Lopi Leyden Owner's Manual

Wood stove

Hide thumbs Also See for Leyden:

Manual (42 pages)

User manual (42 pages)

Owner's manual (40 pages)

Table Of Contents

Table of Contents

Quick Links

Wood Stove

Owner's Manual

• Freestanding Stove

• Mobile-Home Approved

• Alcove Approved

• Hearth-Stove Approved

Save these instructions

for future reference

Tested to: U.L. 1482

Test Report # 028-S-75-2

Listed

Table of Contents

Summary of Contents for Lopi Leyden

Page 1: Wood Stove
Leyden Wood Stove Owner's Manual • Freestanding Stove • Mobile-Home Approved • Alcove Approved • Hearth-Stove Approved Save these instructions for future reference SAFETY NOTICE: If this appliance is not properly installed, a house fire may result. For your safety, follow the installation directions.
Page 2: General Information Introduction & Important Information
Introduction Introduction We welcome you as a new owner of a Leyden wood-burning stove. In purchasing a Leyden you have joined the growing ranks of concerned individuals whose selection of an energy system reflects both a concern for the environment and aesthetics. The Leyden is one of the finest appliances the world over.
Page 3: Table Of Contents
Table of Contents Operating Your Appliance (continued) General Information Ash Removal .............. 24 Introduction & Important Information ......2 Ashpan Removal ..........24 Safety Precautions ............. 4 Blower Operation ............25 Features & Specifications .......... 6 Re-Loading the Stove ..........25 Stove Installation Overnight Burn ............
Page 4: Safety Precautions
Safety Precautions The viewing door must be Gasoline or other flammable closed and latched during liquids must never be used to operation. start the fire or "Freshen Up" the fire. Do not store or use gasoline or other flammable liquids in the vicinity of this Never block free airflow through appliance.
Page 5 Safety Precautions When installed in a mobile home, this appliance must be Do not place clothing or other bolted to the floor, have outside flammable items on or near this air, and not be installed in the appliance. Mobile bedroom (Per H.U.D. Home requirements).
Page 6: Features & Specifications
Features & Specifications Installation Options Features • • Freestanding EPA Phase II Approved • 2.3 Cubic Foot Firebox Volume • Freestanding in an Alcove • Single Air Control • Freestanding in a Mobile Home • Accepts Logs Up to 21” Long •...
Page 7: Stove Installation
Stove Installation (for qualified installers only) SAFETY NOTICE: Please read this entire manual before you install and use your new room heater. Failure to follow instructions may result in property damage, bodily injury, or even death. Contact local building or fire officials about restrictions and installation inspection requirements in your area.
Page 8: Floor Protection Requirements
Stove Installation (for qualified installers only) Floor Protection Requirements • Floor protection must extend 6" to the sides and rear of the stove and 16" to the front of the stove 39.25” wide by 44.875" deep - see Figure 2 and Figure 3). •...
Page 9: Top View - Straight Installation
Stove Installation (for qualified installers only) Minimum Flue Center 31-3/4" Top View - Back Wall Straight Installation Clearance B Typical Flue Center Clearance E Singlewall 24" Reduced Clearance 17.5" 6” Min. 27-1/4” Singlewall w Pipe Shield 14" 2-5/8” Clearance D 3-1/4”...
Page 10: Bypass Handle Installation
Stove Installation (for qualified installers only) Bypass Handle Installation The bypass handle is shipped inside the owner’s pack (along with a 1/8” hex wrench). With the set screws loosened, line up the bypass handle with the bypass rod (Figure 4). Press back on the bypass lever and slide the handle into place.
Page 11: Chimney Connector Requirements
Stove Installation (for qualified installers only) Chimney Connector Requirements • Chimney connector is required from the flue collar of the stove to the factory-built chimney (see Figure 7) or masonry chimney (see Figures 13, 14, and 15). • The chimney connector must be 6” diameter and a minimum 24 gauge black steel, 26 gauge blued steel, or one of the reduced-clearance connectors listed on page 8.
Page 12: Chimney Requirements
Stove Installation (for qualified installers only) Chimney Requirements • DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. • UL 103 HT Chimney must be used from the first ceiling or floor penetration to the chimney cap. •...
Page 13: Chimney Termination Requirements
Stove Installation (for qualified installers only) Chimney Termination Requirements • Must have an approved cap (to prevent water from entering) • Must not be located where it will become plugged by snow or other material • Must terminate at least 3' above the roof and at least 2' above any portion of the roof within 10' (see Figure 8) Chimney must extend 2' Slanted Roofs...
