- Page 1 NX-181xx NetworX Voice keypad with touch buttons User Manual P/N 230241 • REV D • ISS 06MAR15...
- Page 2 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Contact information www.utcfireandsecurity.com or www.interlogix.com Customer support www.interlogix.com/customer-support or www.utcfssecurityproducts.eu...
-
Page 3: Table Of Contents
Content Important information 4 Limitation of liability 4 Advisory messages 4 Warranty 4 Introduction 5 Glossary of terms 7 The NX-181xx 8 Legend 8 Indicators, Icons and Lights 9 Away Arming 10 Stay Arming 10 Disarming 11 Multi Partition Arming – “Away mode”- All Partitions 11 Multi Partition Arming –... -
Page 4: Important Information
Important information Limitation of liability To the maximum extent permitted by applicable law, in no event will UTCFS be liable for any lost profits or business opportunities, loss of use, business interruption, loss of data, or any other indirect, special, incidental, or consequential damages under any theory of liability, whether based in contract, tort, negligence, product liability, or otherwise. -
Page 5: Introduction
damage to the product caused by misuse, careless handling, or where repairs have been made by others. No other guarantee, written or verbal, is authorized by UTC Fire & Security Americas Corporation, Inc. Introduction Your NX-181xx is an intuitive interface for users of your security system. Utilizing the latest in touch screen technology, and coupled with a powerful onboard microprocessor, and inbuilt phrase library, your NX-181xx delivers the most user friendly experience for controlling a security system available today. - Page 6 Keep in mind, the level of security you will obtain with this system relates specifically with two major factors: • The quantity, quality, and placement of security devices attached to this security system. • The knowledge you have of the security system and how that knowledge is utilized in a weekly test of the complete system.
-
Page 7: Glossary Of Terms
Glossary of terms Authority Level The level of access assigned to a users pin code. To turn your security system On. A group of zones within the security system configured with individual control. Partition Users of the security system are assigned partitions that they are allowed to control. -
Page 8: The Nx-181Xx
The NX-181xx Speaker Control Numeric touch keys Emergency keys Partition/Zone lights Microphone Legend There is vital visual information for you to review. See additional information. Touch the corresponding number on the numeric section of the touch screen. Start your recording. Touch the corresponding key on the touch screen. -
Page 9: Indicators, Icons And Lights
Indicators, Icons and Lights Green System is ready. Yellow System message present. Red (flashing) One or more zones are in alarm condition. Red (steady) System trouble message present. To hear system messages, touch the status key. For example, if the status icon is lit red (steady), there is a system fault present, this fault will now be announced. -
Page 10: Away Arming
Red flashing Partition in alarm Red rapid Indicates connected room station when intercom function is active. flashing Yellow Partition armed in the stay mode Partition not ready, zone / zones are not secure Away Arming Away arming is used when you are leaving and you want the premises protected in your absence. -
Page 11: Disarming
Touch [Stay]. Your security system is now armed in the stay mode. Disarming Make your way to the NX-181xx through one of the designated entry / exit doors. When you are detected entering, your NX-181xx will repeat a warning message for the duration of the entry delay until a valid pin code is entered. -
Page 12: Multi Partition Arming - "Away Mode"- Single Partitions
Multi Partition Arming – “Away Mode”- Single Partitions Independent partition control adds an enormous amount of flexibility to your security system and your NX-181xx makes it simple to control. You may wish to arm one partition in the away mode and disarm another partition, whilst arming a third in the stay mode. -
Page 13: Intercom Room Calling
Your system is now disarmed from either the Away or Stay modes. The partition that you have entered into is now disarmed, ONLY proceed with steps 3 and 4 if you wish to disarm all other partitions: [?]-[?]-[?]- Enter your 4 or 6 digit user pin code Turns off all remaining partitions Intercom Room Calling Up to eight NX-181xx Voice keypads can be configured to deliver room-to-room... -
Page 14: Understanding The Main Menu
Understanding the Main Menu Touching the [MENU] key accesses the NX-181xx's main menu, here you will find the 10 main features used for customization and setup of your security system. With its inbuilt intuitive voice prompts aiding you through all menus, using your NX-181xx is enjoyable and easy. -
Page 15: Control The Zone Chime - Menu 2
How to: Bypass a single zone Step Example: How to bypass zone 5 [MENU] - [1] Selects main menu - Option 1, To control zone bypass [5] - [ENTER] Selects zone 5. Note: If your zone number is higher than single digit, enter the 1, 2 or 3 digits indicating the zone you wish to select followed by enter at step 2. -
Page 16: System Event History - Menu 3
Set / Unset chime to this zone and adds it to the chime group Exits back to main menu (“Touch [1] to control zone [MENU] bypass…etc……etc……".) [MENU] Touch menu to exit. System Event History – Menu 3 The Event History menu is used to listen to the last 185 events that occurred in your security system. -
Page 17: System Test - Menu 4
System Test – Menu 4 Your security system is made up of different components, brought together to produce a very powerful, yet easy to use security system. These components are your noisemakers, communicator, back up battery and detection devices. All these different components require regular testing and maintenance in order for them to remain in peak operational performance. - Page 18 you are satisfied all the zones function correctly. Your communicator will not function during this test. Step How to: Perform a siren test [MENU] - [4] Selects main menu - Option 4, System Test. [?]-[?]-[?]-[?] Enter your 4 or 6 digit Master pin code. Selects the siren testing.
