IMPORTANT: READ OWNER'S MANUAL CAREFULLY
MODEL # PANTHER 15B MICRO SCRUBBER
OWNER'S MANUAL
FOR YOUR CONVENIENCE, RECORD THE FOLLOWING
IMPORTANT INFORMATION
MODEL: ___________________________________
SERIAL NUMBER: ____________________________
DATE PURCHASED: _ __________________________
PURCHASED FROM: __________________________
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Triple S PANTHER 15B
Summary of Contents for Triple S PANTHER 15B
- Page 1 OWNER’S MANUAL IMPORTANT: READ OWNER’S MANUAL CAREFULLY MODEL # PANTHER 15B MICRO SCRUBBER FOR YOUR CONVENIENCE, RECORD THE FOLLOWING IMPORTANT INFORMATION MODEL: ___________________________________ SERIAL NUMBER: ____________________________ DATE PURCHASED: _ __________________________ PURCHASED FROM: __________________________ ...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Precautions Machine Set Up & Installation Machine Operation Maintenance Battery Charging Preventative Maintenance Parts Breakdown & Lists 8-10 Wiring Diagram Troubleshooting Warranty ... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS This machine is intended for commercia l use. It is constructed for us e in an indoor environment and is not intended for any other use. Us e only with recommended accessories. All operators shall read, understand and exercise the following safety precautions: 1) DO NOT OPERATE MACHINE: Unless trained and authorized. -
Page 4: Machine Set Up & Installation
MACHINE SET UP & INSTALLATION UNCRATING MACHINE Be sure and check packing carton for any damage. Immediately report any damage to carrier. Check contents of package to ensure that the following items are included: 1. Machine 2. Batteries (x2) 3. Squeegee assembly 4. - Page 5 3. Mount the brush or pad driver onto the drive wheel hub and then rotate counterclockwise until it locks, as indicated in figure 3. 4. To remove the brush/pad, rotate the brush/pad clockwise until it is released from drive wheel hub.
-
Page 6: Machine Operation
1. Fill water into solution tank (3) from the inlet (20) through pipe or bucket. 2. Do not fill the solution tank completely, leave a few centimeters from the edge. ℃ 3. The water temperature must not exceed 40 . ... -
Page 7: Maintenance
CAUTION！ Do not use the machine with discharged batteries to avoid damaging the batteries and reducing the battery life. AFTER USING THE MACHINE After scrubbing, please proceed with below actions before leaving the machine: 1. Remove the brush/pad holder. 2. Empty the tanks as shown in the previous paragraph. 3. -
Page 8: Battery Charging
Out-water pipe filter cleaning （1） Screw and nut tightening check （1） rotary parts lubricated （2） Brush/Pad holder motor carbon brush check or replacement （2） Vacuum system motor carbon brush check or replacement （ ） After the first 8 working hours. （... -
Page 9: Preventative Maintenance
SQUEEGEE CLEANING NOTE The squeegee must be clean and its blades must be in good condition in order to getting a good drying performance. CAUTION ! It is advisable to wear protective gloves when cleaning the squeegee because there may be sharp debris. SQUEEGEE BLADE CHECK AND REPLACEMENT 1. -
Page 10: Parts List
PARTS LIST 46． Control panel 1. Recovery tank lid 2. Recovery tank 47． Main switch 3. Solution tank 48． Brush motor switch 4. Brush cover 49． Vacuum motor switch 5. Protective rollers 50． Suction Electromagnetic valve data switch ． 6. Brush Electric quantity indicator ．... -
Page 11: Parts Breakdown & Lists
PARTS BREAKDOWN... - Page 12 Control Panel ． 46． Control panel Electric quantity indicator ． 47． Main switch Brush motor indicator ． 48． Brush motor switch Vacuum motor indicator ． 49． Vacuum motor switch Suction Electromagnetic valve data indicator 50． Suction Electromagnetic valve data switch TECHINICAL DATA Machine length x width x height 770x500x550MM...
-
Page 13: Wiring Diagram
WIRING DIAGRAM 12AWG BLACK 12AWG 12AWG BLACK 16AWG 16AWG BLACK 20AWG WHITE KEY-PRESS BOARD 20AWG WHITE VACUUM MOTOR BRUSH MOTOR WATER VALVE ... -
Page 14: Troubleshooting
TROUBLESHOOTING Trouble Possible Cause Remedy The battery connector is disconnected Connect The machine does not work, indicator The batteries are completely discharged Charge the batteries light (51) does not turn on The power line disconnected from the power Connect The machine does not work, indicator The batteries are discharged Charge the batteries light (51) turns red... -
Page 15: Warranty
WARRANTY POLICY The warranty terms outlined below are in lieu of any other warranties, either stated or implied, including any implied warranty of merchantability, fitness for a particular purpose or otherwise. Under no circumstances will seller be liable for any loss, damage, expense or consequential damages arising in connection with the use or inability to use this product.
