- Page 1 VGA Distribution Amplifier 1x4 USER MANUAL SVG4 PTN VGA Distribution Amplifier 1x4 Version: SVG42013V1.1 PTN Electronics Limited www.PTN-electronics.com...
- Page 2 Please refer to the dealers for the latest details. This manual is copyright PTN Electronics Limited. All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of PTN Electronics Limited.
-
Page 3: Table Of Contents
VGA Distribution Amplifier 1x4 Table of Contents 1. Introduction ....................... 4 1.1. Introduction to SVG4 ..................4 1.2. Package Contents ..................4 2. Features ........................4 3. Specification ......................4 4. Interfaces Connection Introduction ................5 5. System Diagram ......................6 6. -
Page 4: Introduction
1. Introduction 1.1. Introduction to SVG4 PTN SVG4 is a high quality VGA signal distribution amplifier with 1 input and 4 outputs. Supporting the HD resolution, up to 3200×2400@60 (-3dB), 1 GHz（-3dB）full loading It has a good application in various occasions, such as meeting room, television education, room controlling, monitoring center, government agency, exhibition hall and other fields. -
Page 5: Interfaces Connection Introduction
0~10MHz is +0.1dB to -0.1dB 0~130MHz is +6dB to -0.8dB General Power Power Supply DC 12V Consumption Temperature -20 ~ +70℃ Humidity 10% ~ 90% W160 x H44 x D100 Case Dimension Product Weight 0.4Kg 4. Interfaces Connection Introduction PTN Electronics Limited www.PTN-electronics.com... -
Page 6: System Diagram
If not the problem mentioned above, probably there is something broken inside the unit, please send it to the dealer for repairing. 4) If the POWER indicator doesn’t work or no respond to any operation, please make sure the power cord connection is good. PTN Electronics Limited www.PTN-electronics.com... -
Page 7: Safety Operation Guide
DO NOT repair it on your own, in case of accident or increasing the damage of the equipment. 7) DO NOT splash any chemistry substance or liquid in the equipment or around. PTN Electronics Limited www.PTN-electronics.com... -
Page 8: After-Sales Service
VGA Distribution Amplifier 1x4 8. After-sales Service 1) If there appear some problems when running SVG4, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. 2) You can email to our after-sales department or make a call, please tell us the following information about your cases.
