F3 Field Service Manual – Level 1 Maintenance
•
The wear plate can now be replaced if required. Glue the new wear plate
into the pressure block with a small drop of super-glue, allow the super-glue
to dry before reassembly.
Wear Plate
Armrest
Pressure
Block
Figure 20 Glue the Wear Plate with a small drop of super-glue
P0720-A
Page 19
