TM
THE SOLLATEK DISTRIBUTION SURGE PROTECTOR
DSP-D, DSP-S, DSP-M RANGE
AC Panel Transient Voltage Surge Suppressors
INSTRUCTION MANUAL
DSP-D
THREE PHASE
THREE PHASE
DSP-S
DSP-M
THREE/SINGLE PHASE
THREE PHASE
Important: This manual contains important safety instructions.
Keep this manual handy for reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DSP-D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sollatek DSP-D

  • Page 1 THE SOLLATEK DISTRIBUTION SURGE PROTECTOR DSP-D, DSP-S, DSP-M RANGE AC Panel Transient Voltage Surge Suppressors INSTRUCTION MANUAL DSP-D THREE PHASE THREE PHASE DSP-S DSP-M THREE/SINGLE PHASE THREE PHASE Important: This manual contains important safety instructions. Keep this manual handy for reference.
  • Page 2 IP66 and UL 1449 rated. International three phase supply versions only. The DSP-S range with ten-mode protection, maximum surge handling capacity of 90kA per phase, when used in conjunction with a Sollatek DSP-M series at the main service entrance provides the ultimate in complete high-capacity surge suppression. Requiring no operator intervention, LED indicators allow each MOV network to be constantly monitored.
  • Page 3 LED holder. conductors and neutral-ground busses. Use a pre-existing ½” conduit knock-out or drill a new ½” conduit hole in the panel. Remove the conduit nut from the Sollatek DSP- REMOTE STATUS INDICATION D Series and slide the wires and conduit nipple into the panel. A short piece (less than Each Sollatek DSP-D Series has remote indication of the protector status.
  • Page 4 Should this light glow RED at any time, consult INSTALLATION DESCRIPTION a qualified electrical contractor to check the normally closed Sollatek DSP-S units are connected in parallel (or in “shunt”) across the supply to be integrity of the building wiring. This RED light does customer customer normally open protected.
  • Page 5 Sollatek DSP3P-S90 Configuration and Schematic Connection Diagrams 120/208V THREE PHASE 4W WYE 240/415V THREE PHASE 4W WYE 277/480V THREE PHASE 4W WYE 220/380V THREE PHASE 4W WYE Sollatek DSP3P-S90 Configuration and Schematic Connection Diagrams 240V THREE PHASE 3W DELTA 480V THREE PHASE 3W DELTA...
  • Page 6 Connect the terminals within the suppressor Sollatek DSP-M units are connected in parallel (or in “shunt”) across the supply to be to the load side of 60A breakers or fuses withing the panel. See specific connection protected.
  • Page 7 Sollatek DSP3P-M Configuration and Schematic Connection Diagrams 120/208V THREE PHASE 4W WYE Sollatek DSP3P-M Configuration and Schematic Connection Diagrams 120/240V THREE PHASE 4W HIGH LEG DELTA Note: L2 is designated as the "high leg" Sollatek DSP3P-M Configuration and Schematic Connection Diagrams...
  • Page 8 Sollatek DSP3P-M Configuration and Schematic Connection Diagrams 277/480 THREE PHASE 4W WYE 220/380 THREE PHASE 4W WYE 240/415 THREE PHASE 4W WYE Sollatek DSP3P-M Configuration and Schematic Connection Diagrams 480V Three Phase 3W Delta Maintenance At intervals not exceeding two months, check: 1.
  • Page 9 POWER PROBLEMS AND THEIR ASSOCIATED CAUSES All electrical and electronic equipment, connected to the mains supply is at The following is a summary of the main types of power problems, causes risk of being damaged from spikes, surges, lightning, brown-outs, power- and how these affect electrical and electronic equipment.
  • Page 11 Fax: International +44 1753 685306 National 01753 685306 E-mail: sales@sollatek.com www.sollatek.com ©Sollatek (UK) Limited 1996 All Rights Reserved. SOLLATEK and the SOLLATEK device are the trade marks of the Sollatek group of companies. Dec 05 Version 1.0 DSP-D, DSP-S, DSP-M RANGE...
