specifications
Navigation features
Waypoints:
Total:
500 alphanumeric
Nearest:
10 (automatic)
Proximity:
10 (definable)
Routes:
20 reversible with up to 30 points each,
plus MOB and TracBack
Track log:
Approx. 2,000 points
Map datums:
106 plus user datum
Coordinates:
Lat/Lon, UTM/UPS, Loran TD, plus 10 grids,
including Maidenhead
Performance
Receiver:
WAAS enabled, 12 parallel channel
GPS receiver continuously tracks and
uses up to 12 satellites to compute
and update your position
Acquisition times:
Warm:
Approx. 15 seconds
Cold:
Approx. 45 seconds
AutoLocate
:
Approx. 5 minutes
™
Update rate:
1/second, continuous
GPS accuracy:
Position:
< 15 meters, 95% typical*
Velocity:
0.05 meter/sec steady state
DGPS (USCG) accuracy:
Position:
3-5 meters, 95% typical
Velocity:
0.05 meter/sec steady state
DGPS (WAAS) accuracy:
Position:
< 3 meters, 95% typical
Velocity:
0.05 meter/sec steady state
Dynamics:
6g's
Interfaces:
NMEA 0183 and
RTCM 104 DGPS corrections
Antenna:
GA 29 remote marine mount with 30' cable
Plotter/moving map features
Basemap:
Built-in basemap of the Americas to 20
miles includes detailed ocean, river and
lake coastlines, cities, interstates, US
state highways and local thoroughfares
Uploadable maps:
Up to 2.5 megabytes of data
(data is optional)
Plotting scales:
120 feet to 800 nm with dedicated push-
button zoom control
GPSMAP 168 Sounder
(shown with internal antenna)
REV1104
Power
Source:
Usage:
™
modes
Physical
Size:
Weight:
Display:
Case:
Temperature range:
Accessories
Standard:
Optional:
Depth Sounder features (GPSMAP 168 Sounder only)
Frequency:
Transmit power:
Display options:
Alarms:
GPSMAP 162
GPSMAP
®
162 and 168 Sounder
c o mp a tib l e
GPSMAP 162 = 10-40vDC
GPSMAP 168 Sounder = 12-18vDC
GPSMAP 162 = 4 watts max.
GPSMAP 168 Sounder = 10 watts max.
4.63" H x 6.0" W x 2.75" D
(11.7cm x 15.2cm x 7cm)
1 lb. 6 oz. (0.763 kg)
4.2" diagonal (10.7cm) high-contrast,
4-level gray LCD with backlighting
(240 x 240 pixels)
Fully gasketed, high-impact plastic alloy,
waterproof to IEC 529-IPX-7
5º F to 158º F (-15º C to 70º C)
GPSmap 162 chartplotting receiver
Remote antenna with 30' cable or bail
mount antenna bracket (shown below)
Power/data cable
PC cable with AC adapter
User's manual
Surface/flush mount bracket with knobs
Quick start guide
Transom mount transducer
**
(168 Sdr only)
MapSource
CDs:
™
Fishing Hot Spots,
®
BlueChart,
™
U.S. Roads & Recreation, WorldMap,
U.S. Waterways & Lights
Beacon receiver for differential corrections
Transducers in a wide variety of transom
and thru-hull mounts
Marine swivel mount – 1 inch RAM
Quick release flush mount kit
200 kHz
150 watts (RMS), 1200 watts (peak to peak)
Auto bottom tracking, auto ranging,
2X and 4X zoom levels, split screen
feature, and 3-level fish ID
Fish and shallow/deep water
GPSMAP 168 Sounder
M01-10099-01
Big numbers option shows your
navigation status at a glance.
View satellite and differential
receiver status, along with your
position, all on one page.
Topo,
Tide prediction capability is a feature
on both the GPSMAP 162 and 168
Sounder (U.S. and Canada only).
®
©2001 GARMIN Corporation
Garmin International
1200 East 151st Street
Olathe, Kansas 66062, U.S.A.
913/397.8200 fax 913/397.8282
Garmin (Europe) Ltd.
Unit 5, The Quadrangle
Abbey Park Industrial Estate
Romsey, SO51 9DL, U.K.
44/1794.519944 fax 44/1794.519222
Garmin (Asia) Corporation
No. 68, Jangshu 2nd Rd.
Shijr, Taipei County, Taiwan
886/2.2642.9199 fax 886/2.2642.9099
www.garmin.com
Specifications are preliminary and subject to change
without notice.
* Subject to accuracy degradation to 100m 2DRMS
under the U.S. Department of Defense imposed
Selective Availability Program.
** Also available without a transducer.
