Rear Panel - Laboga AD 5200SA Single User Manual

1. Main fuse integrated with power
supply socket
HINT: Take out the power cord during
a storm or when unused for a longer
period of time.
HINT: While changing the fuse , make
sure the blades of the fuse are
properly installed.

REAR PANEL

Combo:
Head:
Slo Blo fuse T1.6A
is in the case,
integrated with
power supply
is one
socket. There
spare fuse inside.
ATTENTION!
change the fuse, always unplug
the amplifier from the power
outlet and wait for at least one
minute.
ATTENTION!
the fuse for one of the same
value.
2. Additional footswitch socket
An additional footswitch (not included)
can be connected to this socket.
controls bypass of the effects loop and
reverb. When the effects loop is
bypassed, the Return socket is not
active. But, the Send socket is active.
(look at hint in point 5).
The proper
Loop/Reverb can be bought from any
Laboga dealer.
Before you
Always change
It
footswitch effects
