TOOLS AND MATERIALS:

• (2 each) Wrenches and/or
Socket Wrenches and
Sockets (Deep-Well Sockets
are Recommended).
7/16"
Support Table
7/16"
• Extension is Recommended.
1
• Garden Hose or
1/2"
9/16"
3/4"
AND/OR
1/2"
9/16"
3/4"
• Optional: Large &
Sand
• Step Ladder
8ft. (2.4 m)
Small Adjustable
Wrenches
09/04
P/N 211574

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N53 W24700 and is the answer not in the manual?

Questions and answers

Related Manuals for Huffy N53 W24700

Summary of Contents for Huffy N53 W24700

  • Page 1: Required Tools And Materials

    Portable Basketball System • N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A. WARNING! READ AND UNDERSTAND OPERATOR'S MANUAL BEFORE USING THIS UNIT. FAILURE TO FOLLOW OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. Toll-Free Customer Service Number for U.S: 1-800-558-5234,...
  • Page 2 P/N 211574 09/04 WARNING FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Owner must ensure that all players know and follow these rules for safe operation of the system. • DO NOT HANG on the rim or any part of the system including backboard, support braces or net.

  • Page 3: Safety Instructions

    • Minimum operational height is 6'-6" (1.98m) to the bottom of backboard. Most injuries are caused by misuse and/or not following instructions. ALL Huffy Sports basketball systems, including those used for DISPLAYS, MUST be assembled and ballasted with sand or water according to instructions. Failure to follow instructions could result in SERIOUS INJURY.
  • Page 4 PARTS LIST (See Hardware Identifier) Item Qty. Part No. Description 900026 Top Pole Section, Black 908107 Middle Pole Section, Black 908028 Bottom Pole Section, Black 200188 Rod, Zinc 3/8 x 5-1/4 Long 202822 Eyebolt, 3/8–16 x 3-3/4 Long 200117 Base 203124 Stake, Tie Down 203063...
  • Page 5 HARDWARE IDENTIFIER (BOLTS & SCREWS) Item #4 (1) Item #57 (6) Item #65 (1) Item #10 (1) Item #5 (1) Item #23 (1) Item #19 (1) Item #16 (1) Item #54 (3) Item #26 (6) Item #53 (1) Item #21 (1) Item #50 (1) Item #60 (4)* Item #61 (4)
  • Page 6 HARDWARE IDENTIFIER (NUTS & WASHERS) Item #37 (3)* Item #15 (20)* Item #58 (7) Item #11 (7)* Item #55 (1) Item #8 (4) Item #20 (8)* Item #62 (4)* Item #12 (1) HARDWARE IDENTIFIER (STEEL SPACERS, RODS & CLIPS) Item #51 (2) Item #33 (2)* HARDWARE IDENTIFIER (PLASTIC SPACERS, CAPS &...

