Sollatek DSP3P-80 Instruction Manual

240/415v 80kva zone defender pro
Hide thumbs
1
2
Table of Contents

Advertisement

Quick Links

Download this manual

STaTUS InDICaTor

nOTE: ALL wIRES mUST BE COnnECTEd And POwER
APPLIEd Before ThE LEd wlLL ILLUmInATE.
The dSP3P Zonedefender PRO Series of suppressors has comprehensive, solid state, continu-
ous visual status monitoring present in each unit. The gREEn indicator light will go
out in the event the suppressor capability is exceeded or if there is an internal safety
component failure. If the light goes out, call the factory for replacement instructions.

DIaGnoSTIC InDICaTIon

The dSP3P Zone defender PRO provides a patent pending diagnostic circuitry that
monitors connected power and protection status. The following is a description of
each indication.
gREEn (On) AC POwER is present and protection is provided.
REd
(OFF)
gREEn (OFF) AC POwER is present but the Zone defender PRO needs replaced.
REd
(On) In addition, an audible alarm will sound and the remote indication will
change states.
gREEn (OFF) AC POwER or ground is missing. verify wire connections are correct.
REd
(OFF) make sure circuit breaker is engaged. Check panel for power.

remote Status Indication

The dSP3P Zone defender PRO provides for remote monitoring via a (normally open) or
(normally closed) circuit. The circuit is rated for 3amps at 120vAC. The common wire is
yELLOw, the normally open wire is BLUE and the normally closed wire is REd.

MaInTenanCe

At intervals not exceeding two months, check:
1. Status indication light
2. Conditions of connecting cables
noTe: no customer serviceable parts inside. opening unit WIll void Warranty.
Tm
SollaTek (Uk) lTD
UnIT 10 POyLE 14 IndUSTRIAL ESTATE, nEwLAndS dRIvE, POyLE, SLOUgh SL3 0dX, UnITEd KIngdOm
Tel: International +44 1753 688300 national 01753 688300
Fax: International +44 1753 685306 national 01753 685306
E-mail: sales@sollatek.com
www.sollatek.com
©Sollatek (UK) Limited 1996 All Rights Reserved.
SOLLATEK and the SOLLATEK device are the trade marks of the Sollatek group of companies.
Tm
The SollaTek DSP3P-80/120
240/415V 80kVa
zone DefenDer Pro
Instruction manual
Important: This manual contains important safety instructions.
Keep this manual handy for reference.
