CHARGER OPERATION

1.)
Li-ion
3.6V
7.2V
NiMH /
NiCd
100%
i.) Black line on display will flash on which indicates the
charger is in standby mode.
3.) 3.6V Li-ion battery
1)
Flash
3.6V
7.2V
Li- ion Battery
3.6V
Adjust the charger case to fit on 3.6V Li-ion battery.
5.) 2AA or AAA batteries
Li-ion
3.6V
7.2V
NiMH /
NiCd
100%
When 2 batteries are correctly
inserted, the Blue LCD will indicate
2 batteries either in charging
process or fully charged.
After fully charged, the charger will
go to trickle charge maintain state.

SPECIFICATION

Input Voltage Switching Power Adaptor AC 100~240V, 50~60Hz
Li-ion Rechargeable Battery : 3.6V - 3.7V (DC 4.2V : 650mA)
Charge Capability
NiMH Battery : 2xAA 2.8V , 2xAAA 2.8V (DC 2.8V : 650mA)
12V / DC, 2A fuse, (Optional Accessory)
Car Adaptor
Li-ion Rechargeable Battery : Auto Voltage Monitor
Termination Method
NiMH Battery : Minus Delta
3.6/7.2V Li-ion & NiMH Battery Charger
i) Flash
Li-ion
3.6V
7.2V
NiMH /
NiCd
2) Flash 3) Flash 4) Flash 5) Full
30% 60%~70% 100%
1)
Flash 2) Flash 3) Flash 4) Flash
7.2V - 7.4V (DC 8.4V : 650mA)
(- )
2.) Easy adjustable contact and automatically +/- detection
3.6V
7.2V
Front
Adjust 2 pins to the connect position ( Battery )
Place the battery on the charger.
4.) 7.2V Li-ion battery
3.6V
7.2V
Li- ion Battery
7.2V
Adjust the charger case to fit on 7.2V Li-ion battery.
6.) If the Li-ion or NiMH battery does not work
5) Full
Li- ion Battery
3.6V
All display indication will flash on continuously while
the charger detect any defective battery
(UL, VDE, BS, SAA plugs)
Back
1) Flash 2) Flash 3) Flash
7.2V 7.2V
7.2V
30% 60%~70%
Li-ion
3.6V
7.2V
NiMH /
NiCd
C-735
Easy
adjustable
contact
4) Flash 5) Full
7.2V 7.2V
100%
Li-ion
3.6V
7.2V
NiMH /
NiCd
100%