Page 14: Alcove Installation Requirements
Stove Installation (for qualified installers only) Alcove Installation Requirements Whenever the stove is placed in a location where the ceiling height is less than 8' tall, it is considered an alcove installation. Because of the reduced height, the special installation requirements listed below must be met.
Page 15: Mobile Home Requirements
Stove Installation (for qualified installers only) Mobile Home Requirements • Outside air must be installed - see "Outside Air Requirements" on page 13 • Chimney connector and chimney must be one of the following types: AMERI-TEC model DCC connector with AMERI-TEC UL 103 HT chimney DURAVENT model DVL connector with DURAVENT UL 103 HT chimney GSW Super Chimney Twenty-One connected directly to appliance I.C.C.
Page 16: Standard Ceiling With A Factory Built Chimney
Stove Installation (for qualified installers only) Chimney Cap Standard Ceiling (See the section "Chimney with a Factory Follow the chimney Termination Requirements" manufacturer's instructions Built Chimney for more details) and clearances for roof penetrations. A storm collar and flashing are required Chimney Sections (some require a radiation shield).
Page 17: Hearth Stove Positive Connection
Stove Installation (for qualified installers only) Hearth Stove Cap and flashing prevents water from Positive entering NOTE: The entire fireplace and Connection chimney must be clean, undamaged, and meet all local building codes NOTE: (UBC, etc.). Damage must be repaired prior to installation. The Most factory-built chimney must be 15' to 33' tall.
Page 18: Interior Or Exterior Masonry Chimney
Stove Installation (for qualified installers only) Interior or Exterior NOTE: The chimney must have a Masonry Chimney clay tile liner. If it does not, the installation must use a positive NOTE: Clay Liner connection (full reline). The This type of installation entire fireplace and chimney must requires a UBC approved be clean, undamaged, and meet...
Page 19: Operating Your Appliance
Operating Your Appliance Safety Notice If this appliance is not properly installed, a house fire may result. For your safety, follow the installation directions. Contact local building or fire officials about restrictions and installation inspection requirements in your area. Read and follow all of the warnings on pages 4 and 5 of this manual. Operating the Stove when it is Hot Always use gloves when operating a hot stove.
Page 20: Opening The Doors
Operating Your Appliance Opening the Doors Typically the doors are only opened to start the fire. Use the Loading Lid to re-load the stove. Open the bypass first (this prevents A door latch tool is included for smoke from entering the room). operation when the door latch is hot.
Page 21: Bypass Operation
Operating Your Appliance Bypass Operation The bypass controls the flow of smoke inside the heater. When pulled out, smoke goes directly up the flue, creating more draft. When pushed in, the smoke goes around the baffle, utilizing the secondary combustion and making the heater more efficient. ...
Page 22: Starting A Fire
Operating Your Appliance Starting a Fire Since the dawn of time man has debated the best way to start a fire. Some use the boy-scout "tee-pee", some prefer the "tic-tac-toe" stack. Either way, review the hints and warnings below to ensure proper fire starting.
Page 23: Adjusting The Burn Rate
Operating Your Appliance Adjusting the Burn Rate Use the air control slider to control the burn rate of the stove. See the illustration below for details. Use the air control to change the burn rate. Low Burn High Burn (air control closed) (air control open) Approximate Air Control Settings Overnight Burn...
Page 24: Ash Removal
Operating Your Appliance Ash Removal Ashes should be placed in a metal container with a tight fitting lid. The closed container of ashes should be placed on a noncombustible floor or on the ground, away from all combustible materials, pending final disposal. If the ashes are disposed of by burial in soil or otherwise locally ASHES dispersed, they should be retained in the closed container until all cinders have thoroughly cooled.
Page 25: Blower Operation
Operating Your Appliance Blower Operation The blower is available to assist the convection chamber in distributing heat to your home. The directions below detail the options you have with the blower and the best method for operation. HIGH Turn the dial all the way counter- The high position is all the way counter- Turn the dial all the clockwise until it clicks off.
Page 26: Hints For Burning
