- Page 1 ON LINE MULTISTANDARD 5000 VA - 6000 VA Manuale d’uso - User’s Manual - Bedienungsanleitung Manuel d’utilisateur - Manual de Usuario...
- Page 3 SAFETY This part of the manual contains precautions that must be adhered to strictly since they regard SAFETY. a) THE UPS MUST NOT OPERATE WITHOUT AN EARTH CONNECTION. The first connection to be carried out is the earth conductor, which has to be connected to the terminal marked b) Avoid connecting the output neutral to the input neutral or to earth as this could cause malfunctions.
- Page 4 USER’S MANUAL...
- Page 5 NTRODUCTION Thanks you for choosing our product. Our manifacturer are renowned specialists in the development and production of uninterruptible power supplies (UPS). The UPS in this range are high quality products, designed and built with care in order to give you the best performance.
-
Page 6: Table Of Contents
ONTENTS RESENTATION VIEWS DISPLAY MASK VIEW NSTALLATION PENING THE PACKING AND CHECKING CONTENTS OWER VERSION RACK VERSION ONNECTIONS IRST START TART UP FROM MAINS TART UP FROM BATTERY SHUTDOWN ISPLAY ANEL NDICATIONS UPS status indicators Measurements display area Configuration area ODES OF OPERATION R.E.P.O. -
Page 7: Presentation
RESENTATION This new family of UPSs has been designed with versatility in mind. These UPSs can in fact be installed either in a tower version or in a rack version, according to requirements. The 2 different versions of the product are shown below: Tower Rack... -
Page 8: Ups Views
RESENTATION VIEWS Release slots Rotatable display mask Manual by-pass Main switch switch Battery pack Removable front Cable with terminal panel Cable with terminal Battery pack Front view (front panel off) (front panel on) Battery expansion connector COMMUNICATION SLOT (expansion) RS232 communication port IEC 10A Power share sockets USB communication port Power share sockets heat protection... -
Page 9: Display Mask View
RESENTATION DISPLAY MASK VIEW “SEL / SET” button “ON” button “STBY” button Display Operating normally Configuration area Operating on mains power Maintenance action required Operating on battery power Timer Load powered from bypass Measurements display area Battery back-up indicator Stand-by/alarm Load level indicator... -
Page 10: Installation
NSTALLATION PENING THE PACKING AND CHECKING CONTENTS After opening the pack, the first thing to do is make a check of the contents. The pack should contain: 3 plastic covers (top panels) 2 cable guides 2 plastic keys to release display Probes for cables –... -
Page 11: Tower Version
NSTALLATION WARNING: this UPS product conforms to the current electromagnetic compatibility (EMC) regulations (C2 class). It may cause radio interference in the home environment. The user may have to adopt supplementary measures. OWER VERSION This chapter describes the operations required to prepare the UPS for use in the tower version. WARNING: for your safety and that of your product, the information set out below should be carefully followed. -
Page 12: Rack Version
NSTALLATION RACK VERSION This following describes the work needed to convert the UPS into rack version. WARNING: for your own safety and that of your product, it is important that you follow the instructions given below exactly. BEFORE PROCEEDING TO PERFORM THE SEQUENCE OF OPERATIONS DESCRIBED, MAKE SURE THAT THE UPS IS SWITCHED OFF COMPLETELY AND IS NOT CONNECTED TO THE ELECTRICAL MAINS OR LOAD OF ANY KIND... -
Page 13: Use
ONNECTIONS INSTALLATION MUST BE CARRIED OUT EXCLUSIVELY BY QUALIFIED PERSONNEL. THE FIRST CONNECTION TO BE CARRIED OUT IS THE PROTECTION CONDUCTOR (EARTH CABLE), TO BE INSERTED IN THE TERMINAL MARKED THE UPS MUST NOT BE OPERATED WITHOUT BEING CONNECTED TO THE EARTHING SYSTEM. Warning: if the neutral (N) and phase (F) instructions are observed for the plugs and sockets, the UPS will not change the existing neutral arrangements when inserted in a system. - Page 14 4. Use 3-pole cables with 4 mm section. With reference to the figure shown at the side: - Insert the cable from the 32A magneto-thermal switch into cable guide P1 (input line). - Insert the cable from the load into cable guide P2 (output line).
