ORDERING REPLACEMENT PARTS
To order replacement parts, contact the ICON Health & Fitness Ltd. office, or write:
ICON Health & Fitness Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds
LS11 8JG
Tel: Country Code:
08457-089009
Fax: 0113-2411120
When ordering parts, please be prepared to give the following information:
• The MODEL NUMBER OF THE PRODUCT (PETL63510)
• The NAME OF THE PRODUCT (PROFORM
®
635 treadmill)
• The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual)
• The KEY NUMBER OF THE PART(S) (see the PART LIST on page 27 and the EXPLODED DRAWING
attached in the centre of this manual)
• The DESCRIPTION OF THE PART(S) (see the PART LIST on page 27 and the EXPLODED DRAWING
attached in the centre of this manual).
PROFORM is a registered trademark of ICON Health & Fitness, Inc.
Part No. 173756 R0601A
Printed in USA © 2001 ICON Health & Fitness, Inc.
Model No. PETL63510
Serial No.
_
Find the serial number decal and
write the serial number in the space
above for reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are
committed to providing
complete customer satisfaction.
If you have questions, or if
there are missing parts, we will
guarantee complete satisfaction
through our Customer Service
Department.
Please CALL:
08457-089009
Or WRITE:
ICON Health & Fitness Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds
LS11 8JG
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.
USER'S MANUAL
Class HC
Fitness Product
Visit our website at
www.proform.com
