Summary of Contents for Atlona AT-HD-V22M
- Page 1 Atlona 2x2 HDMI Matrix Switcher AT-HD-V22M User Manual Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
-
Page 2: Table Of Contents
..........8.1 RS-232 Serial Interface ..........8.2 RS-232 ..........8.3 Commands ..........9. RS-232 Serial Commands ..........10. Connection and Installation ..........11. Safety Information ..........12. Warranty ..........13. Atlona Product Registration ..........Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
INTRODUCTION Atlona Technologies’ AT-HD-V22M is a 2x2 HDMI Matrix Switcher with audio designed to work as a switcher for multiple Audio/Video sources and displays. This Atlona unit is capable of switching HDMI signals between two sources and two displays. Because it is a matrix switch, any or all of the 2 inputs in multiple resolutions of up to 1080p or 1920x1200. -
Page 4: Panel Descriptions
5. IR SENSOR. The IR sensor receives IR commands from the supplied remote control. 6. SOURCE SETUP BUTTONS. Setup the inputs 1 ~ 2 7. 19 INCH EAR MOUNT PAIR. 19 inch case Ear Mount pair Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 5: Rear Panel
For each desired output select the appropriate input by using the front panel select buttons, IR remote control, or the RS232 serial communications port. When powering up the AT-HD-V22M will return to its last used set- ting before Powered down. 1,2. SWITCH POWER ON or OFF 3. -
Page 6: Ir Extender
TION IR EXTENDER 1. IR Extender Connection 2. IR Extender Package Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515 www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515... -
Page 7: Rs-232 Serial Interface
2. RS-232 Atlona Technologies’ switcher can be controlled via the RS-232 serial control port to allow for interfacing to a PC, The serial communication parameters are 9600 baud, 8 bit, No Parity and 1 stop bit - this is often referred to as 9600 8N1. -
Page 8: Connection And Installation
TION CONNECTION AND INSTALLATION HDMI Player 2 HDMI Player 1 AT-HD-V22M PC RS232 Control IR ext. HDMI Display 2 HDMI Display 1 Note: If connecting the outputs to both displays and AV receivers, the audio output will only be stereo due to the display are only able to handle PCM or Stereo Audio through HDMI inputs. -
Page 9: Safety Information
Attempting to do so could expose you to dangerous electrical shock or other hazards. It may also cause damage to your AT-HD-V22M. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 10: Warranty
Atlona Technologies’ and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technologies’ decision, either return of the price paid for the product, repair, or replacement of the product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of the Customer’s receipt. -
Page 11: Atlona Product Registration
Atlona Product Registration Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure At Atlona, we respect and protect your privacy, assuring you that your registration information is completely secure.
