Installer: Leave this manual with the appli-
ance.
Consumer: Retain this manual for future refer-
ence.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
state or local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
WARNING: If not installed, operated and
maintained in accordance with the manufactur-
er's instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
AND
FAN TYPE
DIRECT VENT
WALL FURNACE
MODEL
DVC-35T-1
DVC-35IPT-1
WARNING: If the information in these instruc-
tions are not followed exactly, a fire or explosion
may result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
Page 1
Advertisement
Table of Contents
Related Manuals for Empire Heating Systems DVC-35T-1
Summary of Contents for Empire Heating Systems DVC-35T-1
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS OWNER’S MANUAL FAN TYPE DIRECT VENT WALL FURNACE MODEL DVC-35T-1 DVC-35IPT-1 Installer: Leave this manual with the appli- WARNING: If the information in these instruc- ance. tions are not followed exactly, a fire or explosion Consumer: Retain this manual for future refer- may result causing property damage, personal ence. -
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Important Safety Information ........................3 Safety Information for Users of LP Gas ......................4 Requirements for Massachusetts ........................5 Introduction ..............................6 Specifications ...............................6 Gas Supply ............................... 7-8 Clearances ..............................8 Installation Instructions .......................... 9-11 DVC-35T Standing Pilot Lighting Instructions ..................12 DVC-35IPT Intermittent Pilot Lighting Instructions ................13 Pilot Flame Characteristics ........................14 Main Burner Flame Characteristics ......................15... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION THIS IS A HEATING APPLIANCE DO NOT OPeRaTe THIS aPPLIaNCe WITHOUT FRONT PaNeL INSTaLLeD. • Due to high temperatures the appliance should be located • Do not put anything around the furnace that will ob- out of traffic and away from furniture and draperies. struct the flow of combustion and ventilation air. -
Page 4: Safety Information For Users Of Lp Gas
SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires by point with the members of your household. Someday when and explosions. In its natural state, propane is odorless and there may not be a minute to lose, everyone’s safety will depend colorless. -
Page 5: Requirements For Massachusetts
REqUIREMENTS FOR MASSACHUSETTS For all side wall horizontally vented gas fueled equipment 3. SIGNAGE. A metal or plastic identification plate shall be installed in every dwelling, building or structure used in permanently mounted to the exterior of the building at a whole or in part for residential purposes, including those minimum height of eight (8) feet above grade directly in owned or operated by the Commonwealth and where the... -
Page 6: Introduction
INTRODUCTION Introduction Installation in Residential Garages always consult your local Building Department regarding regulations, Gas utilization equipment in residential garages shall be installed so that codes or ordinances which apply to the installation of a direct vent wall all burners and burner ignition devices are located not less than 18” above furnace. -
Page 7: Gas Supply
GAS SUPPLY Locating Gas Supply Installing a New Main Gas Cock The gas line can enter the unit either through the floor or outside each appliance should have its own manual gas cock. wall. The gas line opening should be made at this time. Location a manual main gas cock should be located in the vicinity of of the opening will be determined by the position of floor joists the unit. -
Page 8: Clearances
pressure of approximately 4.0” w.c. (.996kPa) for DVC-35T and 3.5” w.c. (.871kPa) for DVC-35IPT at the valve outlet with the inlet pressure to the valve from a minimum of 5.0” w.c. (1.245kPa) for the purpose of input adjustment to a maximum of 7.0” w.c. (1.743kPa). -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS 8. Drill two (2) 1/8” diameter holes in the wall and attach the Locating Wall Opening register with two (2) 10 x 1 1/2” provided screws. The furnace is to be located on an outside wall. Locate wall studs so 9. - Page 10 Locating Electric Supply a 7/8” diameter knockout is provided at the bottom of the left and right side panels. A three-prong (grounding) plug assembly is located within the control compartment (bottom) of the furnace. Please remove 7/8” knockout from appropriate side panel when routing plug assembly to an electrical outlet.
- Page 11 INSTALLATION INSTRUCTIONS (continued) appropriate vent kit for measured wall depth the vent tubes will Direct vent furnaces are designed to be installed on a uniform fit together. outside wall. When the wind comes from any angle (up, down or 1. Place caulking (not provided) beneath the collar of the outside from either side), it must hit the vent cap equally over both the air mounting plate.
-
Page 12: Dvc-35T Standing Pilot Lighting Instructions
DVC-35T STANDING PILOT LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by •... -
Page 13: Dvc-35Ipt Intermittent Pilot Lighting Instructions
DVC-35IPT INTERMITTENT PILOT LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition de- •... -
Page 14: Pilot Flame Characteristics
PILOT FLAME CHARACTERISTICS The correct pilot flame (Figure 12) will be blue, extending past THERMOCOUPLE the thermocouple. The flame will surround the thermocouple just below the tip. Natural gas pilots require adjusting when the inlet gas pressure is above 5” w.c. (1.245kPa). Remove the pilot cover screw on the BURNER control valve (Figure 3), and turn the adjustment screw clockwise to reduce flame. -
Page 15: Main Burner Flame Characteristics
MAIN BURNER FLAME CHARACTERISTICS The correct flame will be a short, blue inner flame with a much larger, light blue, outer flame. The burner does not have a primary air adjustment. The flame will be correct if the factory-set pressure and orifice opening are used. -
Page 16: Wiring
PRESSURE REGULATOR ADJUSTMENT-UNDER CAP SCREW OUTLET PRESSURE TAP PILOT ADJUSTMENT- INLET PRESSURE UNDER CAP SCREW GASFLOW PILOT OUTLET IGNITOR-PILOT ASSY. WIRING TO 24 V THERMOSTAT TO 24 V COMMON ON TRANSFORMER TO 24V."HOT" ON TRANSFORMER 1 P-MODEL GAS VALVE AND WIRING 120 VAC L2 NEUTRAL L1 "HOT"... -
Page 17: Service And Maintenance Suggestions
SERVICE AND MAINTENANCE SUGGESTIONS GENERAL: All furnaces have been fire-tested to check for proper If Pilot Does not Remain on After Releasing Knob: operation. This includes, main burner flame, pilot flame, fan 1. Follow instructions and hold button down longer and operation, fan control, limit control and automatic valve operation. -
Page 18: Dvc-35Ipt Intermittent Pilot Sequence Of Operation
DVC-35IPT INTERMITTENT PILOT SEqUENCE OF OPERATION Apply 24 VAC START To Appliance Thermostat Calls for Heat 5 Minute Retry Delay Pilot Valve Ignition OFF Flame Signal Wait for Flame Signal to Detected Disappear System Check Internal Check Trial for Pilot Valve Opens ... -
Page 19: Dvc-35Ipt Intermittent Pilot System Troubleshooting Sequence
DVC-35IPT INTERMITTENT PILOT SYSTEM TROUBLESHOOTING SEqUENCE START IP SYSTEM TROUBLESHOOTING SEQUENCE Turn OFF Gas Supply Disconnect System Control SmartValve System Troubleshooting Sequence End View INSET A 24 Volt Harness of Control Note: Before Troubleshooting, Become Familiar Thermostat Harness Set Thermostat to Call for with the Sequence of Operation Connector Heat... -
Page 20: How To Order Repair Parts
HOW TO ORDER REPAIR PARTS Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distributor. Parts can be shipped directly to the service person/dealer. All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equipment. -
Page 21: Parts View
PARTS VIEW 13119-10-0709 Page 21... -
Page 22: Service Notes
SERVICE NOTES Page 22 13119-10-0709... - Page 23 SERVICE NOTES 13119-10-0709 Page 23...
- Page 24 empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 24 13119-10-0709...
