5. Installation

1. When making electrical connections it is always recommended that the vehicle's
battery be disconnected from the electrical system before performing the
installation.
Please Note: If the radio is equipped with a built in CD
Changer, you must remove ALL discs before proceeding to
prevent damage to the radio's CD mechanism.
2. Carefully remove the trim panels covering the 10mm bolts that secure the radio
into the dash cavity. Remove these bolts, and carefully pull the radio from the dash
of the vehicle. This will provide access to the factory radio connectors where you
will connect the GateWay harness.
3. Disconnect the factory 12-Pin harness (if present) from the back of the radio.
4. When connecting the satellite radio tuner (SXV100 sold separartely), make the
following connections before connecting the GateWay to the vehicle. Plug the black
end of the 3 foot ISSR12 (8-Pin mini-din to 10-Pin mini-din) into the first port
(farthest from the dipswitches) on the GateWay. Connect the gray end of this cable
into the satellite radio tuner.
5. Plug in the male connector on the PGHTY1 harness into the 12-pin port on the
back of the radio. Next, connect the factory 12-pin harness (if present) into the
female connector on the PGHTY1 harness. Be sure to make a firm connection but
do not force it. Plug the Black micro-fit 24-pin connector on the PGHTY1 harness
into the PXAMG GateWay box.
6. To complete the installation secure the GateWay and satellite radio tuner (SXV100)
into the cavity in the dash behind the radio. Be sure that the cables and interface
modules are not near moving parts or sharp metal edges as they may damage the
cables. To prevent rattling noises inside the dash, use zip ties, tape, or other
fasteners to mount the interfaces securely.
7. With all connections made, reconnect the vehicle's battery, insert the key into the
ignition, and turn the vehicle on. Check for proper operation of the GateWay and
satellite radio tuner before reinstalling the factory dash panels.
Please Note: The first time you access the GateWay, your radio may display
"DEV INIT" while the device is initializing. If this is displayed, please wait one
minute then cycle the ignition off and on. Then access SAT mode again to
begin normal GateWay operation.
4