-
Page 19: User Configuration - Menu 5
Activate all detection devices, by walking within the field of view of motion sensors and opening and closing all protected windows and doors. Touch status to review tested zones [MENU] Moves back to component test selection. (step 3) Exits back to main menu (“Touch [1] to control zone [MENU] bypass…etc……etc……") [MENU]... - Page 20 Selects configure user pin. [4] – [ENTER] Selects user 4. [0] - [ENTER] To disable user. [MENU] Moves back to user configuration (step 3). Exits back to main menu (“Touch [1] to control zone [MENU] bypass…etc……etc……") [MENU] Touch menu to exit. How to: Remove partition control from a specific user Remove control of partition 2 from user 4.
-
Page 21: Phone Number Configuration - Menu 6
Arm only after close window User code will send open, close reports. Master code authority Must be off. Note: Refer to partition lights for selected options. Partition light lit solid red indicates feature is selected. Notes: The system must be disarmed before accessing user configuration. Do not remove all partitions from a users partition control. -
Page 22: Output Control - Menu 7
Step Example: Delete alarm phone number 1. [MENU] - [6] Selects main menu - Option 6, Phone Number Configuration. [?]-[?]-[?]-[?] Enter your 4 or 6 digit Master pin code. Selects alarm phone number 1. Disables alarm phone number 1. [ENTER] Accepts deletion. -
Page 23: Voice Message Recording - Menu 8
Voice Message Recording – Menu 8 With the NX-181xx there is no more need to memorize who has what user code, or what zone number is that sensor in the lounge room. Menu 8 allows you to record names against users, zones, partitions, rooms and outputs, creating an extremely user friendly security system. -
Page 24: Basic System Configuration - Menu 9
[7] selects room name. [?] - [ENTER] Select which User, Zone, Partition, Output or Room number to record. You must touch and hold talk. Record now (2.5 seconds recording time.) Moves back to User, Zone, Partition, Output or Room number selection [MENU] (step 4). - Page 25 [?]-[?]-[?]-[?] Enter your 4 or 6 digit Master user pin code. To configure the time. [9] - [ENTER] Enter the current hours value, i.e., 9 o’clock. [30]-[ENTER] Enter the current minutes value, i.e., 30 minutes. Selects AM time. To configure the date. [19]-[ENTER] Enter the current day, i.e., 19th.
- Page 26 [MENU] Moves back to step 4, Run mode / Idle mode selection. [MENU] Moves back to basic system configuration menu selection (step 2). Exits back to main menu (“Touch [1] to control zone bypass… etc…… [MENU] etc……") [MENU] Touch menu to exit. Note: Setting the option 4, Idle mode LED intensity, to zero [0] will activate the LED extinguish feature.
-
Page 27: Understanding The Mute Menu
Selects rest detector in alarm, and resets sensor. [MENU] Moves back to basic system configuration menu selection (step 2). Exits back to main menu (“Touch [1] to control zone bypass… etc…… [MENU] etc……") [MENU] Touch menu to exit. Understanding the Mute Menu You will find selectable intercom features under this menu, along with four other every day features such as volume control and microphone level adjustment. - Page 28 1. Voice Annunciation Turning this feature On, will force this room station to announce an incoming call, and identify from where the incoming call originated (which room station). Turning this feature Off, will allow a silent unannounced intercom connection. Ideal for baby monitoring. A “call cancelled” message announcement will occur upon disconnection.
- Page 29 [MENU] Touch menu to exit. Table 3: Mute Menu Options Selection Table Voice annunciation Reserved Room privacy Reserved Automatic room answering Reserved Outdoor station room answering Reserved Note: Refer to partition lights for selected options. Partition light lit solid red indicates the feature is selected.
-
Page 30: Word Library
Word Library Boat Remote Cabinet Hall Roof Three Car park Hallway Room Four Ceiling Heat Rumpus Five Cellar Heating Safe Child’s Hold-up Security Seven Alert Home Sensor Eight Closet Home theatre Shed Nine Computer Infrared Shock Cool Inside Shop Eleven Curtain Instant Side... - Page 31 Programmed Phone Number 1.………………………………………………..…………… Programmed Phone Number 2………………………………………………..……………. Programmed Phone Number 3.……………………………………………………………. Zone List Service provider……………………………………………………Phone…………………………………………….. Monitoring station………………………………………….……...Phone…………………………………………….. System type.……………………….……………………………..Date of installation……………………………..NX-181xx NetworX Voice keypad with touch buttons User Manual...
