- Page 1 AtlonA 2x4 HDMI Matrix Switcher AT-HD-V24M User Manual...
-
Page 2: Table Of Contents
..........9. RS-232 Serial Commands ..........9.1 Standby Mode ..........9.2 Power Off Mode ..........9.3 Front Panel Lock ..........9.4 Unit Reset ..........10. Tipical Application ..........11. Safety Information ..........12. Warranty ..........13. Atlona Product Registration .......... -
Page 3: Package Contents
• RS232 package (RS232 DVD Drive & RS232 Cable) INTRODUCTION Atlona Technologies’ AT-HD-V24M is a 2x4 HDMI Matrix Switcher with audio designed to work as a switcher for multiple Audio/Video sources and displays. This Atlona unit is capable of switching HDMI signals between two sources and four displays. -
Page 4: Specifications
SPECIFICATIONS • 2x4 HDMI Matrix Switcher: 2 HDMI Inputs To 4 HDMI Outputs, • Input Signals: Video (TMDS) 0.5~1.0Vpp, DDC 5Vpp • Signal Supports : HDMI Standard, DVI and HDCP Compliant • Video Supported: HDMI and DVI formats up to 1080p or 1920x1200 •... -
Page 5: Rear Panel
For each desired output select the appropriate input by using the front panel select buttons, IR remote control, or the RS232 serial communications port. When powering up the AT-HD-V24M will return to its last used set- ting before Powered down. 1,2. SWITCH POWER ON or OFF 3. -
Page 6: Ir Extender
IR EXTENDER 1. IR Extender Connection 2. The IR Extender Components Setup... -
Page 7: Rs-232 Serial Interface
Not used RS-232 Atlona Technologies’ switcher can be controlled via the RS-232 serial control port to allow for interfacing to a PC, The serial communication parameters are 9600 baud, 8 bit, No Parity and 1 stop bit - this is often referred to as 9600 8N1. -
Page 8: Rs-232 Serial Commands
RS-232 SERIAL COMMANDS STANDBY MODE Note: Turning the unit System Power Off over RS232 will distinguish the LED display leaving only the Power Switch LED on. The Video and Audio outputs will also mute. While the unit is turned off by RS232 it will continue to accept and act upon switching commands. -
Page 9: Tipical Application
TIPICAL APPLICATION HDMI Player 2 HDMI Player 1 IR ext. AT-HD-V24M PC RS232 Control HDMI Display 4 HDMI Display 1 HDMI Display 3 HDMI Display 2... -
Page 10: Safety Information
Use only accessories recommended by ATLONA to avoid fire, shock or other Do not modify the wall plug. hazards. Doing so will void the warranty and safety features. -
Page 11: Warranty
Product, or repair or replacement of the Product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. -
Page 12: Atlona Product Registration
At Atlona, we respect and protect your privacy and assure you that your registration information is completely secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited warranty rights. To register go to www.atlona.com/registration...
