F3 Field Service Manual – Level 1 Maintenance
Note: Hold the handle together tightly until the first two bolts have been fitted
otherwise the internal nut or main wiring loom may become dislodged. The
four bolts should initially only be done up loosely.
•
Fit one short (10mm) bolt and nut to the top position in the handle (this will
ensure that the internal nut stays in place).
•
Fit one long (20mm) bolt and nut to the rear of the handle (under the on/off
switch slider).
•
Fit one long (20mm) bolt and nut to the front of the handle (below the noise
cancel button).
• Fit one short (10mm) bolt and nut to the remaining hole near the centre of the
handle.
•
Tighten the four bolts.
•
Place the earset dustcap over the earset socket.
