CF Series Portable Chillers with CF-1 Instrument
To Process Connection
From Process Connection
Reservoir
Optional Reservoir Sight Glass
Condenser Water-Out
Connection
Reservoir Make-Up
Connection
Condenser Water-In Connection
(optional)
Condenser Water
Regulator Valve
Make-Up Valve
Pump
Caster
Water-Cooled Model.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-6352
Fax: 317-881-1277
Service Department Fax: 317-885-8683
Website: www.Temptek.com
Email: service@Temptek.com
Refrigerant Sight Glass
Expansion Valve
Compressor
Electrical Panel
Condenser
