© 2011 Char-Broil, LLC Columbus, GA 31902
PRODUCT GUIDE
MODEL 466611012
C-22G0S
Sears Model No.
D02 M90330
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-800-241-7548.
Printed in China
See rating label on grill for serial number.
Assembly instructions © 2011
12/14/11 • G313-001-040801

Advertisement

Table of Contents
loading

Related Manuals for Char-Broil 466611012 C-22G0S

Summary of Contents for Char-Broil 466611012 C-22G0S

  • Page 1 For support and to register your grill, please visit us at www.charbroil.com If you have questions or need assistance during assembly, please call 1-800-241-7548. © 2011 Char-Broil, LLC Columbus, GA 31902 Assembly instructions © 2011 Printed in China 12/14/11 • G313-001-040801...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DANGER For Your Safety ........2-3 If you smell gas: Grilling Guide.
  • Page 3 WARNING CAUTION CALIFORNIA PROPOSITION 65 Using pots larger than 6 quarts in capacity could exceed weight limit of the 1. Combustion by-products produced when using this product contain chemicals known to the State of side burner shelf California to cause cancer, birth defects, and other or side shelf, reproductive harm.

  • Page 4: Grilling Guide

    GRILLING GUIDE – Getting Started Temperature - Convective Grills ONLY. The temperature gauge in the hood of your new grill measures air temperature. The air temperature inside your grill will never First Time Use be as hot as the temperature at the cooking surface. Read your Assembly Manual and ensure the grill is put together properly.
  • Page 5 Rotisserie Cooking GRILLING GUIDE – Grilling 101 Rotisserie cooking is best for 'round' meat, such as large roasts, whole poultry, and pork. It generally requires an accessory motor Outdoor grilling is really quite simple. You'll succeed with and spit rod that allows the meat to be turned at a constant burgers, dogs, or steaks usually on your very first try.
  • Page 6 Wood Chips GRILLING GUIDE – Tips & Tricks For extra smoke flavor when grilling, try adding wood chips. Cooking on your new grill is a hands-on experience, and it is Soak the chips in water for approximately 30 minutes before recommended to remain outside with your grill while cooking.
  • Page 7 Cooking surfaces: If a bristle brush is used to clean any of the GRILLING GUIDE – Cleaning Your Grill grill cooking surfaces, ensure no loose bristles remain on cooking Why Clean? surfaces prior to grilling. It is not recommended to clean cooking surfaces while grill is hot.

  • Page 8: Use And Care

    LP Cylinder USE AND CARE •The LP cylinder used with your grill must meet the following requirements: DANGER •Use LP cylinders only with these required measurements: 12" (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) capacity maximum. •...
  • Page 9 LP Cylinder Exchange Connecting Regulator to the LP Cylinder •Many retailers that sell grills offer you the option of replacing 1.LP cylinder must be properly secured onto grill. (Refer to your empty LP cylinder through an exchange service. Use only assembly section.) those reputable exchange companies that inspect, precision fill, 2.Turn all control knobs to the OFF position.
  • Page 10 Leak Testing Valves, Hose and Regulator 1.Turn all grill control knobs to OFF. 2.Be sure regulator is tightly connected to LP cylinder. 3.Completely open LP cylinder valve by turning hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
  • Page 11 Only use the pressure regulator and hose assembly supplied with this grill. Replacement pressure regulator and hose assemblies must be specified or supplied by Char-Broil, LLC. If you have a grill problem see the "Troubleshooting Section". If the regulator frosts, turn off grill and LP cylinder valve immediately.
  • Page 12 Burner Flame Check Ignitor Lighting • Remove cooking grates and flametamers. Light burner, Do not lean over grill while lighting. rotate knobs from HI to LOW. You should see Turn OFF gas burner control valves. a smaller flame in LOW position than seen on HI. Always Turn ON gas at LP cylinder.