  • Page 7: Before You Start

    BEFORE YOU START! To ensure optimal playability of backboard system, a close tolerance fit between the elevator components and hardware is required. Test-fit large bolts into large holes of elevator tubes, backboard brackets, and triangle plates. Carefully rock them in a circular motion to ream out Pour garantir l'utilisation optimale du panneau, les composants du système élévateur et la visserie doivent être bien ajustés (serrés).
  • Page 8 Identify pole sections. While maintaining alignment, bounce middle pole section (2) into top section (1) using a wood scrap as shown until the top pole no longer moves toward the pole identification sticker on the middle pole. IMPORTANT!: Align dimple of top pole section (1) into trough of middle pole section (2) as shown.
  • Page 9 Bounce top and middle pole assembly (1 & 2) onto bottom pole section (3) using a wood scrap as shown. Bounce until the top and middle pole assembly no longer moves toward the pole identification mark on the bottom pole. IMPORTANT!: Align dimple of middle pole section (2) into trough of bottom pole section (3)
  • Page 10 Install wheels (17) onto axle (28) and wheel bracket (25) with push caps (29) as shown. Position base as shown. Secure wheel bracket assembly with bolt (16) and nut (15) as shown. P/N 211574 09/04...
  • Page 11 Install rod (4) through holes in bottom pole section (3) and eyebolt (5). Insert pole assembly into tank (6) and through center hole on wheel assembly as shown. Secure pole assembly with strap (44), washer (11) and lock nut (8). WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE.
  • Page 12 Secure base struts (9) to pole using bolt (10) washers (11) and nut (12) as shown. WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Rotate the non-secured ends of base struts (9) as shown.
  • Page 13 Secure base struts (9) to base using bolt (14) washers (11) and nut (15). WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Install upper pivot bracket (18) to front of base using bolt (19), washer (20) and nut (8) as shown. 09/04 P/N 211574...
  • Page 14 Insert bolt (21) through lower pivot bracket (22) as shown, bolt (21) will be secured during step 13. Carefully place base assembly on its side. Install lower pivot bracket (22) with bolt (23), washers (20) and lock nut (8) as shown. Secure both hinge tubes (24) to second wheel bracket (25) with carriage bolts (26) and flange nuts (15).
  • Page 15 Install wheels (27) onto axle (28) and wheel bracket (25) with push caps (29) as shown. Position base as shown. Secure wheel bracket assembly with disc (30), washer (20) and nut (8) as shown. WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR...
  • Page 16 Install pole mount bracket (45) and reinforcement bracket (47) with carriage bolts (46) as shown. Tighten flange nuts (15) completely. Attach spacers (32, 33) to pole mount bracket (45) with bolts (54), washers (20), and lock nuts (37) as shown. IMPORTANT! Tighten just until washers (20) stop moving.
  • Page 17 Assemble lanyard (34) to locking pin (35) as shown (FIG A). Attach covers (48) onto pole mount bracket (45) with carriage bolt (50) and nut (15) as shown. IMPORTANT!: Loop end of pin lanyard (34) over carriage bolt (50) as it passes through the pole mount bracket (45) during this...
  • Page 18 Install spacers (51) onto backboard brackets (52), with bolts (53, 54) and lock nuts (55, 37) as shown. IMPORTANT!: KEEP HARDWARE LOOSE UNTIL AFTER STEP 25 IS COMPLETED. P/N 211574 09/04 Insert handle assembly through pole mount assembly as shown. Lock pole assembly in place at the 10’ (3.05 m) mark with pin (35).
  • Page 19 Identify elevator tubes (63 & 56). Toward Board Toward Board Attach lower elevator tubes (56) and counter balance spring (68) to backboard support brackets (52) using spacers (59), bolt (57), and nut (58) as shown. Upper Elevator tube Lower Elevator tube Toward Pole Toward...
  • Page 20 Starting with nuts (15) flush against bracket (52) secure rim (70) and bracket to backboard. IMPORTANT! For spring loaded rim assembly, refer to instructions included with rim hardware. NOTE: Rim mounting nuts and bolts supplied with rim hardware. NOTE: DO NOT use washers here on spring return style rims.
  • Page 21 Support pole on sawhorse. Attach backboard assembly to top pole section (1) as shown. Install pole cap (64). NOTE: Two people are recommended for this step. Use caution; elevator assembly is heavy. Install upper elevator tubes (63) to triangle plates (66) as shown. Install handle assembly to lower elevator tubes (56) using bolt (57), spacers (67), and nut (58) as shown.
  • Page 22 Insert bolt (57) through left side upper elevator tube (63), then stretch spring (68) onto bolt (57). Insert bolt (57) through right side upper elevator tube (63) and secure with nut (58). WARNING! USE EYE PROTECTION WHEN INSTALLING SPRINGS. P/N 211574 09/04...
  • Page 23 SECTION D: INSTALL FRONT COVER & HANDLE Upright system and fill base (8) with water (approx. 40 gallons) and snap fill cap (42) in place. Attach front cover (40) to hinge tubes (18) using carriage bolts (51) and flange nuts (22) as shown.
  • Page 24 Roll assembly to desired playing area. Secure assembly to ground using strap (44) and tie down stake (7). Apply height and moving label (43) to front of pole as shown. HEIGHT ADJUSTMENT TO ADJUST BACKBOARD: 1. While holding handle, remove pin. 2.
  • Page 25 Install net clips. Installez les pinces du filet. WARNING: Use of this product without proper installation of net clips, or when all net clips are not present could result in bodily harm. Be sure to follow directions carefully. AVERTISSEMENT : L'utilisation de ce produit sans installer correctement ou toutes les pinces du filet risque de causer des blessures.
  • Page 26 Install net. Installez le filet. Das Netz anbringen Instale la red. Insert net into bottom of clip as shown. Insérez le filet dans la base de la pince, comme illustré. Das Netz wie gezeigt unten in den Clip stecken. Introduzca la red en la parte inferior del sujetador como se muestra. Twist net until it snaps into position.