-
Page 15: First Start - Up
IRST START 1) Ensure that all the operations described in the paragraph above, “Connections”, have been carried out correctly. 2) Close the magneto-thermal switch located upstream of the UPS. 3) Press the general switch located on the front panel. 4) The UPS will start up after a few seconds; the display comes on, a beep is emitted and the icon will flash. -
Page 16: Display Panel Indications
ISPLAY ANEL NDICATIONS This chapter will describe in depth all the items of information that may be posted on the LCD. For easier understanding, we can divide the information displayed into three main groups: UPS status indicators Measurements display area Configuration area UPS status indicators ICON... -
Page 17: Measurements Display Area
Measurements display area The most important measurements relating to the UPS may be displayed on the display screen. When the UPS is switched on, the display shows the mains voltage value. To move on to display something else, press the “SEL / SET” button repeatedly until the desired measurement value appears. -
Page 18: Configuration Area
Configuration area The configuration area contains the main operating parameters of the UPS and displays its current status. The parameters found in this area can be modified by taking action directly from the display panel. SETTABLE PARAMETERS: Frequency: output voltage frequency Frequency Voltage: Output voltage Voltage... -
Page 19: Modes Of Operation
ODES OF OPERATION The mode that gives the load maximum protection is ON LINE mode (default), where the energy intended for the load undergoes a double conversion and is reconstructed on the output in a perfectly sinusoidal way with frequency and voltage fixed by the precision digital control provided by a microprocessor fully independently of the input (V.F.I.). -
Page 20: Ups Configuration
UPS C ONFIGURATION The following table illustrates all the possible configurations that users have at their disposal to best adapt the UPS to their needs. LEGEND: Indicates that the configuration can be modified, both via the configuration software supplied and also by means of action on the display panel. Indicates that the configuration can be modified only through the configuration software supplied. - Page 21 FUNCTION DESCRIPTION PREDEFINED POSSIBLE CONFIGURATIONS MODE Alarm threshold • Disabled Selects the overload for maximum Disabled • 0 ÷ 103 in steps of 1% user limit load Display Selects the level of Maximum Minimum ÷ Maximum in 20 steps brightness brightness of the LCD •...
-
Page 22: Communication Ports
OMMUNICATION PORTS The following communication ports are found on the rear of the UPS (see UPS Views): Serial port, available with RS232 connector and USB connector. NOTE: use of one connector automatically excludes the other one. Expansion slots for additional COMMUNICATION SLOT interface cards. RS232 and USB connectors RS232 CONNECTOR USB CONNECTOR... -
Page 23: Software
OFTWARE RS232 Monitoring and control software The UPSmon are provides effective and intuitive management of the UPS, displaying all the most important information, such as input voltage, load applied, and battery capacity. It is also able to automatically effect operations such as shutdown, transmission of e-mails, SMS and network messages when particular events that can be selected by the user occur. -
Page 24: Battery Pack
ATTERY PACK EPLACING THE BATTERY PACKS As mentioned in the introduction, the UPS comes with a dedicated battery pack to allow an easy hot swap replacement of the batteries with full safety ensured thanks to the protected connection system. WARNING: for your safety and that of your product, the information set out below should be carefully followed. -
Page 25: Problem Solving
ROBLEM SOLVING Irregular functioning of the UPS is very often not an indication of a fault but due simply to trivial problems, minor difficulties or carelessness. We therefore recommend that you refer to the table below which gives a summary of useful information to solve the most common problems. - Page 26 ROBLEM SOLVING PROBLEM POSSIBLE CAUSE SOLUTION THE BUZZER SOUNDS CONTINUOUSLY AND THE Reduce the load to within the threshold of 100% (or THE LOAD APPLIED TO THE DISPLAY SHOWS ONE OF UPS IS TOO HIGH user threshold in the case of code A54). THESE CODES: A54, F50, F51, F52, F55, L50, L51, L52 Replace the battery packs (as indicated in the chapter...
-
Page 27: Alarm Codes
ROBLEM SOLVING LARM CODES By using a sophisticated self-test system, the UPS can check and report on the display panel any problems and/or failures that could occur during normal operation of the equipment. In case of a problem, the UPS signals the event by posting on the display the code and type of alarm present (FAULT and/or LOCK). - Page 28 ROBLEM SOLVING Commands in progress: indicates presence of a remote command in progress. CODE DESCRIPTION Remote shutdown command Remote load on bypass command Remote switch-on command Battery test in progress LOCK The LOCK (block) type report signals are usually preceded by an alarm signal and, on account of their importance, result in the inverter being switched off and the load being powered through the bypass line (the procedure is excluded in case of lockouts due to strong and persistent overloads and lockouts following a short- circuit).
-
Page 29: Technical Data Table
ECHNICAL DATA TABLE 5000 6000 MODELS INPUT Nominal voltage [Vac] 220 - 230 - 240 Nominal frequency [Hz] 50 – 60 Accepted range [Vac] 0 ÷ 276 Voltage and frequency range for non [Vac] Maximum: 276 intervention of the battery [Vac] Minimum: 164 ÷... - Page 30 ECHNICAL DATA TABLE OPERATION POWERED BY OVERLOAD TIMES BYPASS INVERTER Activates bypass after 2 sec 100% < Load ≤ 110% Stoppage after 60 sec Stoppage after 120 sec Activates bypass after 2 sec 110% < Load ≤ 150% Stoppage after 4 sec Stoppage after 4 sec Activates bypass instantaneously Load >...