  • Page 13: Spider Alert

    Cleaning the Burner Assembly • Cooking surfaces: If a bristle brush is used to clean any of Follow these instructions to clean and/or replace parts of burner the grill cooking surfaces, ensure no loose bristles remain on assembly or if you have trouble igniting grill. cooking surfaces prior to grilling.

  • Page 14: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 15: Parts List

    PARTS LIST Qty Description NOT Pictured FIREBOX … HARDWARE PACK … ASSY INSTRUCTION, ENGLISH LOGO PLATE … ASSY INSTRUCTION, FRENCH HOSE VALVE REGULATOR ASSEMBLY CONTROL PANEL BURNER COLLECTOR BOX ELECTRODE SIDE SHELF SHELF BRACKET, RF/LB SHELF BRACKET, RB/LF WHEEL AXLE ROD MATCH HOLDER CART LEG, UPPER LEFT ASSEMBLY CART LEG, UPPER RIGHT ASSEMBLY...

  • Page 16: Parts Diagram

    PARTS DIAGRAM...

  • Page 17: Assembly

    ASSEMBLY NOTE: DO NOT over tighten screws and washers that come into contact with porcelain coated surfaces. Over tightening may cause the porcelain coating to crack and break, resulting in exposed metal that will be prone to rust. □ Place upper left leg and upper right leg as shown. □...

  • Page 18: Assembly

    Place front panel between legs. Hook the slots to the preassembled #10-24x3/8’’ machine screws. Tighten the screws. Front panel Turn assembly upside down and place on cardboard to prevent scratching of paint. Insert axle rod through wheels. Secure with wheel bushing and hitch pin. Push wheel assembly down until the axle bolt is locked securely by the clips on bottom of left leg.
  • Page 19 Stand cart upright. Hook tank exclusion wire onto the right hole on front panel. Flex tank exclusion wire to insert other end into the hole on back brace. Front Panel Tank exclusion wire Back Brace Attach firebox supports to upper legs by hooking the key hole slots on firebox supports onto the preassembled #10- 24x3/8’’...
  • Page 20 In front, place control panel assembly between upper legs, and slide the slots on control panel onto the preassembled #10-24x3/8’’ machine screws on upper legs. Tighten the screws. Place firebox assembly onto firebox supports and secure with 5x15 fiber washers and #10-24x3/4’’ wing screws. Note: To prevent damage to porcelain, DO NOT over-tighten screws.
  • Page 21 Place burner assembly into firebox as shown. Make sure the burner tubes are correctly engaged with the valve. Fasten the burner assembly to firebox using 5x15 fiber washers and #10-24 wing nuts. Note: To prevent damage to porcelain, DO NOT over-tighten screws. Attach ignitor wire to ignitor.
  • Page 22 Attach handle to lid with two 7x25 fiber washers, two 5x15 fiber washers and two #10-24 wing nuts. Place lid assembly onto firebox, align hinges. Hinges on lid fit inside hinges on firebox. Secure using two hinge pins and hitch pins. 5x15 Hitch Pin #10-24...
  • Page 23 Hang grease cup clip from bottom of firebox, and place grease cup into grease cup clip. CAUTION Failure to install grease cup clip and cup will cause hot grease to drip from bottom of grill with risk of fire or property damage.
  • Page 24 Tank collar opening must face the front of the grill. Set bottom of tank into notches of tank bracket. Lean tank inward and engage tank collar with tank wire. LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use & Care section).

  • Page 25: Troubleshooting

    DANGER: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from •Damaged hose. •Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.

  • Page 26: Troubleshooting

    Troubleshooting (continued) Problem Possible Cause Prevention/Solution Burner(s) will not light PIEZO PUSH-BUTTON AND ROTARY: using ignitor. •Push-button sticks at bottom. •Replace ignitor. •Rotary knob rotates without clicking. •Replace knob. •Sparking between ignitor and electrode. •Inspect wire insulation and proper connection. Replace wires if insulation is broken.
