The additional footswitch
socket is in TRS form (T
– tip: 1; R – ring: 2; S –
Sleeve: 3), where the tip
activates the bypass of
the effects loop, the ring
turns the reverb off, and
the sleeve is ground.
3. Balanced line output with guitar
speaker's emulation
Balanced output with 0dBV line level,
where the signal is taken from speaker
transformer through
emulation.
HINT: Output can be used to connect
the amplifier directly to a mixer or
other devices
ATTENTION! This output can't
be used without a speaker or
fake load
connected
socket.
4. Effects loop socket – "Return"
Inserting a plug into this socket brakes
internal connection in the amplifier,
which bypasses the effects loop.
HINT: This input can also be used as
line input, therefore
serves as a power amp.
guitar speaker
("dummy load")
to power output
the amplifier
5. Effects loop socket - "Send"
Output signal socket taken from the
preamplifier. Nominal
level is 0dBV.
HINT: This output always has signal,
even if the
Consequently, the outlet can be used
to connect a guitar tuner permanently
– it does not influence the sound.
6. Power output socket for a 4 ohm
impedance cabinet.
7. Power output socket for an 8 ohm
impedance cabinet.
8. Power output socket for a 16 ohm
impedance cabinet.
ATTENTION! Do not connect
the cabinets
impedance at the same time.
ATTENTION!
the amplifier on, make sure the
cabinet is
appropriate
socket.
signal output
loop is not used.
with different
Before turning
connected to the
power output
