Cumberland Stove Works MF3800 Installation And Service Manual
Multi-fuel parlor stove
Hide thumbs
Also See for MF3800:
- Operator's manual (32 pages) ,
- Operation and maintenance manual (32 pages) ,
- Troubleshooting manual (2 pages)
Table of Contents
Advertisement
For Qualified Installers Only
• Important operating and maintenance instructions included.
• Read, understand and follow these instructions for safe installation
and operation.
• LEAVE THIS MANUAL WITH ANY PARTY RESPONSIBLE FOR
INSTALLATION AND SERVICE.
• This stove should not be used as the only source of heat in the
house. Power outages and periodic maintenance will result in
a total loss of heat.
HOT! DO NOT TOUCH. SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during operation and
cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as appliance.
• Alert children and adults to hazards of high temperatures.
• DO NOT operate with protective barriers open or removed.
• Keep clothing, furniture, draperies and other combustibles
away.
Tested and approved for shelled field corn, approved pellets and
cherry pits. Burning any other type of fuel voids the warranty.
Please read this entire manual before installation and
using this multi-fuel-burning room heater. Failure
to follow these instructions could result in property
damage, bodily injury or even death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not overfire - If any external part starts to glow, you
are overfiring. Reduce feed rate. Overfiring will void
the warranty.
• Comply with all minimum clearances to combustibles
as specified in the manual. Failure to comply may cause
a house fire.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult local building or fire officials about restrictions and
installation inspection requirements in your area.
• Notify insurance company of parlor stove installation.
WARNING
PRIOR TO OPERATION, THIS UNIT
MUST BE INSTALLED PROPERLY. FOR
OPERATION
AND
MAINTENANCE
PROCEDURES, SEE THE OPERATION
AND MAINTENANCE MANUAL THAT
COMES WITH THE STOVE OR CONTACT
A CERTIFIED DEALER. STOVES SHOULD
BE
INSTALLED
BY
A
INSTALLATION DEALER.
INSTALLATION AND
SERVICE MANUAL
MF3800
MULTI-FUEL
PARLOR STOVE
OMMF3800IS
QUALIFIED
Rev. Date 11/17/10
© 2010 Ardisam, Inc.
All Rights Reserved.
