SAFETY INSTRUCTIONS

FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY RESULT IN
SERIOUS INJURY, PROPERTY DAMAGE AND WILL VOID WARRANTY.
Owner must ensure that all players know and follow these rules for safe
To ensure safety, do not attempt to assemble this system without following the
instructions carefully. Proper and complete assembly, use and supervision is
essential for proper operation and to reduce the risk of accident or injury. A high
probability of serious injury exists if this system is not installed, maintained, and
operated properly. Check entire box and inside all packing material for parts
and/or additional instructional material. Before beginning assembly, read the
instructions and identify parts using the hardware identifier and parts list in this
document.
• If using a ladder during assembly, use extreme caution.
• Two (2) people are recommended for this operation.
• Seat the pole sections properly. Failure to do so could allow the pole sections to
separate during play.
• Before digging, contact utility company to locate underground power cables, gas,
and water lines. Ensure there are no overhead power lines within 20 ft. (7 m) radius
of pole location.
• Climate, corrosion, excessive use, or misuse could result in system failure.
• If technical assistance is required, contact Huffy Sports.
• Minimum operational height is 6' 6" (1.98 m) to the bottom of backboard.
• This equipment is intended for home recreational use only and NOT
excessive competitive play.
• Read and understand the warning label affixed to pole. Label is shown on page 6.
• The life of your basketball pole depends on many conditions. The climate,
placement of the pole, the location of the pole, exposure to corrosives such as
pesticides, herbicides or salts are all important.
• Adult supervision is recommended when adjusting height.
• Serious injury could occur if teeth/face come in contact with backboard, net, or rim.
Most injuries are caused by misuse and/or not following instructions.
For more information on assembly, placement, proper use and maintenance, visit
The American Basketball Council website at http://www.smarthoops.com.
In U.S. and Canada only:
We appreciate your purchasing one of our many fine products. We are sure that you will be very satisfied with your selection. Although
great care and effort have been taken, occasionally problems may occur. To ensure prompt and correct handling of any problems, or to
answer any questions, please contact our Toll-Free Customer Service Number listed below. Service will be quicker if you have your
Model Number (found on carton) and assembly instructions ready when calling. PLEASE WRITE YOUR MODEL NUMBER IN
THE SPACE PROVIDED ABOVE.
Toll-Free Customer Service Number for U.S: 1-800-558-5234, For Canada: 1-800-284-8339, For Europe: 00 800 555 85234
© COPYRIGHT 2001 by HUFFY SPORTS
printed on recycled paper
WRITE IN YOUR MODEL NUMBER:
In-Ground Basketball System
Owner's Manual
operation of the system.
Use caution when using this system.
Have questions...don't go back to the store!
For Australia: 1-800-333 061 - Internet Address: http://www.huffysports.com
(Sweden: 009 555 85234),
1
Customer Service
N53 W24700 South Corporate Circle
Sussex, WI 53089
__________
REQUIRED TOOLS AND
MATERIALS:
• Two People
• Tape Measure
• Tape
• Shovel and Spade
• Concrete, 900 lb. (408 kg) and Container to Mix
• Carpenter's Level
• Wood Board (Scrap)
• Step Ladder 8 ft. (2.4 m)
• Wrenches: (Two) 1/2", 9/16", 3/4" or two Large and
Small Adjustable Wrenches
• Drill
• Safety Goggles
U.S.A.
05/03
P/N 211376A

Advertisement

Table of Contents
loading

Summary of Contents for Huffy 211376A

  • Page 1: Safety Instructions

    • Concrete, 900 lb. (408 kg) and Container to Mix • Carpenter’s Level • Wood Board (Scrap) • Step Ladder 8 ft. (2.4 m) • Wrenches: (Two) 1/2”, 9/16”, 3/4” or two Large and Small Adjustable Wrenches • Drill • Safety Goggles 05/03 P/N 211376A...
  • Page 2: Before You Start

    Verlängerungsvorrichtung und die verschiedenen Befestigungsteile fest miteinander verschraubt werden. Große Schrauben zur Probe in die großen Löcher der Verlängerungsrohre, Korbwandklammern und Dreiecksplatte stecken und diese vorsichtig in einer Kreisbewegung hin- und herbewegen, um eventuelle Farbrückstände aus den Bohrungen zu entfernen. P/N 211376A 05/03 any excess paint from holes if necessary.
  • Page 3: Height Adjustment

