- Page 1 DVI Distribution Amplifier 1x2 USER MANUAL SDV2 PTN DVI Distribution Amplifier 1x2 Version: SDV22013V1.1 PTN Electronics Limited www.PTN-electronics.com...
- Page 2 Please refer to the dealers for the latest details. This manual is copyright PTN Electronics Limited. All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of PTN Electronics Limited.
-
Page 3: Table Of Contents
DVI Distribution Amplifier 1x2 Table of Contents 1. Introduction ......................1 1.1. Introduction to SDV2 ..................1 1.2. Package Contents ................... 1 2. Features ........................1 3. Specification ......................1 4. Interface Introduction ....................2 5. System Diagram ....................... 3 6. -
Page 4: Introduction
DVI Distribution Amplifier 1x2 1. Introduction 1.1. Introduction to SDV2 SDV2 is equipped with high-quality 1 input, 2 outputs distribution chip, perfect matching with outside devices and anti-static function enable the advantages over others in distributing DVI signal. It is a DVI 1 x 2 distribution amplifier with DVI-I connectors, HDCP compliance, HDTV compatible, up to 1920x1200@60Hz. -
Page 5: Interface Introduction
10% ~ 90% W134 x H77 x D28 Case Dimension Product Weight 0.4Kg 4. Interface Introduction ① ② ③ Figure 5-1 Interfaces of SDV2 Name Description DVI input port. ① DVI INPUTS Female DB24+5 connector. ② DC 5V Power interface, accessing with a DC5V power. -
Page 6: System Diagram
DVI Distribution Amplifier 1x2 5. System Diagram PTN Electronics Limited www.PTN-electronics.com... -
Page 7: Troubleshooting & Maintenance
DO NOT repair it on your own, in case of accident or increasing the damage of the equipment. 7) DO NOT splash any chemistry substance or liquid in the equipment or around. PTN Electronics Limited www.PTN-electronics.com... -
Page 8: After-Sales Service
1) We offer products for all three-year warranty, which starts from the first day you buy this product (The purchase invoice shall prevail). 2) If there appear some problems when running SDV2, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty.
