Installing a SN6000 Fibre Channel Switch involves the following steps:
1. Mount the
2. Install the transceivers, page 39
3. Configure the
4. Apply power to the
5. Connect the management station or workstation to the
6. Configure the
7. Cable devices to the

Mount the switch

The switch can be placed on a flat surface and stacked, or mounted in a 19" Electronics Industries
Association (EIA) rack. See
specifications. Adhesive rubber feet are provided for surface mounts only. Without the rubber feet, the
switch occupies 1U of space in an EIA rack.
The rack mount kit is supported with the following HP custom racks only:
• HP 9000 Series Rack
• HP 10000 Series Rack
• HP 10000 G2 Series Rack

Before you begin

WARNING!
• In single-rack installations, stabilizing feet are attached to the rack.
• In multiple-rack installations, racks are coupled together.
• Leveling jacks on the rack are extended to the floor.
• The full weight of the rack rests on the leveling jacks.
• Heavy items, such as uninterruptible power supplies and hard drive storage enclosures, are installed
near the bottom of the rack.
• Similar components are installed next to each other in the rack. Because devices are of differing
depths, this will facilitate maintenance and service tasks.
• Only one device in a rack is extended at a time. A rack may become unstable if more than one device
is extended.
CAUTION:
• For proper airflow, the SFP+ media side (port side) of the device must face the front of the rack.
Mounting the switch in this direction allows air to enter from the front of the rack (SFP-port side of
switch) and exhaust through the back of the rack (power-supply side of switch). This prevents
overheating, which may cause equipment in the rack to fail.
• Allow a minimum of 63.5 cm (25 in.) clearance in front of the rack to allow the doors to open fully, and
76.2 cm (30 in.) in back of the rack to allow for servicing and airflow.
• If the device is mounted in a closed rack or there are multiple rack-mounted devices, make sure that the
operating temperature inside the rack enclosure does not exceed the maximum rated ambient
temperature.
• Multiple rack-mounted devices connected to the same AC supply circuit may overload that circuit or the
AC supply wiring. Consider the power source capacity and the total power usage of all switches on the
circuit.
• Reliable grounding in the rack must be maintained.
switch, page 35
workstation, page 39
switch, page 40
switch, page 41
switch, page 42
"Weight and physical
To reduce the risk of personal injury or damage to the equipment, ensure that:
HP StorageWorks SN6000 Fibre Channel Switch Installation and Reference Guide
switch, page 41
dimensions" on page 74 for weight and dimensional
35