    • See instruction manual for proper installation. In the U.S.:1-800-558-5234 and Canada: 1-800-284-8339 HEIGHT ADJUSTMENT TO ADJUST BACKBOARD: Position looped end of crank onto hook as shown. Rotate crank handle to raise or lower backboard. 201248 201240 2/99 Height Indicator Crank Hook 2/99 05/03 P/N 211376A...
  • Page 4 Correctly identify each pole section and mark indicated distance from ends with tape. Make sure ground is level with playing surface, then dig pole hole. WARNING! CONTACT UTILITIES BEFORE DIGGING. P/N 211376A 05/03 5-1/2” (14 cm) 5-1/2” (14 cm) BOTTOM GROUND...
  • Page 5 Assemble clamps (7) around bottom pole and ground sleeve (4) as shown. IMPORTANT! CLAMP ASSEMBLY MUST BE POSITIONED AS SHOWN BELOW. Fill hole approximately 3/4 full with concrete. Tamp down concrete to release air pockets. SURFACE 05/03 PLAYING P/N 211376A...
  • Page 6 1" (2.54 cm) IMPORTANT! WAIT MINIMUM OF 24 HOURS BEFORE GOING ON TO NEXT STEP. CONCRETE MUST CURE. P/N 211376A 05/03 FRONT OF POLE MUST BE PARALLEL WITH * PLAYING SURFACE * PLAYING SURFACE...
  • Page 7 INSTRUCTIONS WILL VOID ALL WARRANTIES WRITTEN OR IMPLIED. NOTE: Pole sections should have a 4-1/2" (11.4 cm) minimum overlap. WOOD SCRAP WARNING TWO PERSON MINIMUM REQUIRED FOR THIS NOT FOLLOWING RECOMMENDATION MAY RESULT IN BODILY INJURY. PROCEDURE. 05/03 P/N 211376A...
  • Page 8 PLAYING SURFACE Lower clamp cover (12) over clamps and snap into proper position. P/N 211376A 05/03 Remove pole cap (11) from bottom pole section and insert clamp cover (12) onto bottom section (3). Bend back exposed top flange sections of secured ground sleeve (4) as shown.
  • Page 9 Beginning with top hole in left and right screw jack support plates (16 & 17), install elevator tubes (15) to pole as shown. Then secure lower holes in support plates to pole. NOTE: Not all holes in support plates (16 & 17) are used in this assembly. IMPORTANT! DO NOT OVER TIGHTEN. 05/03 P/N 211376A...
  • Page 10 Center screw jack (21) between support plates (16 & 17) and secure as shown below. Attach logo label (22) to height indicator cover (23). Place cover (23) over screw jack (21). Install pole cap (11). POLE P/N 211376A 05/03 2.1m IMPORTANT! DO NOT OVER TIGHTEN.
  • Page 11 Align spacer (25) and screw jack assembly between elevator tubes (15) and secure. IMPORTANT! WHEN SECURING SCREW JACK (21) TO TOP ELEVATOR TUBES (15), USE SPACER (25) BETWEEN ELEVATOR TUBES AS SHOWN. 05/03 P/N 211376A...
  • Page 12 (15) as shown. NOTE: Same hardware used for upper and lower installation. P/N 211376A 05/03 REAR VIEW OF Y-FRAME (27) Loosely assemble bolt (28) and nut (29) to Y-frame support bracket (27) as shown. Repeat for opposite side. NOTE: Bolt (28) heads face outward toward backboard.
  • Page 13 Align rim mounting holes on Y-frame support bracket (27) to rim holes on backboard and tighten completely. WARNING TWO PERSON MINIMUM REQUIRED FOR THIS PROCEDURE. NOT FOLLOWING RECOMMENDATION MAY RESULT IN BODILY INJURY. IMPORTANT! ALIGN RIM MOUNTING HOLES WITH HOLES IN Y- FRAME 05/03 P/N 211376A...
  • Page 14: Outside View

    Refer To Instructions Included With Rim Hardware For Rim Assembly. P/N 211376A 05/03 The two outer hooks on net clip must face towards inside of goal rim. Insert larger hole in net clip onto rim stud, push down on net clip, then slide net clip right, locking or snapping securely into position (clips must "snap"...
  • Page 15: Front View

    SUPERVISION COULD RESULT IN SERIOUS BODILY HARM AND/OR PROPERTY DAMAGE. NOTE: If net releases during normal play, net was improperly installed. Please review instructions to install net properly. BACK VIEW WARNING STORE CRANK OUT OF REACH OF ADJUST HEIGHT WITHOUT ADULT 05/03 P/N 211376A...
  • Page 16 Apply height adjustment label (37) to front of pole as shown. P/N 211376A 05/03 REGULATION RIM HEIGHT IS 10 FEET (3.05 M). Secure pole pad (32) as shown. 10 feet (3.05 m)
  • Page 17: Parts List

    Bolt, Hex Flange, 5/16-18 x 4-1/2 808804 Pole Pad 12* 200121 Clip, Net Holder, (Black) 12* 200120 Clip, Net Holder, (Red) 204282 806259 Crank, Height Adjustment 201248 Label, Height Adjustment Item #10 (2) HARDWARE IDENTIFIER (CONTINUED) 05/03 Item #14 (16*) P/N 211376A...
  • Page 18 HARDWARE IDENTIFIER (CONTINUED) Item #25 (1) Item #24 (2) Item #28 (2) Item #29 (6) Item #26 (2) Item #34 (12*) Item #30 (4) Item #31 (4) YOU MAY HAVE EXTRA PARTS WITH THIS MODEL. P/N 211376A 05/03...
