2. SYSTEM OPERATION

2.1. System Status Memory

The system will enter the same mode after powering on as when it was powered off.

2.2. Button Function

Button
BTN #1 once
BTN #2 once
BTN #1 2 sec.
BTN #3 once
BTN #3 2 sec.
BTN #4 3 sec. Remote Engine Start
BTN #2+3 once*
BTN #1+2 once
BTN #1+3**
BTN #1 then #1 once
BTN #1 then #1 twice
BTN #1+4 1 sec.
BTN #2+4 once*
BTN #3+4 once* 2way RC Vibration On/Off 2way RC Vibration On/Off 2way RC Vibration On/Off
*=For 2way LCD or LED remotes only.
**=The CH3 output will be continuous whilst BTN #1+3 are pressed.

2.3. Programming New Remote Controls

The included remote controls have been programmed to the system in the factory. Follow the
procedure below to program a new remote control to the system:
- Turn the ignition on with the system disarmed.
- Within 10 seconds, press valet switch 3 times. (or 6 times if pager upgrade is installed).
- The siren sounds for 2 sec. to confirm the system is now in code learning mode.
- Within 10 sec., press any button of 1
The siren will sound for 1 sec. and hazard lights flash twice to confirm the 1
been programmed to the system and all the previous codes in the system will be erased
entirely.
- Within 10 sec., repeat for the 2
applicable.
* Up to 4 remotes can be programmed to the system
* The system will leave the code learning mode after programming 4 remotes to the system
and the siren will sound for 2 seconds to confirm.
* If no buttons are pressed within 10 seconds, the system will leave the learning code mode
and the siren will sound for 2 seconds to confirm.
* The system will leave the code learning mode if the ignition is turned off at any time and the
siren will sound for 2 seconds to confirm.

2.4. To Arm the System

A. By remote control
Remote Arming:
- With the system disarmed and ignition off.
- Press button #1 once.
- Siren chirps once.
- Hazard lights flash once.
- Doors lock and windows close.*
- LED flashes slowly to confirm the system is armed.
* Window closure requires car with total closure or separate window closure module.
B. By passive arming
To turn the Passive Arming feature on or off:
- While the system is disarmed or the ignition is on:
- Press button #1+4 for 1 sec.
- The siren will chirp once to confirm the function is on.
- The siren will chirp twice to confirm the function is off.
When Passive Arming is on:
- Turn the ignition off and close the doors, bonnet and boot properly.
- LED indicator flashes rapidly.
- The system will automatically be armed 30sec. later.
- The siren chirps once and hazard lights flash once to confirm the system is armed.
Armed
Arm
Disarm
Panic
Car Finder
Boot Release
Remote Engine Start
Status Report
Silent Disarm
CH3
Arm & Bypass I
Arm & Bypass II
Passive Arming On/Off
2way RC Power Saving
st
remote control
nd
remote control and again for 3
Disarmed
Arm
Disarm Door Unlock
Panic
Car Finder
Boot Release Boot Release
Anti-hijacking
Status Report Status Report
Silent Disarm Silent Disarm
CH3
Passive Arming On/Off
2way RC Power Saving
rd th
and 4
-
IGN On
Door Lock
CH3
st
remote has
remotes as
