2 | VIDEOJET decoder 3000
Keyboard support
VIDEOJET decoder 3000 allows direct connection of
an IntuiKey keyboard to its serial interface. Controlled
by and communicating to a video management system
this allows to set up PC-less operator desks, ideal for
remote locations like doorman's offices.
IP Matrix system
IP Matrix can be used to control IP-based monitoring
systems of up to 32 cameras and up to ten monitors
via an IntuiKey keyboard without the use of a
computer. In normal operation, the system works only
via the network connections between IP cameras,
encoders and decoders, controlled via the IntuiKey. As
part of a larger CCTV system, IP Matrix can be used as
a satellite system. The higher-ranking system can
access IP Matrix for control purposes.
Otherwise, IP Matrix works independently and is
completely self-sufficient.
Easy upgrade
Remotely upgrade the decoder whenever new
firmware or software becomes available. This ensures
up-to-date products, thus protecting investment with
little effort.
Decoding performance
Encoding
Streams
H.264 HD
1
H.264 HD
1
H.264 HD
1
H.264 SD
4
Certifications and approvals
Safety
Region
Number
IEC 60950-1
System
Region
Number
IEC 62676-2
EN 50132-5-2
Electromagnetic compatibility
Region
Number
EU
EN 55022 ITE
EN 55024 ITE
EN 61000-3-2
EN 61000-3-3
EN 50130-4 Alarm systems
EN 50121-4 Railway
Resolution
Max. bit rate
1080p30
10 Mbps
1080i60
10 Mbps
720p60
10 Mbps
960H/4CIF/
6 Mbps
432p
Region
Number
AUS/NZ
AS/NZS 3548 Class B
US
FCC 47 CFR Part 15 Subpart B Class B
Approvals
Region
Certification
Europe
CE
VIDEOJET decoder 3000
USA
UL
VIDEOJET decoder 3000
UL
Bosch UL online certifications directory
(link)
Installation/configuration notes
Dimensions (front view / side view)
Dimensions in mm (in)
Front connectors and indicators
VIDEOJET decoder 3000 front view
1 HDMI OUT
2 VIDEO OUT
3 AUDIO IN
4 AUDIO OUT
