Gourmet 4 Burner Electronic Grill
Parrilla Electronica Gastrónoma de 4 Hornillas
OWNER'S MANUAL / MANUAL DEL PROPIETARIO
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS
WITH THE GRILL OWNER FOR
FUTURE REFERENCE.
AVISO PARA EL
INSTALADOR:
ENTREGUE ESTAS
INSTRUCCIONES AL
PROPIETARIO DE LA PARRILLA
PARA REFERENCIA FUTURA.
ASSEMBLY AND OPERATING INSTRUCTIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS
ARE IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.
SE PUEDE PRODUCIR UNA EXPLOSIÓN PELIGROSA SI SE HACE CASO OMISO A
ESTAS ADVERTENCIAS E INSTRUCCIONES. LEA Y SIGA TODAS LAS ADVERTENCIAS
E INSTRUCCIONES EN ESTE MANUAL PARA EVITAR LESIONES PERSONALES,
WARNING/ADVERTENCIA
INCLUSO LA MUERTE, O LOS DAÑOS MATERIALES.
MODEL/MODELO 810-8640-S
Advertisement
Table of Contents
Related Manuals for Charmglow Gourmet 810-8640-S
Summary of Contents for Charmglow Gourmet 810-8640-S
- Page 1 Gourmet 4 Burner Electronic Grill Parrilla Electronica Gastrónoma de 4 Hornillas OWNER’S MANUAL / MANUAL DEL PROPIETARIO ASSEMBLY AND OPERATING INSTRUCTIONS INSTRUCCIONES DE ARMADO Y OPERACIÓN SAVE THIS MANUAL FOR FUTURE REFERENCE GUARDE ESTE MANUAL PARA REFERENCIA FUTURA WARNING/ADVERTENCIA NOTICE TO INSTALLER: HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS LEAVE THESE INSTRUCTIONS ARE IGNORED.
- Page 2 IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
-
Page 3: Table Of Contents
TABLE OF CONTENTS General Warnings ..........3 Installation and LP Cylinder Specifications and Safe Use . -
Page 4: General Warnings
GENERAL WARNINGS WARNING • Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. •... -
Page 5: Installation And Lp Cylinder Specifications And Safe Use
WARNING • FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as a garage, shed or breezeway. • Use your grill OUTDOORS in a well ventilated space away from dwellings or other buildings to prevent dangers associated with gas accumulation and toxic vapors. We recommend your grill be situated at least 10 feet (3.1 m) from buildings. - Page 6 CYLINDER SPECIFICATIONS: When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;...
-
Page 7: Connecting Lp Cylinder And Hose / Regulator To Grill
WARNING FILLING THE LP GAS CYLINDER: • Allow only qualified LP gas dealers to properly fill or repair your LP gas cylinder. • New tanks should be purged prior to filling; inform LP gas dealer if you are using a new tank. •... - Page 8 WARNING • Never use your grill without leak testing all gas connections and hoses. See the section on "Leak Testing" in this manual for proper procedures. WARNING The pressure regulator and hose assembly supplied with your gas grill must be used. •...
-
Page 9: Leak Testing
DANGER LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •... -
Page 10: Pre-Start Check List
6. Check each place listed (A–H) for growing bubbles which indicates a leak. 7. Turn off gas supply at cylinder valve. 8. Tighten any leaking connections. 9. Repeat soapy water test until no leaks are detected. 10. Turn off gas supply at cylinder valve until you are ready to use your grill. 11. -
Page 11: Lighting Instructions
WARNING Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip any of the warnings and instructions contained in the preceding sections of this manual. WARNING LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside the grill. -
Page 12: Operating Grill And Helpful Hints
TURNING OFF THE GRILL: 1. Turn off the cylinder valve. 2. Make sure that all burners are off. The red indicator light above the ON/OFF switch for the burners should not be lit. Note: Turn off LP cylinder first to prevent gas from being left in the system under pressure. -
Page 13: Using Other Features Of The Grill
THE SIDE BURNER: • The side burner can be used to prepare side dishes such as beans, potatoes, corn, or to warm sauces. • The burner valve can be adjusted from high to low depending upon your cooking demands. WARNING •... - Page 14 THE CONVECTION OVEN: The convection oven can be used to bake your favorite cookies, cakes, pies, brownies, etc. We do not recommend the use of roasting bags, plastic or glass containers in the oven. For best results, it is recommended that you preheat the convection oven for 5 minutes at 400°F (204.4°C) temperature. 1.
