POWER Light is "on" w hen AC
pow er is present; flashes to
indicate a low battery
condition.
ARMED Light is "on" w hen
armed; "off" w hen disarmed;
flashes to indicate a previous
alarm.
INSTANT Light is "on" w hen
there is no entry/exit delay.
FIRE Light is "on" to indicate fire
alarm; flashes to indicate a
trouble condition w ith your fire
system.
PULL OUT ZONE ID TAB
ZONE LIGHTS are "on" steady
to indicate bypass; slow flash
for zone fault; rapid flash for
service condition.
NOTE: Some of the features described above may or may not be available for your system. Check w ith your installation company
READY Light is "on" w hen the
system is ready to arm;
flashes if ready to "force arm".
5 FUNCTION KEYS perform
various functions.
to find out how your system is programmed.
SERVICE Light is "on" to
indicate a trouble condition
w ith your system.
EMERGENCY ACTIVATION KEYS
NX-6V2 SYSTEM
KEYPAD
Includes models
NX-108E, NX-116E, NX-124E
NUMERIC CODE
ENTRY KEYS
