P r o M i t e O v e r v i e w
3

General Overview

The ProMite charger is a fully Automatic/ Electronic On-board Marine Battery
Charger. ProMite is prewired for easy installation and is 100% waterproof for fresh
and salt water applications.
The ProMite incorporates a durable one piece plastic housing. The ProMite offers
fully automatic charging which includes a "Float " maintenance mode that is safe
for long and short term storage. ProMite can be left on indefinitely without harming
or over charging your batteries.
Easy to view LED indicators will provide you with AC Power On and Charging Status.
The LED Indicators can be seen from the front and side of the charger when
installed.
The ProMite is available in 3 models and can be used in 12, 24 and 24 volt with
engine battery (model specific) configurations without rewiring or switching. Just
attach the DC output cable terminals as illustrated in the installation section of this
manual.
S p e c i f i c a t i o n s & A c c e s s o r i e s

Specifications

model volts amps banks
ProMite5 12 5
ProMite5/5 12/24 10
ProMite5/5/3 12/24/+ENG 13
Optional Accessories
87710 51060
model
Handheld DC System Tester
Remote Battery Bank Status Monitor
ProMite AC Plug Holder (white)
ProMite AC Plug Holder (black)
Universal AC Plug Holder (black)
Universal AC Plug Holder (white)
Battery Bank Cable Extender
Battery Bank Cable Extender
To Place an Order Please Contact Your Local Dealer or ProMariner at:
Tel: 603-433-4440 / Fax: 603-433-4442 / www.promariner.com
DC cable size size L x W x H est. weight
1 6' 6"x 3 .65" x 2.5" 5 lbs
2 6'/6' 9"x 5.25" x 3.5" 8 lbs
3 6'/6'/6' 9"x 5.25" x 3.5" 9 lbs
51201 ProMite Plug Holder
51202 Universal Plug Holder
part no. cable size volts
87710 n/a n/a
51060 10' 12
51200 n/a n/a
51201 n/a n/a
51202 n/a n/a
51203 n/a n/a
51070 15' n/a
51071 5' n/a
12
AC in
90-135
90-135
90-135
51070
banks
n/a
3
n/a
n/a
n/a
n/a
n/a
n/a