Operating Your Appliance Hints for Burning • Get the appliance hot before adjusting to low burn • Use smaller pieces of wood during start-up and high burns to increase temperature • Use larger pieces of wood for overnight or sustained burns •...
Page 27: Burn Procedure Pictorial Overview
Operating Your Appliance Burn Procedure Pictorial Overview For this wood stove to burn correctly it must be brought up to temperature, This allows the combustor to operate properly and transfer more heat into the home. By following the steps below you should be able to start and maintain a long-lasting, low-burn fire .
Page 28 Operating Your Appliance Burn Procedure Pictorial Overview (continued) 4 HOURS - This picture was taken 4 hours into a Now that the unit is hot and has a good coal bed, low burn. fill the unit with wood, wait a few minutes then close the bypass and adjust the air control to low.
Page 29: Troubleshooting
Operating Your Appliance Troubleshooting Problem Possible Cause • Open the bypass (pg. 21). Smoke Enters Room During • Start-Up Open the air control (pg. 23). • Cold Air Blockage - burn a piece of newspaper to establish a draft. • If the flame is not getting enough air, a small crack in the door is all that is needed.
Page 30: Maintaining Your Appliance
Maintaining Your Appliance Failure to properly maintain and inspect your appliance may reduce the performance and life of the appliance, void your warranty, and create a fire hazard. Daily Maintenance (while stove is in use) Remove Ash (if necessary) Remove ash as it builds up in the ashpan. Do not let it build up above the grate in the firebox. This prevents ash from falling on the tray below the ashpan when the ashpan is removed.
Page 31: Monthly Maintenance (While Appliance Is In Use)
Maintaining Your Appliance Monthly Maintenance (while appliance is in use) Make sure the appliance has fully cooled prior to conducting service. Door and Glass Inspection The door must form an air-tight seal to the firebox for the stove to work correctly. Inspect the door gasket to make sure it forms an air-tight seal to the firebox.
Page 32: Yearly Maintenance
Maintaining Your Appliance Monthly Maintenance (while appliance is in use) – Continued Clean the Combustion Brick Use a suitable vacuum cleaner (AshVac™ or equivalent) to vacuum the combustion brick (see illustration below). Hold the vacuum up against the holes in the combustion brick to pull ash from within the brick and combustor.
Page 33 Maintaining Your Appliance Yearly Maintenance – Continued Adjusting the Ashpan Latch The ashpan latch may be adjusted by opening the ashpan, turning the latch to the closed position, then pushing the ashpan in firmly. Repeat this process until the latch holds the ashpan secure, and air-tight. Cleaning the Combustor Area Ash may build up in the area to the left and right of the combustor.
Page 34: Door Parts
Maintaining Your Appliance Door Parts ID # Description Part # ID # Description Part # Door, Left Door, Right Door Gasket Gasket Cement Glass Gasket Glass Glass Clip w Screws, Gasket Door Hinge w Pins Left Door Handle w Hardware Right Door Handle w Hardware Replacing the Glass The glass must not contact the door retainer or glass clips directly.
Page 35: Firebox Parts
Maintaining Your Appliance Firebox Parts Apply penetrating oil (WD40) to the bolts prior to removal to prevent stripping. This nut is located on the exterior of the stove beneath the rear heat shield. ID # Description Part # ID # Description Part # Side Brick...
Page 36 Limited 5 Year Warranty To register your TRAVIS INDUSTRIES, INC. 5 Year Warranty, complete the enclosed warranty card and mail it within ten (10) days of the appliance purchase date to: TRAVIS INDUSTRIES, INC., 4800 Harbour Pointe Blvd. SW, Mukilteo, WA 98275. TRAVIS INDUSTRIES, INC. warrants this appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows: Check with your dealer in advance for any costs to you when arranging a warranty call.
Page 37 Limited 5 Year Warranty CONDITIONS & EXCLUSIONS 1. This new appliance must be installed by a qualified installer. It must be installed, operated, and maintained at all times in accordance with the instructions in the Owner’s Manual. Any alteration, willful abuse, accident, neglect, or misuse of the product shall nullify this warranty. 2.
Page 39: Optional Equipment
Optional Equipment Rear Blower Installation (Part # 99000138) The rear blower improves heat transfer by pushing heated air through the convection channel. Operating instructions are described in the section "Blower Operation". © Travis Industries 100-01177_005 4100818...
Page 40: Index
Index Air Control (Adjusting the Burn Rate) ......23 Hearth Stove Positive Connection ........ 17 Alcove Installation Requirements ......... 14 Hints for Burning ............26 Ash Removal ..............24 Interior or Exterior Masonry Chimney ......18 Ash Removal ..............30 Introduction &...
