CD-IN Connector
Front Audio Connector
Modem-CN Connector
Onboard AC97 CODEC
(Optional)
AUX-IN Connector
CNR Expansion Slot
32-bit PCI Expansion Slot x5
WOM (Wake ON Modem)
Connector
WOL (Wake ON LAN)
Connector
IrDA Connector
nd
2
USB Port Connector
Chassis Fan Connector with
H/W Monitoring
2Mbit Flash ROM BIOS
Front Panel Connector
JP14 CMOS Data Clear Jumper
PS/2 Mouse
SPP/EPP/ECP Parallel Port
Connector
USB Port
PS/2 Keyboard
COM 1 Port
COM 2 Port
Connector
Game Port
MIC-In
Line-In
Speaker Out
JP27 USB Keyboard/Mouse
Wakeup
Resettable Fuse
Low ESR Capacitor
462-pin CPU socket supports
AMD Athlon & Duron
600MHz~1.4GHz+
AGP 4x Expansion Slot
ATX Power Connector
VIA Apollo KT133A (AK73(A)-V)
or KT133 (AK73-V) chipset
CPU Fan Connector
With H/W monitoring
PC-100/133 DIMM Slot x3
supports maximum up to 1.5GB
JP21 FSB Select Jumper
FDD Connector
ATA/33/66/100 IDE Connector x2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AK73(A)-V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AOpen AK73(A)-V

  • Page 1 Connector 600MHz~1.4GHz+ WOL (Wake ON LAN) Connector AGP 4x Expansion Slot IrDA Connector ATX Power Connector VIA Apollo KT133A (AK73(A)-V) or KT133 (AK73-V) chipset USB Port Connector CPU Fan Connector With H/W monitoring Chassis Fan Connector with H/W Monitoring PC-100/133 DIMM Slot x3 supports maximum up to 1.5GB...
  • Page 2: Jp14 Clear Cmos

    1. JP14 Clear CMOS You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. 1. Turn off the system and unplug the AC power. Everything you need to boot this 2. Remove ATX power cable from connector PWR2. motherboard is included in this 3.
  • Page 3: Jp21 Fsb/Pci Clock Ratio

    3. Installing CPU & Housing Fan 5. Setting CPU Voltage & Frequency Plug in the CPU fan cable to the 3-pin CPU FAN connector. If you have chassis fan, you Setting CPU Core Voltage can also plug it on FAN2 (without H/W monitoring) connector. This motherboard supports CPU VID function.
  • Page 4: Connecting Ide And Floppy Cables

    6. CNR Expansion Slots 8. JP27 Keyboard / Mouse Wakeup CNR is a riser card specification to replace the AMR (Audio/Modem Riser) that supports This motherboard provides keyboard / mouse wake-up function. You can use JP27 to V.90 analog modem, multi-channel audio, and phone-line based networking. Because enable or disable function, which could resume your system from suspend mode with CPU computing power is getting stronger, the digital processing job can be implemented keyboard or mouse installed.
  • Page 5: Connecting Front Panel Cable

    12. Connecting CD / MODEM / AUX-IN 10. Connecting ATX Power Connector The CD-IN connector is used to connect CD Audio The ATX power supply uses 20-pin connector shown below. Make sure you plug in the MODEM-CN cable from CDROM or DVD drive to onboard sound. right direction.
  • Page 6: Bios Upgrade

    17. BIOS Upgrade You can use the autorun menu of Bonus CD disc. Choose the utility and driver and select AOpen Easy Flash is a user friendly flash method. The BIOS binary file and flash routine model name. are combined together and you simply run a single file to complete the flash process.
  • Page 7: Part Number And Serial Number

    IDE cable. The problem should be caused by the Check if the system can IDE cables or HDD itself. reboot successfully. Re-install Windows 95, Windows 98 or Windows NT. AK73(A)-V is model name of motherboard; R1.00 is BIOS version...
  • Page 8 Test Report: We recommend to choose board/card/device from the compatibility test reports for assembling your PC. Thanks for choosing AOpen products. To provide the best and fastest service to our http://www.aopen.com/tech/report/default.htm customer is our first priority. However, we receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time.