-
Page 15: Grill Cooking Tips
GRILL COOKING TIPS CLEANLINESS • Always wash hands thoroughly with soap and hot water prior to handling food and after handling raw meat, uncooked poultry or seafood. • When using a platter to carry raw meat, uncooked poultry or seafood to the grill, make sure to wash the platter thoroughly with soap and hot water before placing cooked foods back on the platter or use different platters for raw and cooked foods. -
Page 16: Proper Care And Maintenance
PROPER CARE & MAINTENANCE • To protect your grill from excessive rust, the unit must be kept clean and covered at all times when not in use. • Wash cooking grills and heat distribution plates with hot, soapy water, rinse well and dry. Lightly coat cooking grill with vegetable oil or vegetable oil spray. -
Page 17: Burner Assembly/Maintenance
BURNER ASSEMBLY/MAINTENANCE • Although your burners are constructed of stainless steel, they may corrode as a result of the extreme heat and acids from cooking foods or from the climate your grill is exposed to. Regularly inspect the burners for cracks, abnormal holes, and other signs of corrosion damage. If found, replace the burner. •... -
Page 18: Transporting And Storage
WARNING TRANSPORTING AND STORAGE: • Never move a grill when it is hot or when objects are on the cooking surfaces. • Make sure that cylinder valve is shut off. After moving the grill check that all gas connections are free of leaks. Refer to instructions for Leak Testing. •... -
Page 19: Connecting Lp Cylinder And Hose / Regulator To Grill
TROUBLE SHOOTING Problem: Possible Causes: 1. Check LP cylinder fuel level. 2. Bad electrode spark. Check to see if the grill will match light. Electrode or collector may need adjustment. • Burner will not light 3. Burner may not be properly seated. 4. -
Page 20: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Your grill's serial number and model number, and the contact information for Brinkmann Customer Service, are listed on a silver label found beneath the control panel, on the back of the grill or on the side of the grill body, under the side shelf. -
Page 21: Connecting Lp Cylinder And Hose / Regulator To Grill
FREQUENTLY ASKED QUESTIONS Cleaning Stainless Steel Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed. DO NOT use a commercial oven cleaner. For stubborn food residue, use a degreaser and fiber or brass cleaning brush. Cleaning Porcelain-Finished Cast-Iron Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed. -
Page 22: Parts List And Assembly Instructions
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT. ® The following provided tools are required to assemble this Charmglow Gourmet Gas Grill with Electronic Controls: • Screwdriver... - Page 23 FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT: www.brinkmann.net FOR GRILL WARRANTY REPLACEMENT PARTS, PLEASE VISIT US AT: www.grillpartsonline.com (Proof of purchase will be required.) Inspect contents of the box to ensure all parts are included and undamaged.
- Page 24 Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard Side Table Grill Body Assembly Side Table down to protect grill finish and assembly area. CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary.
- Page 25 Step 4 Place the heat distribution plates on the lower ledge above the burners. Insert the rear of warming rack to the Step 5 Side Burner Grate holes in back panel. Place the cooking grills on the ledge above the heat distribution plates. Warming Rack Step 6 Insert the rear of warming rack to...
- Page 26 ® Charmglow 8640 (Assembled)
-
Page 27: Replacement Parts List
REPLACEMENT PARTS LIST Part No: Part Description: Part No: Part Description: 8640-17 Rotisserie Kit 8640-1 Hood Inner Panel 8640-18 Side Tables 8640-2 Hood Handle 8640-19 Side Burner Shelf Kit 8640-3 Logo 8640-20 Side Burner Tray 8640-4 Temperature Gauge 8640-21 Side Burner Orifice Viewing Hole Lid 8640-5 Hood 8640-22... - Page 28 Part No: Part Description: Part No: Part Description: 8640-33 Main Burner Gas Tube-R 8640-61 Heat Insulation Panel for Control Panel 8640-34 Thermocouple 8640-62 Heat Insulation Panel for Touch PCB 8640-35 Motor Mount Bracket Kit 8640-63 Drawer Kit 8640-36 Rotisserie Motor Kit 8640-64 Trim Box Bracket 8640-37...
- Page 29 LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. ® ANY LIABILITY FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE FAILURE OF THE CHARMGLOW GOURMET 4 BURNER ELECTRONIC GRILL TO COMPLY WITH THIS WARRANTY OR ANY IMPLIED WARRANTY IS EXCLUDED. CUSTOMER ACKNOWLEDGES THAT THE PURCHASE PRICE CHARGED IS BASED UPON THE LIMITATIONS CONTAINED IN THE WARRANTY SET OUT ABOVE.
