Installing the Snap On Covers
1.
Housing
Place the unit on a soft surface to avoid damaging the plastic.
Installing The Shroud
Remove
tape backing
before installing.
(A)
Begin by hooking area "A" (above) over the dome light and slide the cover over the unit. The cover will snap in place.
Installing the Screen Cover
(B)
Open the screen and hook the two tabs "B" on the bottom edge of the screen. Snap the opposite side over the hinge.
Installing he t Screw Caps
Plug-in
Install the screw caps after the unit is mounted.
2. 3.
Snap On Cover Snap On Cover
(Shroud) (Screen Back Cab)
1 Pewter, 1 Shale 1 Pewter, 1 Shale
(B)
4
4.
Pry Tool
catch
5.
Screw Cap
(L & R)
2 Pewter, 2 Shale
catch
