- Page 1 Hunter Light Fixture Installation Instructions 41911-01 10/13/2005 41911-01 rev 10-13-05.indd 10/13/2005, 1:01 PM...
-
Page 2: Troubleshooting
Read entire installation instructions carefully before beginning instal- lation and save these instructions. • To reduce the risk of electrical shock, install this light fixture only on Hunter fan types A through Z. Note: e fan type can be found on the ceiling fan package or on the name plate label located on top of the motor housing of the ceiling fan. - Page 3 Note: Save the plug button and switch housing cap should you choose to remove the light fixture in the future. 4. Feed the two wires from the light fixture through the center hole in the lower switch housing. 5. Attach the light fixture to the lower switch housing with the two screws included with the light fixture.
- Page 4 7. Connect the 9-pin plug connectors. Attach the lower switch housing to the upper switch housing with the three previously removed screws. 8. Install 2 - 60 W Max A-15 bulbs. 9. Attach the 8” extension chain to the fan pull chain. 10.
- Page 5 Note: Save the switch housing cover and two screws should you choose to remove the light fixture in the future. 3. Feed the two wires from the light fixture through the center hole in the switch hous- ing cover (included with the light fixture).
- Page 6 Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114 is Light Fixture weighs 2.5 lbs. © 2005 Hunter Fan Company Printed in China & Taiwan 41911-01 rev 10-13-05.indd 10/13/2005, 1:01 PM...
